Summary of Contents for Etabeta electronics PA-6000RM
- Page 1 INSTALLATION AND OPERATION MANUAL PA-6000RM & PA-6000SV MATRIX SYSTEM MICROPHONE AND PANEL MANUAal Caution: Please read this manual carefully before operating Damage caused by misuse is not covered by the warranty 1 / 7...
- Page 2 Dear user: Thank you for choose CMX product, before use PA-6000RM & PA-6000SV, please read the attached user manual, so you can know how to user our device. Please keep the user manual safety so you can check it again if any questions during the operation.
- Page 3 Address setting diagram (4 is to detect the termination resistance) PA-6000SV 6X6 matrix multimedia power amplifier control wall controller front and rear panel diagram 3 / 7...
- Page 4 7. Terminal block (connected to the host output network cable AUDIO-) Connection and setup The matrix amplifier has 5 input channels and a complete multi-source audio player. Microphone inputs 1, 2 and 3 are designed for microphone or line-level sources such as CD or MP3 players or mixer outputs.
- Page 5 The paging microphone (PA-6000RM) speaks to the first partition. 1. Press Z1 of the paging microphone (PA-6000RM), the paging indicator will light up, and the digital display of the host will display C0; press the green CALL button to start talking.
- Page 6 Note: Bluetooth connection, initially no password. 1. Balanced audio input 100V/70V speaker unbalanced audio input 8 Ohms Attention 1) Do not install the system equipment in direct sunlight or near the heating element, because the device may be deformed, faded or due to high temperature into the protection state and stop working;...
