PCB Piezotronics ICP 222B Installation And Operating Manual page 16

Model Number
222B
Performance
Sensitivity(± 15 %)
Measurement Range(Compression)
Measurement Range(Tension)
Maximum Static Force(Compression)
Maximum Static Force(Tension)
Broadband Resolution(1 to 10,000 Hz)
Low Frequency Response(-5 %)
Upper Frequency Limit
Non-Linearity
Environmental
Temperature Range
Temperature Coefficient of Sensitivity
Electrical
Discharge Time Constant(at room temp)
Excitation Voltage
Constant Current Excitation
Output Impedance
Output Bias Voltage
Physical
Stiffness
Size (Diameter x Height)
Weight
Housing Material
Sealing
Electrical Connector
Electrical Connection Position
Mounting Thread
All specifications are at room temperature unless otherwise specified.
In the interest of constant product improvement, we reserve the right to change specifications without notice.
®
ICP is a registered trademark of PCB Group, Inc.
ICP® FORCE SENSOR
ENGLISH SI
0.90 mV/lb 202.33 mV/kN
6000 lb 26.69 kN
2500 lb 11.12 kN
6000 lb 26.69 kN
2800 lb 12.46 kN
0.2 lb-rms 0.8896 N-rms
0.0003 Hz 0.0003 Hz
12 kHz 12 kHz
≤ 1.5 % FS ≤ 1.5 % FS
-65 to +250 °F -54 to +121 °C
≤ 0.03 %/°F ≤ 0.054 %/°C
≥ 2000 sec ≥ 2000 sec
20 to 30 VDC 20 to 30 VDC
2 to 20 mA 2 to 20 mA
≤ 100 Ohm ≤ 100 Ohm
8 to 14 VDC 8 to 14 VDC
3 lb/µin 0.53 kN/µm
0.870 in x 1.620 in 22.1 mm x 41.51 mm
2 oz 58 gm
Stainless Steel Stainless Steel
Hermetic Hermetic
10-32 Coaxial Jack 10-32 Coaxial Jack
Side Side
3/8 - 24 Female 3/8 - 24 Female
OPTIONAL VERSIONS
Optional versions have identical specifications and accessories as listed for the standard model
except where noted below. More than one option may be used.
J
- Ground Isolated
[1]
M
- Metric Mount
[2]
Mounting Thread
[3]
[4]
N
- Negative Output Polarity
Output Polarity(Compression)
W
- Water Resistant Cable
Electrical Connector
Electrical Connection Position
NOTES:
[1]Typical.
[2]Calculated from discharge time constant.
[1]
[3]Estimated using rigid body dynamics calculations.
[4]Zero-based, least-squares, straight line method.
Entered: LK Engineer: APB
Date: 7/28/2016 Date: 7/28/2016
3425 Walden Avenue, Depew, NY 14043
Revision: K
ECN #: 45758
M10 x 1.00 Female
Negative Negative
Sealed Cable Sealed Cable
Side Side
Sales: KWW Approved: APB
Date: 7/28/2016 Date: 7/28/2016
Phone: 716-684-0001
Fax: 716-684-0987
E-Mail: info@pcb.com
Spec Number:
1249
