Operating Instructions

Vibrating level switch for

powders relay (DPDT)

VF-90

VIBRATING FORK

Table of Contents

Need help?

Do you have a question about the VF-90 and is the answer not in the manual?

Questions and answers

Summary of Contents for BINMASTER VF-90

Page 2: Table Of Contents
Dismounting steps......................26 Disposal ......................... 26 Supplement ..........................27 Technical data ........................ 27 Dimensions ........................30 Industrial property rights ....................32 Trademark ........................32 VEGAWAVE 61 • Relay (DPDT) VF-90 Vibrating Rod | 925-0376 | ©2023 BinMaster all rights reserved...
Page 3 Safety instructions for Ex areas: Take note of the Ex specific safety instructions for Ex applications. These instructions are attached as documents to each instrument with Ex approval and are part of the operating instructions. Editing status: 2022-09-15 VEGAWAVE 61 • Relay (DPDT) VF-90 Vibrating Rod | 925-0376 | ©2023 BinMaster all rights reserved...
Page 4: About This Document
The dot set in front indicates a list with no implied sequence. Sequence of actions Numbers set in front indicate successive steps in a procedure. Disposal This symbol indicates special instructions for disposal. VEGAWAVE 61 • Relay (DPDT) VF-90 Vibrating Rod | 925-0376 | ©2023 BinMaster all rights reserved...
Page 5: For Your Safety
Arbi- trary conversions or modifications are explicitly forbidden. For safety reasons, only the accessory specified by the manufacturer must be used. To avoid any danger, the safety approval markings and safety tips on the device must also be observed. VEGAWAVE 61 • Relay (DPDT) VF-90 Vibrating Rod | 925-0376 | ©2023 BinMaster all rights reserved...
Page 6: Safety Label On The Instrument
DIN EN ISO 14001. Please help us fulfil this obligation by observing the environmental instructions in this manual: • Chapter " Packaging, transport and storage" • Chapter " Disposal" VEGAWAVE 61 • Relay (DPDT) VF-90 Vibrating Rod | 925-0376 | ©2023 BinMaster all rights reserved...
Page 7: Product Description
Principle of operation VEGAWAVE 61 is a point level sensor with tuning fork for point level Application area The VF-90 detection. VEGAWAVE 61 • Relay (DPDT) VF-90 Vibrating Rod | 925-0376 | ©2023 BinMaster all rights reserved...
Page 8: Adjustment
Solid detection in water If VEGAWAVE 61 was ordered for solids detection in water, the tuning If the VF-90 was ordered for solids detection in water, the tuning fork is set to the density of water. In air or when immersed in water the VF-90 signals “uncovered”.
Page 9 Lifting and carrying With instrument weights of more than 18 kg (39.68 lbs) suitable and approved equipment must be used for lifting and carrying. VEGAWAVE 61 • Relay (DPDT) VF-90 Vibrating Rod | 925-0376 | ©2023 BinMaster all rights reserved...
Page 10: Mounting
DIN/EN/IEC/ANSI/ISA/UL/CSA 61010-1. It can be used indoors as well as outdoors. In general, the VF-90 can be installed in any position. The instru- In general, VEGAWAVE 61 can be installed in any position. The instru- Switching point...
Page 11: Mounting Instructions
4 Mounting Fig. 2: Measures against moisture ingress Do not hold the VF-90 on the vibrating element. Especially with Transport Do not hold VEGAWAVE 61 on the vibrating element. Especially with the VF-90 flange and tube versions, the sensor can be damaged by the weight of the instrument. Remove the protective cover just before mounting.
Page 12 61 horizontally. However, if the switching point can have a tolerance of a few centimeters, we recommend mounting VEGAWAVE 61 approx. the VF-90 approx. the VF-90 20° inclined to the vessel bottom to avoid buildup. VEGAWAVE 61 • Relay (DPDT) VF-90 Vibrating Rod | 925-0376 | ©2023 BinMaster all rights reserved...
Page 13 Inflowing medium If VEGAWAVE 61 is mounted in the filling stream, unwanted false the VF-90 measurement signals can be generated. For this reason, mount the VF-90 at a position in the vessel where no disturbances, e.g. VEGAWAVE 61 at a position in the vessel where no disturbances, e.g. the VF-90 from filling openings, agitators, etc., can occur.
Page 14 In applications such as grit chambers or settling basins for coarse falling rocks sediments, the vibrating element must be protected against damage with a suitable baffle. This baffle must be manufactured by you. > 125 mm (> 5") Fig. 7: Baffle for protection against mechanical damage VEGAWAVE 61 • Relay (DPDT) VF-90 Vibrating Rod | 925-0376 | ©2023 BinMaster all rights reserved...
Page 15: Connecting To Power Supply
Take note of the corresponding installation regulations for Ex applica- Connection cable tions. for Ex applications Cover all housing openings conforming to standard according to EN 60079-1. VEGAWAVE 61 • Relay (DPDT) VF-90 Vibrating Rod | 925-0376 | ©2023 BinMaster all rights reserved...
Page 16: Connection Procedure
