USER MANUAL -MCUSBBO-6

DOUBLE USB CHARGER

Specification of MCUSBBO-6 double USB charger

The MCUSBBO-6 charger is intended to charge devices like smartphones, MP3 players and other

electronic equipment. Before connecting the device, check compliance of the charger with

charging parameters of the given device.

Dane techniczne

Number of USB ports (type A)

Nominal input voltage

Nominal input current

Nominal output voltage

Nominal output current

Ingress protection degree

Warranty is granted for a period of 12 months of the date of purchase. The defective MCUSBBO-6

charger along with the proof of purchase should be sent to the manufacturer or to the seller. Warranty

does not include mechanical damages, defects resulting from unauthorised repairs and improper use

of the product.

Warranty period will be extended for the duration of the repair.

54,00

100-240V AC; 50/60Hz

0,25 A

5 V DC

3.1 A (

total value for the whole mechanism

IP 20

46,00

)

1 I 2

Table of Contents

Do you have a question about the MCUSBBO-6 and is the answer not in the manual?

Page 1 IP 20 Warranty conditions Warranty is granted for a period of 12 months of the date of purchase. The defective MCUSBBO-6 charger along with the proof of purchase should be sent to the manufacturer or to the seller. Warranty does not include mechanical damages, defects resulting from unauthorised repairs and improper use of the product.
Page 2 ASSEMBLY INSTRUCTIONS 1. Remove the adapter (2) of the charger by levering it with a knife or a flat screwdriver in the place of the recess (1) on the adapter. 2. Unscrew the screw (3) and pull out the adapter (4) together with the USB charger module (5). If necessary, you can detach the USB charger module from the adapter by pressing the movable catch on the module.
