Self-Retracting
Lifelines
Certified to:
CSA Z259.2.2-17
Product Specific Name
SRL-73303-60 / V845643060
SRL-73303-96 / V845643096
READ CAREFULLY
BEFORE USE
Canada:
SureWerx, 49 Schooner St.,
Coquitlam, BC V3K 0B3
Made in Germany
May 31, 2022
V845643060-V845643096 Manual
Advertisement
Subscribe to Our Youtube Channel
Related Manuals for Surewerx PeakWorks SRL-73303-60
Summary of Contents for Surewerx PeakWorks SRL-73303-60
- Page 1 Self-Retracting Lifelines Certified to: CSA Z259.2.2-17 Product Specific Name SRL-73303-60 / V845643060 SRL-73303-96 / V845643096 READ CAREFULLY BEFORE USE Canada: SureWerx, 49 Schooner St., May 31, 2022 Coquitlam, BC V3K 0B3 Made in Germany V845643060-V845643096 Manual...
- Page 2 INTRODUCTION This manual contains the Manufacturer’s Instructions as required by CSA Z259.2.2 It should be used as part of the fall protection training program required by law. All PeakWorks® products are designed and engineered to meet or exceed applicable CSA and ANSI standards along with labour ministry requirements. WARNING: All persons using this equipment must read and understand all the instructions and warnings contained in this manual.
- Page 3 RESCUE PLAN A rescue plan is an integral and critical part of any fall protection plan and system. It is the responsibility of the employer to have a rescue plan prepared by a competent person. All workers using any fall arrest system must have a rescue plan prior to using the system.
- Page 4 SRL CAPACITY PeakWorks SRLs are designed for use by a single person with a combined weight (clothing, tools, etc.) of no more than 310 lbs. Make sure all of the components in your system are rated to a capacity appropriate to your application.
- Page 5 FALL CLEARANCE Fall Clearance is the distance required to safely arrest the user’s fall. It is the distance from the anchorage to the ground. A Fall Clearance Calculation must be done anytime this or any other fall protection equipment is used. Step 1: Calculate Free Fall (FF) Step 2: Determine how much the connecting device deploys (DD) Step 3: Determine the stretch of the harness (Xh)
- Page 6 INSTRUCTIONS FOR USE—HAZARD AREA 1. A PeakWorks SRL device with recovery mechanism in accordance with CSA Z259.2.2-17 SRL-R is an automatic fall arrest system, part of a fall protection PPE with integrated fall restraint functions to serve as a fall arrest and recovery lifting device. In conjunction with a safety harness, this SRL device provides safety for persons carrying out work with a risk of falling (e.g., when moving in containers, vertical shafts, sewer systems).
- Page 7 13. A fall arrest block must be withdrawn from use if damaged, loaded by fall, or if its safe condition is doubtful. It may only be used further and removed from service if tested and released in writing by an expert from or trained by the manufacturer. *Check connector to ensure that the indicator has not been released.
- Page 8 FUNCTION DESCRIPTION FOR SELF-RETRACTING LIFELINES WITH RESCUE LIFTING DEVICE THROUGH CRANK MECHANISM Rescue Application: Required Operations: 1. Open the sealed Velcro lock; see Figure 1. 2. Unfold the crank handle; see Figure 1. 3. Pull out the locking pin with pear handle (see Figure 2), (Action 1), until the crank handle axis (Action 2) pops out audibly and visibly (Figure 3).
- Page 9 Ancrer au-dessus de l’anneau en D dorsal du harnais de l‘utilisateur. WARNING: This device shall be removed from service when the visual load indicator is deployed. SureWerx, 49 Schooner St., Lifeline shall not contact edges or surfaces during fall arrest. Anchor above user’s dorsal D-Ring.
- Page 10 PRE-USE INSPECTION If the Self-Retracting Lifeline is known to have arrested a fall, it must be removed from service immediately and returned for inspection and servicing. Before each use, check that the brake operates correctly that the SRL is securely anchored level with or above the user (NEVER below) that all components to be used in conjunction with this device are compatible and in good condition avoid anchoring the device in such a position that could result in a “pendulum/swing fall”...
- Page 11 INSPECTION This equipment and any other fall protection equipment used in conjunction with it should be inspected by the worker every time it is used. This equipment must be inspected annually by a competent person. A competent person is defined by OSHA: “By way of training and/or experience, a competent person is knowledgeable of applicable standards, is capable of identifying workplace hazards relating to the specific operation and has the authority to correct them”.
- Page 12 INSPECTION LOG Inspection Corrective Maintenance Inspection Date Results Action Performed Conducted By...
- Page 13 NOTES...
- Page 14 Canada: SureWerx, 49 Schooner St., Coquitlam, BC V3K 0B3 Made in Germany...
