Camco eaz lift 48800 Installation And Operating Instructions Manual

SCISSOR JACKS
® FOR USE WITH TRAILERS
WARNING: CAREFULLY READ THE FOLLOWING INSTALLATION INFORMATION.
Installation and Operating Instructions
WARNING
• Study, understand, and follow all instructions before operating this device.
• Do not exceed rated capacity.
• Use only on a hard level surface.
• Center load on saddle.
• Scissors Jack is for stabilizing only. Do not use to lift excessive weight.
or tires off the ground. Vehicle frame and door jamb damage may result.
• Do not use scissors jack as a tire changing jack.
• Use only the supplied socket to raise and lower jack.
• Do not use a cheater bar or impact wrench.
• If using a wired or cordless drill, slow the speed as the jack is reaching
fully collapsed state.
• Failure to heed these markings may result in personal injury and/or property damage.
CAUTION: Before using this Leveling Scissor Jack contact your RV manufacturer
about sub-frame strength. Some RVs may be designed and manufactured with
sub-frames incapable of handling force beyond the intended strength to support
the cabin weight. CAMCO CANNOT BE HELD RESPONSIBLE FOR ANY DAMAGES DUE
TO IMPROPER USE OR INSTALLATION OF THIS PRODUCT. CAMCO CANNOT BE HELD
ACCOUNTABLE FOR THE STRUCTURAL INTEGRITY OF ANY RV FRAME.
CD895151 1009362R3 #1220
MODEL
#48800 - 20" (2 pack-5000 lb)
#48810 - 24" (1 pack-5000 lb)
#48820 - 24" (2 pack-5000 lb)
#48830 - 24" (2 pack-7500 lb)
#48840 - 30" (2 pack-5000 lb)

Tools for Installation

• 50 ft string
• C-clamps or ViseGrips
• Electric drill
• 1/8" drill bit
• 11/32" drill bit
• Arc welder (Used only if
welding jacks to frame)
• 9/16" socket
• Ratchet w/extension
• Lithium Grease
• Appropriate safety protection
(gloves, eye protection, etc.)
NOTICE
If product components are
missing or damaged do not
return to dealer, contact the
manufacturer.
1-800-334-2004
