Page 1
Defangatore magnetico sotto caldaia DSBLUE.PL DSBLUE.PL Magnetic boiler filter anuale perativO peratiOn anual SKU 70049 Data di installazione | Installation date ________/________/________ TECNOGAS manuale operativo operation manual...
Page 2
Al fine di non invalidare la garanzia, consigliamo di affidarsi a installatori e manutentori esperti. Thank you for buying this Tecnogas product. For your safety, please read these instructions carefully before use. In order not to avoid guarantee, we strongly recommend to rely on expert technicians and service.
Page 3
Ottone CW 617N UNI EN 12165 Nichelato Fittings and plugs Brass CW 617N UNI EN 12165 nickel plated Elemento filtrante Rete in acciaio inox AISI 304 Filtering element AISI 304 stainless steel mesh Magnete Neodimio Magnet Neodimium TECNOGAS manuale operativo operation manual...
Page 4
E’ fortemente consigliato dotare il sistema di filtrazione di un adeguato sistema di by-pass che ne consenta l’esclusione in caso di necessità. TECNOGAS manuale operativo operation manual...
Page 5
In-line installation with In-line installation with main body facing downwards. For this type of installation it is advisable to provide a ball valve f to provide a ball valve for any of the filter connection TECNOGAS manuale operativo operation manual...
Page 6
Check if the o-ring seal is not demaged; if necessary replace it. Make sure there are no leaks before putting the filter back into operation. If the filter is mounted in horizontal position (Fig. A and B), first relieve the pressure in the filter through the TECNOGAS manuale operativo operation manual...
Page 7
Fig. C Fig. E Per richiedere il Certificato di Conformità (CE o normative di riferimento) inviare una mail a: info@tecnogas.net To request the Compliance Certificate (CE or Rules of Reference), please send an e-mail to: info@tecnogas.net Prodotto distribuito da Tecnogas Srl - Padova (ITALY) e manifatturato in PRC...
