Shuttle XP19 Specifications

Tft monitor

Advertisement

19" Widescreen LCD Monitor
Experience the optimized and colorful image with Shuttle XP19
immediately! XP19 offers well-defined images with its stylish and
elegant appearance. Featuring 24Slim™ body for the space saving
and the slim frame border to maximize the vision. Especially the 5ms
fast response time delivers outstanding image quality definitely gets
you to the true-to-life entertainment. The conveniently integrated
speaker provides incredible audio experience and the friendly on
screen display lets the users individualize the visual preferences while
enjoying the stunning XP19.
XP19 is definitely ideal companion for various applications to extreme
your vision and life. Never miss XP19 if you want to look good with a
good look monitor.

Feature Highlight

Size: 19" (inch) Widescreen, WSXGA+
Type: active Panel TFT Display
Panel Surface: Anti-Glare
Native Resolution: 1680 x 1050
H/V frequency: H: 30-81KHz, V: 56-75Hz

Screen

Brightness: 300 cd/m2
Contrast ratio: 1000:1
Viewing angle: 170° (H) x 160° (V)
Response time: 5 ms
Color resolution: 16.7 million (true color)
Pixel Pitch: 0.243 mm
Video input: RGB Analog, D-Sub 15 pin
Video output: RGB Analog, D-Sub 15 pin

Connectors

Speaker input
Power: Input for external power supply
User Controls: 5 key Control Button
On Screen
Display
Languages: Eng/Deu/Fre/Ita/Spa/Por/Ch-
(OSD)
s/Ch-t/Pol/Rus/Kor/Dan/Dut/Fin/Swe/Jap
Dimensions: 433 x 356 x 24 mm WHD
(17.0" x 14" x 0.9" WHD)
Packing Dimensions: 613 x 517 x 110 mm
Weight: 4.6 / 6.5 kg (net/gross)
Other
features
Power Supply: external, fanless
Power Consumption:
max. 40 W, Standby < 2 W
Speakers: integrated, hidden
Page 1 | 11 July 2008
w w w . s h u t t l e . c o m

Product Specification

Shuttle TFT Monitor
Images for illustration purposes only.
S h u t t l e C o m p u t e r H a n de l s G m b H
Fritz-Stras s man n -Str. 5
25337 Elmshorn | Germany
XP19
Tel. +49 (0) 4121-47 68 60
Fax +49 (0) 4121-47 69 00
s a l e s @ s h u t t l e . e u
