ToolPRO CGA18BD.9 Instruction Manual

Hide thumbs

Advertisement

Quick Links

Download this manual
TOOLPRO
18V Angle Grinder
Instruction Manual
Important
- Please read these instructions fully before operating or maintaining your cordless angle grinder
These instructions contain important information that will help you get the best from your li-ion
cordless angle grinder, ensuring it remains safe to operate.
If you need help or have damaged or missing parts, call the Customer Helpline on 1300 889 028
After Sales Support
FREE CALL 1300 889 028
EMAIL:salesau@positecgroup.com
CGA18BD.9

Advertisement

loading
Need help?

Need help?

Do you have a question about the CGA18BD.9 and is the answer not in the manual?

Questions and answers

Related Manuals for ToolPRO CGA18BD.9

Summary of Contents for ToolPRO CGA18BD.9

  • Page 1 TOOLPRO 18V Angle Grinder CGA18BD.9 Instruction Manual After Sales Support FREE CALL 1300 889 028 EMAIL:salesau@positecgroup.com Important - Please read these instructions fully before operating or maintaining your cordless angle grinder These instructions contain important information that will help you get the best from your li-ion cordless angle grinder, ensuring it remains safe to operate.

  • Page 2: Table Of Contents

    Contents Safety Information ....................3 In The Box ....................... 11 Accessories ......................11 Operating Instructions .................... 12 Working Hints For Your Angle Grinder..............18 Maintenance ......................18 Trouble Shooting ....................18 Technical Data ......................19 Customer Helpline 1300 889 028...

  • Page 3: Safety Information

    Safety Information Important - Please read these instructions fully before starting assembly Warning Symbols To reduce the risk of injury, Please read the instruction manual Warning Wear ear protection Wear eye protection Wear dust mask Indoor use only Do not expose to rain or water Do not burn Waste electrical products must not be disposed of with household waste.
  • Page 4 Safety Information Important - Please read these instructions fully before starting assembly General Power Tool Safety Warnings WARNING! Read all safety warnings and all instructions. Failure to follow the warnings and instructions may result in electric shock, fire and/or serious injury. Save all warnings and instructions for future reference.
  • Page 5 Safety Information Important - Please read these instructions fully before starting assembly General Power Tool Safety Warnings key left attached to a rotating part of the power tool may result in personal injury. e) Do not overreach. Keep proper footing and balance at all times. This enables better control of the power tool in unexpected situations.
  • Page 6 Safety Information Important - Please read these instructions fully before starting assembly General Power Tool Safety Warnings If contact accidentally occurs, flush with water. If liquid contacts eyes, additionally seek medical help. Liquid ejected from the battery may cause irritation or burns. 6) Service Have your power tool serviced by a qualified repair person using only identical replacement parts.
  • Page 7 Safety Information Important - Please read these instructions fully before starting assembly Safety Instructions For All Operations area must wear personal protective equipment. Fragments of workpiece or of a broken accessory may fly away and cause injury beyond immediate area of operation. j) Hold the power tool by insulated gripping surfaces only, when performing an operation where the cutting tool may contact hidden wiring.
  • Page 8 Safety Information Important - Please read these instructions fully before starting assembly Safety Warnings Specific for grinding and cutting-off operations Safety Warnings Specific for Grinding and Abrasive Cutting-Off Operations: a) Use only wheel types that are recommended for your power tool and the specific guard designed for the selected wheel.
  • Page 9 Safety Information Important - Please read these instructions fully before starting assembly General Safety Warnings for your battery charger WARNING: Read all safety warnings and all instructions. Failure to follow the warnings and instructions may result in electric shock, fire and/or serious injury. Save all warnings and instructions for future reference.
  • Page 10 Safety Information Important - Please read these instructions fully before starting assembly Safety Warnings for battery pack a) Do not dismantle, open or shred cells or battery pack. b) Do not short-circuit a battery pack. Do not store battery packs haphazardly in a box or drawer where they may short-circuit each other or be short-circuited by conductive materials.

  • Page 11: In The Box

    In The Box Parts Auxiliary handle Guard clamping lever Spindle lock button Disc On/Off switch Disc guard Soft grip handle Spanner Battery pack release button * Inner flange Battery pack * Outer flange Accessories Anti-vibration auxiliary handle Spanner Quick adjustment guard Customer Helpline 1300 889 028...

  • Page 12: Operating Instructions

    Operating Instructions NOTE: Before using the tool, read the instruction book carefully. 1. CHARGING YOUR BATTERY PACK A) CHARGING THE BATTERY The battery charger supplied is matched to the Li-Ion battery installed in the machine. Do not use another battery charger. The Li-ion battery is protected against deep discharging.
  • Page 13 Operating Instructions packs. Indicator lights indicate problems (see table below). If this occurs, insert a new battery pack to determine if the charger is OK. If the new battery charges correctly, then the original pack is defective and should be returned to a service center or recycling service center.
  • Page 14 Operating Instructions WARNING: For cutting metal, always work with the wheel guard for cutting. The wheel guard for cutting is mounted in the same manner as the wheel guard for grinding. 2. INSTALLING AND ADJUSTING AUXILIARY HANDLE (SEE FIG. E) You have the option of two working positions to provide the safest and most comfortable control of your angle grinder.
  • Page 15 Operating Instructions 3. FITTING THE DISCS (SEE FIG. F1-F3) Put the inner flange onto the tool spindle. Ensure it is located on the two flats of spindle (See F1). Place the disc on the tool spindle and inner flange. Ensure it is correctly located. Fit the threaded outer flange making sure it is facing in the correct direction for the type of disc fitted.
  • Page 16 Operating Instructions 5. HAND GRIP AREAS (SEE FIG. G) Always hold your angle grinder firmly with both hands when operating. 6. SLIDE ON/OFF SWITCH (SEE FIG. H) To start the power tool, first press the back of on/off switch, then push the on/off switch forward.
  • Page 17 Operating Instructions 7. REMOVING THE GUARD Never remove your guard for any other working conditions. To remove, first take off the disc and both flanges. Then open the clamping lever and rotate the guard to align the projections with the gear case cut outs, then remove the guard. To re-fit the guard, repeat this process in reverse.

  • Page 18: Working Hints For Your Angle Grinder

    Working Hints For Your Angle Grinder 1. Always start at no load to achieve maximum speed then start working. 2. Do not force the disc to work faster, reducing the Disc’s moving speed means longer working time. 3. Always work with a 15-30 angle between disc and workpiece. Larger angles will cut ridges into the workpiece and affect the surface finish.

  • Page 19: Technical Data

    Trouble Shooting 5. The power-draw from the battery generates heat. This is increased as the energy draw increases. You will not damage the battery pack and the generated heated heat is normal. Should you desire to cool it down, simply allow the drill to cool off prior to continuing work.
