Airtime
Wall Rail – WRC300* | Main Components
™
Wall Anchor
C
A
Positioning
Bar
(shown in
Bracket)
Airtime
Wall Rail – WRC500* | Main Components
™
Wall Anchor
C
A
Positioning
Bar
(shown in
Bracket)
965 West Main Street, Branford, CT 06405 | Fax: 203.764. 1 858 | Email: sales@cygnusmedical.com
Universal
D
Bracket
Universal
D
Bracket
12" RAIL
See next page for WRC100, WRC200 Diagrams.
www.cygnusmedical.com | 800.990.7489
Included
with WRC300:
1 – 36" Rail
2 – Positioning Bars**
36" RAIL
2 – End Caps
B
3 – Wall Anchors
3 – Universal Brackets
End Cap
*Used to mount one Airtime Control
Unit & two fl exible endoscopes.
**Positioning bars used to hold scopes.
Included
36" RAIL
with WRC500:
3 – 36" Rails
B
1 – 12" Rail
End Cap
6 – Positioning Bars**
8 – End Caps
11 – Wall Anchors
7 – Universal Brackets
*Used to mount one Airtime Control
Unit & two fl exible endoscopes. Includes
height reduction system.
**Positioning bars used to hold scopes
36" RAIL
and for height reduction.
