FOLDING POWER WHEELCHAIR
PW-1800
OWNER'S MANUAL

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the PW-1800 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for KOMFI-RIDER PW-1800

Summary of Contents for KOMFI-RIDER PW-1800

  • Page 1 FOLDING POWER WHEELCHAIR PW-1800 OWNER’S MANUAL...

  • Page 2: Table Of Contents

    TABLE OF CONTENT 1. PW1800：Power Wheelchair 1.1. Specifications------------------------------------------------ 2 1.2. Outline-------------------------------------------------------- 3 1.3. Assembling-------------------------------------------------- 4~5 1.4. Folding & Disassembling---------------------------------- 6 2. Caution-------------------------------- --------------------------- 7~8 3. Controller Description & Security Function -------------- 9 3.1 Security Function------------------------------------------- 9 4. Operation guide--------------------------------------------- 5. Special Features -------------------------------------------------- 12 6.

  • Page 3: Specifications

    1.1. Specification: 1. Frame Material: high-quality SPCC steel pipe 2. Framework: foldable 3. Motor output: 200W × 24V × 2pcs 4. Battery: 36AH ×12V × 2pcs 5. Charger: 5Amp, Off-board 6. Brake: Electromagnetic brake /Manual brake 7. Max. Speed: 6.4km/h 8.

  • Page 4: Outline

    1.2. Outline: PW-1800 FRONT VIEW 1. Push handle 2. Backrest 3. Armrest 4. Side panel 5. Drive motor 6. Rear wheel 7. Joystick 8. Controller 9. Footrest 10. Heel loop 11. Foot plate 12. Front caster 13. Rear bag 14. Backrest Folding Mechanism 15.

  • Page 5: Assembling

    1.3. Assembling: 1. Press down the seat tubes with your both hands and please make sure the tubes are tightly fixed on the crossbar guides. (Fig. 1& 3) 2. The backrest Folding Mechanism can adjust the backrest. (Fig.2) 3. Attach the bottom of the backrest with the seat. (Fig.4) 4.
  • Page 6 DO NOT OPERATE THIS ELECTRIC WHEELCHAIR WITHOUT FIRST READING AND UNDERSTANDING THIS MANUAL. Three main connectors from the controller (Indications are labeled on the wires) To connect the power cables from the controller to the motor and the battery connectors, you need to connect left motor connector to left one, right motor connector to right one, power connector to battery connector.

  • Page 7: Folding & Disassembling

    1.4. Folding & Disassembling: 1. Turn off the power (press the power button again), the battery gauge will turn off. (Fig.10) 2. Disconnect the battery connectors and take out two batteries. (Fig.11 & 12) 3. Unleash the heel loop (Fig. 13) (optional) 4.

  • Page 8: Caution

    2. Caution: 1. Always make sure the power is off when getting off or on the power wheelchair. 2. Always make sure the clutch levers are in engaged mode before getting on or getting off the wheelchair. (Paralleled to the wheels) 3.
  • Page 9 17. Please do not drive your power-chair without the illuminate facilities during the nighttime. 18. Please do not lower the footplate to less than 50mm(2”) above the ground, because accidents might occur owing to insufficient ground clearance. 19. Keep your feet on the footplate at all times during operation and do not stand on the footplate.

  • Page 10: Controller Description & Security Function

    3. Controller description 5. Button Battery Gauge 1.Joystick 2.Speed Down 6.Buzzer Button Button 3.Service Indicator 4.Speed up 7. Power ON/OFF Button ＊Battery gauge ： When the indicators are turned on, the battery gauge is showed below: Green lights: The battery has full capacity. Orange lights: Do not drive power-chair for a long trip.
  • Page 11 The following system diagnostics are provided as below table: Flash Description Recommended Action Code Motor Current Over Motor current is over the controller set limit. Release Limit Fault the joystick to neutral and try again. Try charging the batteries. Battery Fault Batteries may require replacing.

  • Page 12: Operation Guide

    4. Operation Guide: 1. Rotate the clutch lever of gearbox inward to connect the drive. (paralleled to the wheels) 2. After seated on the wheelchair, turn on the power (Press the power button), and the battery gauge will turn on. 3.

  • Page 13: Special Features

    5. Special Features Freewheel Levers The power wheelchair is equipped with two freewheel levers. These levers allow you to disengage the drive motors and maneuver the chair manually. WARNING! DO NOT use your wheelchair while the drive motors are disengaging unless you are in the presence of on an incline.

  • Page 14: Battery Charger

    6. Battery Charger 1. Output fuse of anti-polarity counter 2. Charge cable 3. Power switch 4. 115V/230V switch 5. Socket of power cable 6. Radiating fan 7. Red light: the power input indicator 8. Yellow light: being charged 9. Green light: charging finished 6.1.

  • Page 15: Features

    6.2. Features: 1. Ensures the battery connection automatically. 2. Monitoring in all procedure until the battery is fully charged. 3. For protecting exhausted batteries, slow charge in the beginning and fast charge until it goes up to the normal voltage. 4.

  • Page 16: Note

    6.5. Note: 1. Ensure the output-DC voltage corresponds to the battery type and voltage. Otherwise might cause explosion. 2. Switch off the charger (O) before connecting the charger and the battery. 3. Do not expose the charger to the rain, water or near fire materials. Do not store the charger in humid places or in closed places.

  • Page 17: Maintenance & Warranty

    7. Maintenance & Warranty: 7.1Maintenance (consuming parts): 1. Battery: Please charge instantly after long distance driving to prolong the battery. And does the full charge per 2 weeks if long time no drive. Please use maintenance/water- free battery to avoid trouble. 2.

  • Page 18: Emc Statements

    8. EMC statements This portion of the content will provide the user with basic information that describes the problems with EMI, known sources of EMI, protective measures either to lessen the possibility or exposure or to minimize the degree of exposure, and suggested action should unexpected or erratic movement occur.
  • Page 19 The sources of radiated EMI can be broadly classified into three types: 1. Hand-held portable transceivers (transmitter-receivers with the antenna mounted directly on the transmitting unit. 2. Examples include: citizens band (CB) radios, “ walkie talkie”, security, fire, and police transceivers, cellular telephones and other personal communication devices.
  • Page 20 ■WARNINGS Electromagnetic interference (EMI) from sources such as radio and TV stations, amateur radio (HAM) transmitters, two-way radios, and cellular phones can affect powered vehicles and motorized wheelchair. Following the warnings listed below should reduce the chance of unintended brake release or powered vehicle movement, which could result in serious injury.
  • Page 22 Notes For all further information, contact your local dealer. Dealer’s details: One Rehab |Unit 1 Fernwood Estate |Shillinglee Road | Chiddingfold | Godalming | GU8 4SX...
