Focus on customized architectural lighting
SHB160 floodlight is a high-power LED floodlight product specially designed for outdoor
landscape lighting. Adopting high thermal conductivity die-casting aluminum shell, with high
thermal conductivity and weather-resistant PU glue potting + sealing ring double waterproof; the
appearance of the lamps is exquisite and generous; the lamps are connected by national
standard flexible cables, which can be bent or deformed at will; the appearance and luminous
color can be customized ; Mainly used for decorative lighting and brightening of building
outlines, overpasses, monuments, columns, flower beds and other places.
Product features & Product Dimension(mm)
★Standard DMX512 control
protocol
★Integrated power supply design, the
power supply method is simpler
protection
★Special
outdoor lightning protection and
static electricity
★Adopt intelligent control
products, support RGB/W
current separate high
brightness adjustable and
special effect design
------------------------------------------------------------------------------------------------------------------------------------------------------------
LED Flood Light Specification
★The lamp can be adjusted at an angle greater
than or equal to 180°
★Can be equipped with anti-glare cover
★Good heat dissipation performance, high
design
for
waterproof level (IP66)
★Sealing
conductive
waterproof design
★Professional optical design, fine and uniform
light mixing, long projection distance
ring
heightened
glue,
full
potting,
thermal
double
Advertisement
Table of Contents
Summary of Contents for SunTech SHB160
- Page 1 LED Flood Light Specification Picture SHB160 floodlight is a high-power LED floodlight product specially designed for outdoor landscape lighting. Adopting high thermal conductivity die-casting aluminum shell, with high thermal conductivity and weather-resistant PU glue potting + sealing ring double waterproof; the appearance of the lamps is exquisite and generous;...
-
Page 2: Product Parameters
Focus on customized architectural lighting Product Parameters Basic parameters Optical parameters 24 ～ DC24V Voltage Power 36 W(Customiz ed ) Power 3030 / 3535 9/24PCS LED quantity Source Control Way DMX512/No control Greyness 65536 / Regular RGB/White ≥80Ra Color Beam angle 5°/ 7 °/10 °/15 °/25 °/30 °/45 °... - Page 3 Focus on customized architectural lighting Adjustable Glass Tempered glass >180 ° angle Other Parameters Working -20°C to 60°C IP Grade IP66 tempetature Storage Electrical -20°C to 55°C temperature safety grade Lifespan 50,000H Control Way & Accessory DMX512 Main ---- controller Slave ---- controller...
-
Page 4: Installation Way
Focus on customized architectural lighting Installation Way 一．Installation method 二：Installation operation Step 1. (As shown above) Step 2. (As shown above) Choose a firm and solid mounting base, Install the lamp, adjust the direction of the pre-install M6-M7 expansion lamp, and tighten the nut so that the screws horizontally according to the hole bracket and the base body are not positions of the mounting bracket；... -
Page 5: System Connection
Focus on customized architectural lighting System Connection System connection diagram： 1. The main controller is used with sub-controllers and data converters. The working voltage of the main control and sub-controllers is AC220V, and the working voltage of the data converter is the same as that of the light source. - Page 6 Focus on customized architectural lighting Precautions: 1. Please read the product manual carefully before installing and using the product; 2. Handle the product with care to avoid damage to the product, please leave it to a professional for installation, repair and maintenance; 3.
