User manual - Inverter Ceiling Floor

Inverter Ceiling Floor

User Manual

Models

36K

60K

Table of Contents

Need help?

Do you have a question about the TITAN Series and is the answer not in the manual?

Questions and answers

Summary of Contents for ADINA TITAN Series

Page 1 User manual - Inverter Ceiling Floor Inverter Ceiling Floor User Manual Models...
Page 2: Table Of Contents
PRECAUTION Read the following PRECAUTIONS carefully before installation. The air conditioner must be installed by professional technicians. The installation should be done in accordance with the manual. Please forgive delay of notice in case of any advancement. Content Usage PRECAUTIONS -----------------------------------------------------2 PARTS AND FUNCTIONS ----------------------------------------- 4 OPERATION AND PERFORMANCE ---------------------------------6 MAINTENANCE----------------------------------------------------------- 7...
Page 3: Precautions
USAGE PRECAUTIONS Read the following " PRECAUTIONS" carefully before installation. The caution items stated here must be followed because these important contents are related to safety. The meaning of each indication used is as below. Incorrect installation due to ignoring of the instruction will cause harm or damage, and the seriousness is classified by the following indications.
Page 4 Descrition of symbols Description of icon Icon Meaning Symbol Meaning Contents prohibited are represented Mistaken operation/use may cause Warning by nots or figures. death or serious injury. Mistaken operation/use may cause Execution in force. Iterms forcibly executed Notice injury or damage of properties only. are represented by notes or figures.
Page 5: Parts And Functions
PARTS AND FUNCTIONS Indoor Unit Air Outlet Air Outlet Refrigerant Pipe Junction Refrigerant Pipe Junction Filter Filter Remote controller receiver Remote controller receiver Air outlet Refrigerant connection pipe Refrigerant connection pipe Air inlet Stop valve Stop valve Air Outlet grille Air Outlet grille Remote controller Remote controller...
Page 6 3 minutes protection Restart the unit at once after stopping or turning it off, compressor will not operate in the first 3min ,this phenomena is one of system functions(self-protection) Feature of heating When indoor unit operate in the heat mode, no heat air blows out till3-5min after heat exchanger being warm The outdoor fan motor may stop runnig during operation if outdoor temperature is high.
Page 7: Operation And Performance
OPERATION AND PERFORMANCE CHECKS BEFORE OPERATION Check if the ground wire is connected well. Check if the ground wire is connected well. Check if the air filter is installed well. Check if the air filter is installed well. You must clean the filter and then start the air conditioner when it is not used for a long time. You must clean the filter and then start the air conditioner when it is not used for a long time.
Page 8: Maintenance
MAINTENANCE Malfunction & Handling Ways If the following situation happens, please stop running the air conditioner and cut off the power and If the following situation happens, please stop running the air conditioner and cut off the power and contact with dealers. contact with dealers.
Page 9 2.Defrosting In heating mode, the outdoor heat exchanger may be frosted because the outside temperature is too low. The frost cover may ill effect normal heating effect for AC. Thus, AC will automatically defrost after heating mode is running for a while. In the process of defrostation, the compressor is running with the indoor and outdoor fans stop.
Page 10: Trouble Shooting
2. When used again after the unit stops for a long period: When cleaning the filter and indoor unit, you must stop the unit and cut off power supply. Wipe the indoor unit with soft cloth. It is forbidden to posh the machine with petrol, benzene, lye, powder, detergent, insecticide etc., Which will damage the unit.
Page 11 The display content The definition of failure or protection of indoor LED The indoor-outdoor communication goes wrong. The Room Temperature Sensor T1 goes wrong. The Internal Coil Temperature sensor T2 goes wrong. The External Temperature Sensor T3 goes wrong. The outdoor unit goes wrong. The model configuration processing goes wrong.
