K-Tech ET901 Programming Manual

QUICK TROUBLESHOOTING
FAQ
Q. Operator cannot hear passenger at beginning of call.
A. If not using voice message announcement—check to
see if it is deleted properly.
Q. Can the phone work only on phone line power?
A. The SUREphone requires AC power in order to
operate.
Q. Passenger cannot hear operator.
A. Check for excessive noise in elevator, such as a bad
fan. On COP mount units check for proper sealing
between COP and phone faceplate
Line Specifications:
(See also the Installation Guide)
The K-Tech ET901 works on most phone lines meeting
the following minimum conditions:
1. 24 - 51 V Analog line (on hook)
2. DTMF compatible
3. 20 mA min loop current
4. 18 –22 gauge shielded twisted pair in elevator trav-
eling cable.
Phone number hints:
Check to see if you need to dial the area code or 1 be-
fore the number.
On PBX systems you may have to put a 9 or 8 and a
pause ( ) before the phone number. Also you may
need to set the timer to "02" or "03" for proper shutoff.
Special Conditions:
The K-Tech ET901 has it's own built in dialer and cannot
be used with an external dialer.
Using the phone on a ringdown circuit may restrict use
of SUREphone features which are related to the dialing
circuit. Program a pause in phone location 1.
All special phone line features, such as call waiting and
call forwarding should be turned off.
THE INFORMATION BELOW IS IMPORTANT.
YOU MUST HAVE THE SERIAL NUMBER
AVAILABLE WHEN CALLING TECH SUPPORT.
SERIAL #
K-Tech International Inc.
5 _ _ _ _ _
Part # PCB045 Rev. ___
Serial Number: ____________________________
Date Installed: ____________________________
Installed by: ____________________________
Phone Line #: ____________________________
Phone line Voltage: 48VDC (POTS or CO line)
24VDC (PBX System)
Other ____________________
Phone Number(s)
Dialing:
1. ___________________________________
2. ___________________________________
3. ___________________________________
4. ___________________________________
5. ___________________________________
Voice message
________________________________________________
________________________________________________
________________________________________________
________________________________________________
K-Tech International, Inc
56 Ella Grasso Ave
Torrington, CT 06790 USA
Phone (860) 489-9399
Sales: 1-800-993-9399
Tech Support: 1-888-883-8399
Fax (860) 489-4399
Email: support@KTechOnline.com
Website: www.KTechOnline.com
BOK057 Printed in USA
K-Tech
1-888-883-8399
ET901
Programming
Guide
Keep This Booklet for
Reference
Additional information is available at
www.KTechOnline.com
