Summary of Contents for MasterForce CUB401
- Page 1 80V BRUSHLESS CULTIVATOR 270-2454 2800194ME CUB401 OPERATOR’S MANUAL CAUTION To Reduce The Risk Of Injury, User Must Read And Understand Operator’s Manual. Save These Instructions For Future Reference.
-
Page 2: Table Of Contents
TABLE OF CONTENTS Safety Symbols ......................Page 2 Safety Instructions ...................... Page 3 Overview ........................Page 7 Assembly ........................Page 8 Operation ........................Page 10 Maintenance / Troubleshooting ................. Page 11 Notes ........................Page 12 Warranty ........................Page 14... -
Page 3: Safety Symbols
SAFETY SYMBOLS Some of the following symbols may be used on this product. Please study them and learn their meaning. Proper interpretation of these symbols will allow you to operate the product better and safer. Symbol Name Designation / Explanation Volts Voltage Amperes... -
Page 4: Safety Instructions
SAFETY INSTRUCTIONS The purpose of safety symbols is to attract our attention to possible dangers. The safety symbols, and the explanations with them, deserve your careful attention and understanding. The symbol warnings do not by themselves eliminate any danger. The instructions and warnings they give are no substitutes for proper accident prevention measures. - Page 5 SAFETY INSTRUCTIONS IMPORTANT SAFETY substantial footwear is recommended when working outdoors. Wear protective INSTRUCTIONS hair covering to contain long hair. • Do not force the machine — Use the R E A D A L L I N S T R U C T I O N S correct tool for your application.
- Page 6 • Never operate the equipment on a slope. the user, or damage to the product. • Use extreme caution when pulling the • Use only Masterforce Batteries: BAB726 machine towards you. and other BAB series. • When not in use, the machine should be stored indoors in dry, and high or locked-up •...
- Page 7 SAFETY INSTRUCTIONS parts, breakage of parts, mounting, and any responsible adult. other condition that may affect its operation. • Do not allow children under the age A guard or other part that is damaged should of 14 to operate this blower. Children be properly repaired or replaced by an who are 14 years of age and older must authorized service center unless otherwise...
-
Page 8: Overview
OVERVIEW SPECIFICATIONS Motor 80V Brushless No-load speed 170 ± 5% RPM Cultivating Path 10'' (25 cm) Cultivating Depth 5'' (13 cm) Weight (Without Battery) 29.3 lb. (13.3 kg) The recommended ambient temperature range: Item Temperature Cultivator storage temperature range 32°F (0°C) - 113°F (45°C) Cultivator operation temperature range 32°F (0°C) - 113°F (45°C) Battery charging temperature range... -
Page 9: Assembly
ASSEMBLY THE TINES UNPACKING The cultivator has four tines—two inner This product requires assembly. tines stamped B and C and two outer tines stamped A and D. For correct operation of the • Carefully remove the product and any unit, the tines must be installed in the correct accessories from the box. - Page 10 ASSEMBLY THE HANDLE THE BATTERY PACK 1. Align the holes on the upper handle with WARNING the holes on the lower handle. Insert the Follow these instruc- bolts, and tighten them using the wing nuts tions in order to avoid injury and to reduce the provided.
-
Page 11: Operation
OPERATION OPERATION TIPS START / STOP THE CULTIVATOR The cultivator can be used to break up gar- To start den soil and prepare a seedbed for planting. 1. Press the safety lock button. Plan ahead to leave enough room between 2. -
Page 12: Maintenance / Troubleshooting
MAINTENANCE CLEAN THE MACHINE STORE THE MACHINE • Clear the unwanted material out of the air vent with a vacuum cleaner. • Clean the machine before storage. • Do not spray the air vent or put the air vent • Make sure that the motor is not hot when in solvents. - Page 13 EXPLODED VIEW ITEM NO. PART NO. DESCRIPTION R0201200-00 Handle Knob Assembly R0201201-00 Wheel Shelf Assembly R0201202-00 PCBA R0201203-00 Small Hitch Pin R0201694-00 Shield R0201695-00 Wheel R0201696-00 Motor Engagement Box R0201207-00 Large Hitch Pin R0201208-00 Tine Assembly R0201209-00 Ring Pin R0201210-00 Gear Box Page 12...
-
Page 14: Notes
NOTES Page 13... -
Page 15: Warranty
WARRANTY 4-YEAR LIMITED WARRANTY This MASTERFORCE™ brand power tool carries our famous No Hassle 4-Year Limited Warranty to the original purchaser. If, during normal use, this MASTERFORCE™ power tool breaks or fails due to a defect in material or workmanship within four (4) years from the date of original purchase, simply bring the tool with the original sales receipt back to your nearest MENARDS ®... - Page 16 © 2019 Menard, Inc., Eau Claire, WI 54703 12/2019...
Need help?
Do you have a question about the CUB401 and is the answer not in the manual?
Questions and answers
what is the use of ring pins
Ring pins (referred to as hitch pins in the manual) are used to secure the tines onto the tine shaft of the MasterForce CUB401. They are inserted into holes to lock the tines in place during assembly.
This answer is automatically generated
@Stela Adam Thank you! However, I was referring to item 10 on page 12, which is called ``ring pin''. We received two of those; they are stiff and useless, which probably indicates a mistake.