Page 12 The display content The definition of failure or protection of indoor LED Module protection Over/Under-voltage protection Over-current protection (Variable-frequency compressor) Outdoor unit protection Exhaust high-temperature protection (Variable-frequency compressor or Slave F3) Under-cooling protection in the cooling mode (Indoor unit coil temperature protection) Over-heating protection in the cooling mode (Condenser high-temperature protection)
Page 13: Installation
INSTALLATION Important safety information Please go through all the IMPORTANT SAFETY INFORMATION before installation. Please install according to the installation manual. Please read the lable on the machine carefully before installation. WARNING Users must engage dealer or authorized specialist for installation. Any structure modification must comply with specific construction standard.
Page 14: Indoor Unit Installation
Charge additional refrigerant The refrigerant charge volume is based on 5m connecting pipe. If the connecting length is longer than 5m,please refer to the followings. please keep record of additional refrigerant charge, pipe length and height drop of indoor&outdoorunit ( stick inside right panel) Electric wiring Choose the electric capacity and circuit according to the design manual.
Page 15 FLOOR CONSOLE TYPE 1.Select the piping and drainage directions. The piping and drain can be made in two directions as shown below(fig.1). When the direction is selected,please drill a 100mm(4 )diameter hole on the wall,and the hole must be tilted downward towards the outdoor for smooth water flow.When the pipe is led out from the rear,make a hole in figure,at the position shown(fig.2).
Page 16 Insert the anchor bolts into the drilled holes, and drive the pins completely into the anchor bolts with a hammer. Hammer Anchor bolts (M10) Install the unit to them with nuts,washers and spring washers NOTE: The installation angle should not exceed 15 degrees. Bolt A Spring washer Washer...
Page 17 UNDER CEILING TYPE 1.Select piping and drain directions. CAUTION: Install the drainage hose at the rear,it should not be installed on the top . When the directions are selected, drill 80 mm (3-1/8") and 50 mm (2") or 150 mm (6") dia. hole on the wall so that the hole is tilted downward toward the outdoor for smooth water flow.
Page 18: Drainage Pipe Connection
DRAINAGE PIPE CONNECTION 1.Installing the drain hose Insert the drain hose into the drain pan, then secure the drain hose with a nylon fastener(we have connected the drain hose to the drain pan in the factory,you just need connect the drain pipe.). Wrap the insulation (drain hose) around the drain hose connection.
Page 19 1.2 Limitations The unit should be installed in accordance with all National, State and local safety Codes and the limitations listed below: 1.Limitations for the indoor unit, coil and appropriate accessories must also be observed. 2.The outdoor unit must not be installed with any duct work in the air stream. The outdoor fan is the propeller type and is not designed to operate against any additional external static pressure.
Page 20 3.0 Unit installation 3.1 Location Before starting the installation, select and check the suitability of the location for both the indoor and outdoor unit. Observe all limitations and clearance requirements. The outdoor unit must have sufficient clearance for air entrance to the condenser coil, for air discharge and for service access.
Page 21 The outdoor unit must be connected to the indoor coil using field supplied refrigerant grade copper tubing that is internally clean and dry .units should be installed only with the tubing sizes for approved system combinations. The charge given is applicable for total tubing lengths up to 17 feet.
Page 22 Fig.5 3.6 Precautions during brazing of lines All outdoor unit evaporator coil connections are copper-to-copper and should be brazed with a phosphorous-copper alloy material such as SIfos-5 or equivalent. DO NOT use soft solder. The outdoor units have reusable service valves on both the liquid and vapor connections.
Page 23 2.Braze the liquid line to the liquid valve at the outdoor unit. Be sure to wrap the valve body with a wet rag. Allow the nitrogen to continue flowing. Refer to the Tabular Data Sheet for proper liquid line sizing. 3.Carefully remove the rubber plugs from the evaporator liquid and vapor connections at the indoor coil.
Page 24 3.8 Unit mounting Base pan (bottom If elevating the heat pump ,either on a flat roof or on view)do not a slab, observe the following guidelines. obstruct drain holes(shaded) 1.The base pan provided elevating a unit on a flat roof or on a slab, observe the following guidelines. 2.If elevating a unit on a flat roof, use 4"...
