- Page 1 Quick Start Guide Please read this Quick Start Guide carefully and keep it for future use. Model No.: MT-MS22101...
-
Page 2: Product Overview
Product Overview •Speaker Unit •USB-C Charging Cable •AUX IN Audio Cable •Baldric •Quick Start Guide, General Safety Warnings & Warranty Card 1. Power On/O Button, Mode Button, audio input selection Charging LED Indicator 2. Bluetooth Pairing, disconnect/connect, Mode LED Indicator 3. - Page 3 6. USB-C Charging Input 7. Reset Button 8. AUX IN Port 9. MIC IN Port (6.35mm) 10.USB IN (Audio) Port 11. SD Slot 12.Handle...
- Page 4 During pairing, activate Bluetooth on your phone and set it to search for new Monster device for pairing. When the speaker is connected successfully, connected tone will be heard and the blue LED will stop flashing and the LED indicator will...
-
Page 5: Volume Control
Volume Control Short press the Volume Button “+” or “-” to turn volume up or down. Music Play/Pause: In the music playback mode, press the MFB to play/pause music. Track forward: In the music playback mode, press and hold the Volume “+”... -
Page 6: Power Saving Setting
Audio source can be switched by press the “①” Button, the sequence is as follows: SD Mode AUX IN Mode Bluetooth Mode USB IN（AUDIO)Mode ± Microphone (Dynamic -60dB 3dB) When speaker is on, microphone is ready to use after plugging the jack into the MIC IN Port and switch on. -
Page 7: Led Indicator Guide
LED Indicator Guide Status Description Voice/Tone Power On LED Indicator: white LED stays On Opening Tone Power O LED Indicator: White LED lights o “Goodbye” Pairing Mode LED Indicator: blue LED flashes quickly “Discovering” Bluetooth “Your device is Mode LED Indicator: blue LED stays On Connected connected”... -
Page 8: Specifications
Specifications Input 5V, 2A Ingress Protection IPX7 Battery 11.1V, 4000mAh Speaker (Main base) Output 2 x 30W Speaker (Treble) Output 2 x 15W Bluetooth Bluetooth Operation Range USB/Micro SD Format Up to 64GB 399mm x 214mm x 160mm Dimensions (W x H x D) Net Weight 3.47kg For Techincal and Warranty Support:... - Page 9 Compliance and Responsible Disposal Packaging The packaging of your product has been selected from environmentally friendly materials and can usually be recycled. Please ensure these are disposed of correctly. Plastic wrapping can be a su ocation hazard for babies and young children, please ensure all packaging materials are out of reach and are safely disposed of.
- Page 10 Notes...
- Page 11 Notes...
- Page 12 1300 886 649 tempo.org/support Distributed by Tempo (Aust) Pty Ltd, PO Box 132, Frenchs Forest NSW 1640...
