Polygroup TG76M2AGMD21 Assembly Instructions

NEED HELP?
DO NOT RETURN TO STORE. PLEASE VISIT US AT:
www.polygroupstore.com OR 1-888-919-0070
TREE ASSEMBLY INSTRUCTIONS
Congratulations on purchasing your new tree from
This tree comes with Quick Set® technology - allowing you to set up your tree and light it up in minutes!
Carefully follow the instructions below on how to quickly and easily set up your new tree.
1. Before you start to assemble your tree, choose an appropriate location near a wall outlet.
2. Assemble the tree stand and place on a level surface. (See Fig. A)
Fig. A - Tree Stand Assembly
Fig. B - Tree and Light Assembly
Section 1
3. Each tree section is numbered with a sticker. Please identify all sections before assembling.
4. Assemble the tree from bottom to the top. Start with the bottom section and remove the protective cap before inserting into the
assembled stand. Make sure the pole is firmly inserted and secured into the stand.
5. Continue by inserting the upper tree section(s) to the lower section(s) until inserting the tree top.
6. Allow branches to fall into place or gently pull up and out. When adjusting branches, be sure that all wires are free of branch hinges.
7. Insert green label adapter insert into the wall outlet (See Fig. B), your entire tree should now be lit.
8. Begin to shape the branches and tips working from the bottom to the top. Start with tips farthest from the pole and fan out one to
the right, one to the left and one at the center of the main stem. (See Fig. C)
Fig. C
Top view
MODEL #: TG76M2AGMD21
Polygroup®!
Tree top
Section 2
Side view
Unfold the legs and lay the
stand in a flat area. Then slide
the locking disc downward and
snap into place.
Open the
cap cover
Align both arrows
in a straight line
before sliding
down to insert
Insert Green
Adapter
Label Plug
To Be Plugged
into Adapter
Into Wall
Outlet
1
*Electrical Rating For The Tree
(For Indoor Use Only)
Input: 120VAC, 60Hz, 0.38A
Output: 29V DC 0.621A
Do Not Tamper
Internal Parts
