Cubii Total Body+ Quick Start Manual

Using Your Cubii Total Body+
Follow the guidelines below to enhance your experience.
ADJUSTING THE RESISTANCE
Cubii Total Body+ has 12 resistance levels. Adjust
your workout intensity by pressing the plus (+) or
minus (-) button on the built-in display monitor, or via
the Cubii app. Level 1 is the lowest intensity and level
12 is the highest. We recommend you begin at Level 1
and increase the intensity gradually over time.
GETTING YOUR GROOVE
You can use your Cubii Total Body+ in short intervals throughout the day or
for long periods of time. We recommend you begin with a five minute session,
see how your body feels afterwards, and increase your session length gradually
over time. You can also go forwards or backwards on the Cubii Total Body+
to work different muscle groups.
USING THE RESISTANCE HANDLES
Before using, firmly grasp the handles and place your feet on the pedals or
the base plate of your Total Body+ elliptical. Pull the handles up and out of the
elliptical to a neutral position, and begin your exercise routine. Once finished,
TM
return the handles to their resting position on the elliptical body.
CARRYING AND STORING YOUR TOTAL BODY+
• To store Cubii, simply keep it in a clean dry place.
• Cubii Total Body+ is approximately
CONTACT
20.9"L x 17.6"W x 10.1"H
1-844-282-4401 (53.2cm x 44.7cm x 25.7cm)
cubii.com/help • Hold the handle to move Cubii.
For additional support, place your
support@mycubii.com
other hand under the base. Do not
use the pedal arms to move Cubii.
Ask someone for help if you find
it too heavy to lift.
WARNING: The maximum recommended extension of the resistance handles is four feet
when using both handles together, and eight feet when using just one. Please do not extend
beyond this threshold. Please only use resistance handles while seated.
v1
™
READING THE DISPLAY CONSOLE
User Options: Press the USER button to switch
between User 1, User 2, and Guest. Current selection
indicated by triangle.
Top Row: The top row displays your total number of
strides. A "stride" is the equivalent of one full rotation
of the pedaling motion.
Middle Row:
The middle row displays the resistance
level through both a resistance meter and the
resistance level number. For example, when you are at
full resistance, the resistance meter will be completely
solid and the number will read "12".
Bottom Row: The bottom row displays the metrics:
TIME elapsed during active workout CALORIES burned
DISTANCE (mi or km) pedaled RPM rotations per minute
(pedaling speed)
Press the MODE button to switch between metrics. Use the
to automatically toggle between metrics every 7 seconds.
Bluetooth® Wireless Technology Features: The Bluetooth® symbol
flashes when available to connect to a device. The symbol remains solid
when connected to the Cubii app. The elliptical must be charged to
pair with a device.
Battery Indicator: The number of bars in the battery symbol indicates
battery charge remaining. The symbol will flash for 20 seconds when unit
requires recharging. The symbol flashes while charging and remains solid
when charging is complete. The symbol disappears when not plugged in.
Distance Metric Toggle:
To switch between miles and kilometers, use the
MODE button to select the DISTANCE metric, then hold the
for 6 seconds.
Manual Data Reset:
Manually reset workout data for any profile by selecting
the profile, then hold MODE for 3 seconds. This resets data displayed on the
screen for the selected profile.
See the included Owner's Manual for more features, such as creating a "Smart Reset" to
automatically reset workout data each night, or for info on unlinking profiles from the console.
Please Note: Cubii Total Body+ is only to be used while sitting. Do not stand on the unit.
Quick Start Guide
SCAN mode
MODE button