Page 25 3.10 Removing the top panel and motor When motor requires changing follow the steps 2 bolt below: Step1: Go in to electrical panel, disconnect motor power lines. IMPORTANT NOTE Disconnect main power to unit. Severe burns and 5/16 bolts NOTE: Damage will occur to condenser unit electrical shock will occur if you do not disconnect if you remove fan bolts prior to cover removal.
Page 26 4.3 Wiring Diagram CAUTION: These units musts be wired and installed in accordance with all national and local safety codes. 2 For 48K/55K/60K model 1 For 18K/24K/36K model...
Page 27 5.0 Evacuation It will be necessary to evacuate the system to 500 microns or less. If a leak is suspected, leak test with dry nitrogen to locate the leak. Repair the leak and test again. To verify that the system has no leaks, simply close the vacuum pump suction to isolate the pump and hold the system under vacuum.
Page 28 7.0 Protection function introduction Sensor T3 (condenser pipe temperature) and T4(outdoor ambient temperature) When open-circuit, compressor, outdoor fan motor and reverse valve will be OFF Discharge temperature protection When discharge temp 239 F, compressor will stop < When discharge temp 176 F, compressor will restart High pressure protection When high pressure 652PSIG, compressor and outdoor fan motor will stop...
Page 29 Verify that the outdoor unit is running and the indoor air mover is delivering the maximum airflow for this system size. Read and record the outdoor ambient temperature Read and record the liquid and suction pressures at the ports on the liquid and suction valves. If refrigerant lines are sized using the nameplate charge, the correct liquid pressure is found at the intersection of the suction pressure and the outdoor ambient.
Page 30: Remote Controller
WIRING DIAGRAM REMOTE CONTROLLER The outlooking and some function of remote control may vary according to the model. The shape and position of buttons and indicators may vary according to the model, but their function is the same. The unit confirms the correct reception of each press button with a beep.
Page 31 Remote control DISPLAY Meaning of symbols on the liquid crystal display No. Symbols Meaning FEEL mode indicator COOLING indicator DEHUMIDIFYING indicator FAN ONLY OPERATION indicator HEATING indicator TIMER OFF indicator TIMER ON indicator AUTO FAN indicator LOW FAN SPEED indicator MIDDLE FAN SPEED indicator HIGH FAN SPEED indicator SLEEP indicator...
Page 32 COOLING MODE The cooling function allows the air conditioner to cool the room and at the same time reduces the humidity in the air. To activate the cooling function ( COOL ) , press the MODE button until the symbol appears on the display.
Page 33 TIMER MODE----TIMER ON To set the automatic switching on of the air conditioner. To program the time start,the appliance should be off. Press TIMER , Set the temperature with pressing the key ,Press TIMER Again , set the time with pressing the key , Press the key more times till on the display you can read the time which passes between the programming and the timed start.
Page 34 FEEL MODE To activate the FEEL (automatic) mode of operation, press the MODE button on the remote control until the symbol appears in the display. In the FEEL mode the fan speed and the temperature are set automatically according to the room temperature (tested by the probe which is incorporated in the indoor unit)to ensure user comfort.
Page 35 Air flow direction adjustment procedure Adjusting air flow direction Up/down direction can be adjusted by using the AIRFLOW button on the remote controller. Up/down direction can be adjusted by using the AIRFLOW button on the remote controller. This button,each time pressed,changes the mode in the following sequence: This button,each time pressed,changes the mode in the following sequence: AUTO push the LOUVER button,changes the mode to swing louver .
Page 36 Remote controller handling procedure Batteries replacing procedure Following cases signify dead cells.Replace the dead batteries with new ones. Following cases signify dead cells.Replace the dead batteries with new ones. Receiving sound is not emitted from the unit when signal is transmitted. Receiving sound is not emitted from the unit when signal is transmitted.