11. Screw the housing lid back on The electrical connection is finished. Wiring plan, single chamber housing The following illustrations apply to the non-Ex as well as to the Ex-d version. VEGAWAVE 61 • Relay (DPDT) VF-90 Vibrating Rod | 925-0376 | ©2023 BinMaster all rights reserved...
Page 17 Wiring plan We recommend connecting VEGAWAVE 61 in such a way that the We recommend connecting the VF-90 in such a way that the switching circuit is open when there is a level signal, line break or failure (safe state).
Page 18 It is imperative that you take measures to extinguish sparks to protect the relay contact (e.g. Z diode) or use an electronic version with transistor output. VEGAWAVE 61 • Relay (DPDT) VF-90 Vibrating Rod | 925-0376 | ©2023 BinMaster all rights reserved...
Page 19: Setup
With the potentiometer you can adapt the switching point to the solid. range (1) It is already preset and must only be modified in special cases. By default, the potentiometer of the VF-90 is set to the right stop By default, the potentiometer of VEGAWAVE 61 is set to the right stop the VF-90 (>...
Page 20: Function Table
Dry run protection (6) (7) Relay energized Green Mode min. Dry run protection (6) (7) Relay deenergized Failure of the supply volt- (min./max. mode) (6) (7) Relay deenergized VEGAWAVE 61 • Relay (DPDT) VF-90 Vibrating Rod | 925-0376 | ©2023 BinMaster all rights reserved...
Page 22: Maintenance And Fault Rectification
VEGA service hotline under the phone no. +49 1805 858550. The hotline is manned 7 days a week round-the-clock. Since we offer this service worldwide, the support is only available in the English language. The service is free, only standard call charges are incurred. VEGAWAVE 61 • Relay (DPDT) VF-90 Vibrating Rod | 925-0376 | ©2023 BinMaster all rights reserved...
Page 23: Exchanging The Electronics Module
2. Unscrew the housing lid 3. Lift the opening levers of the terminals with a screwdriver 4. Pull the connection cables out of the terminals 5. Loosen the two screws with a screw driver (Torx size T10 or slot VEGAWAVE 61 • Relay (DPDT) VF-90 Vibrating Rod | 925-0376 | ©2023 BinMaster all rights reserved...
Page 24: How To Proceed If A Repair Is Necessary
By doing this you help us carry out the repair quickly and without having to call back for needed information. VEGAWAVE 61 • Relay (DPDT) VF-90 Vibrating Rod | 925-0376 | ©2023 BinMaster all rights reserved...
Page 25 Attach the completed form and, if need be, also a safety data sheet outside on the packaging • Ask the agency serving you to get the address for the return ship- ment. You can find the agency on our homepage. VEGAWAVE 61 • Relay (DPDT) VF-90 Vibrating Rod | 925-0376 | ©2023 BinMaster all rights reserved...
Page 26: Dismount
If personal data is stored on the old device to be disposed of, delete it before disposal. If you have no way to dispose of the old instrument properly, please contact us concerning return and disposal. VEGAWAVE 61 • Relay (DPDT) VF-90 Vibrating Rod | 925-0376 | ©2023 BinMaster all rights reserved...
Page 27: Supplement
Ʋ Pipe thread, conical (ASME B1.20.1) 1½ NPT Instrument weight (depending on pro- 0.8 … 4 kg (0.18 … 8.82 lbs) cess fitting) Max. lateral load 600 N (135 lbf) VEGAWAVE 61 • Relay (DPDT) VF-90 Vibrating Rod | 925-0376 | ©2023 BinMaster all rights reserved...
Page 28 -40 … +80 °C (-40 … +176 °F) Process conditions Measured variable Limit level of solids Process pressure -1 … 25 bar/-100 … 2500 kPa (-14.5 … 363 psig) VEGAWAVE 61 • Relay (DPDT) VF-90 Vibrating Rod | 925-0376 | ©2023 BinMaster all rights reserved...
Page 29 Operating voltage 20 … 253 V AC, 50/60 Hz, 20 … 72 V DC (at U >60 V DC, the ambient temperature can be max. 50 °C/122 °F) Max. power consumption 8 VA (AC), 1.5 W (DC) VEGAWAVE 61 • Relay (DPDT) VF-90 Vibrating Rod | 925-0376 | ©2023 BinMaster all rights reserved...
Page 30: Dimensions
½ NPT Fig. 15: Housing versions Plastic single chamber Stainless steel single chamber (electropolished) Stainless steel single chamber (precision casting) Aluminium - single chamber VEGAWAVE 61 • Relay (DPDT) VF-90 Vibrating Rod | 925-0376 | ©2023 BinMaster all rights reserved...
Page 31 The VF-90 threaded version Fig. 16: VEGAWAVE 61, threaded version G1½ (DIN ISO 228/1) The VF-90 ø 34 mm (1.34") Fig. 17: Temperature adapter VEGAWAVE 61 • Relay (DPDT) VF-90 Vibrating Rod | 925-0376 | ©2023 BinMaster all rights reserved...
Page 32: Industrial Property Rights
собственность. Дальнейшую информацию смотрите на сайте www.vega.com. VEGA系列产品在全球享有知识产权保护。进一步信息请参见网站< www.vega.com。 Trademark All the brands as well as trade and company names used are property of their lawful proprietor/ originator. VEGAWAVE 61 • Relay (DPDT) VF-90 Vibrating Rod | 925-0376 | ©2023 BinMaster all rights reserved...
Page 36 Phone: 402-434-9102 VEGA Grieshaber KG Am Hohenstein 113 Phone +49 7836 50-0 7201 N 98th St Fax: 402-434-9133 77761 Schiltach E-mail: info.de@vega.com Lincoln, NE 68507 Email: info@binmaster.com Germany www.vega.com www.binmaster.com VF-90 Vibrating Rod | 925-0376 | ©2023 BinMaster all rights reserved...
