Summary of Contents for eCopy AS-Y5091
- Page 1 eCopy Hub Card ASY5091 User Manual Part # 76-4014 Rev # 012304...
- Page 2 Information contained in this document is subject to change without notice. eCopy assumes no responsibility for errors or omissions in this document. Contact eCopy Technical Support for current product information. © 2004, eCopy, Inc. All rights reserved. No part of this manual may be reproduced or transmitted in any form without the express written permission of eCopy, Inc.
-
Page 3: Table Of Contents
Table of Contents Introduction ...1 Features ... 1 System requirements ... 1 Hardware setup...2 Safety instructions and warnings... 2 Network switch removal... 2 Connecting the network cables ... 3 Obtaining technical support ...4... -
Page 4: System Requirements
Introduction The Touchstone Technology 3-Port Network Switch is distributed as an integrated component of eCopy ScanStations. It is a self contained three port switch that fits into a standard, full height, PCI slot. The board is self configuring and receives power from the host computer’s PCI Bus. The board is compliant with FCC Class-B, VCCI, and UL standards. -
Page 5: Hardware Setup
Hardware setup Safety instructions and warnings Expansion cards contain delicate integrated circuits. To protect them against damage from static Caution! electricity, take the following precautions: Always switch off and disconnect the computer and any attached devices from their electrical outlets >... -
Page 6: Connecting The Network Cables
If there is only one network jack > 1. Remove the copier’s network cable from the wall jack and connect it to the left port on the internal 3-port switch. 2. Connect the supplied long Ethernet cable from the network wall jack to the uplink port on the right of the internal 3-port switch. - Page 7 Obtaining technical support Technical support is available to registered users from eCopy during the warranty period or for the duration of your software support and maintenance agreement (contact your supplier for details). When calling eCopy Technical Support, please be at your computer with your system powered on and be prepared to provide the technical support representative with the following information: What to have What it is...
