Summary of Contents for Energer ENB518HTL
- Page 1 SAFETY AND OPERATING MANUAL Original Instructions 200W MULTI-CUTTER ENB518HTL...
- Page 2 Read all safety warnings and all instructions before use. Failure to follow the warnings and instructions may result in electric shock, fire and/or serious injury. Save all warnings and instructions for future reference.
-
Page 3: General Safety Instructions
Prevent unintentional starting. Ensure the switch is in the off-position before connecting to power source and/or battery pack, picking up or carrying the tool. Carrying power tools with your finger on the switch or energising power tools that have the switch on invites accidents. 200W MULTI-CUTTER ENB518HTL... - Page 4 d) Remove any adjusting key or wrench before turning the power tool on. A wrench or a key left attached to a rotating part of the power tool may result in personal injury. e) Do not overreach. Keep proper footing and balance at all times. This enables better control of the power tool in unexpected situations.
-
Page 5: Special Safety Instructions
Your risk from these exposures varies, depending on how often you do this type of work. To reduce your exposure to these chemicals: work in a well-ventilated area, and work with approved safety equipment, such as those dust masks that are specially designed to filter out microscopic particles. 200W MULTI-CUTTER ENB518HTL... - Page 6 VIBRATION The European Physical Agents (Vibration) Directive has been brought in to help reduce hand arm vibration syndrome injuries to power tool users. The directive requires power tool manufacturers and suppliers to provide indicative vibration test results to enable users to make informed decisions as to the period of time a power tool can be used safely on a daily basis and the choice of tool.
- Page 7 Be sure the supply is the same as the voltage given on the rating plate. The tool is fitted with a two- core cable and plug. Always remove the mains plug from socket before carrying out any adjustment or servicing. 200W MULTI-CUTTER ENB518HTL...
- Page 8 SYMBOLS To reduce the risk of injury, user must read instruction manual Double insulation Warning Wear ear protection Wear eye protection Wear dust mask Wear safety gloves This product has been marked with a symbol relating to removing electric and electronic waste.
- Page 9 Components and controls 200W MULTI-CUTTER ENB518HTL...
- Page 10 1. Key storage 2. Variable speed control 3. Venting slots 4. On/Off switch 5. Sanding pad (PERFORATED) 6. Sanding sheet Flange 8. Hex key 9. HSS semicircle saw blade 10. End cut blade 11. Dust extraction access 12. Dust collection adapter (35mm) 13.
-
Page 11: Technical Data
Wear ear protection when sound pressure is over 80dB(A) ACCESSOIRES Hex key 5mm End cut blade 35mm Sanding pad (fit with sanding paper: 80x80mm) HSS semicircle saw blade 80mm 80grit sanding sheet(perforated) 180grit sanding sheet(perforated) 120grit sanding sheet(perforated) Dust collection adapter (32mm&35mm) Small flange 200W MULTI-CUTTER ENB518HTL... -
Page 12: Mounting Accessories
OPERATION INSTRUCTIONS NOTE: Before using the tool, read the instruction book carefully. Intended Use The power tool is intended for sawing and separating wooden materials, plastic, plaster, non-ferrous metals and fasteners (e.g. nails and clamps) as well as for working on soft wall tiles and for dry grinding of small surfaces. - Page 13 The variable speed control (2) can be used to set the optimum oscillating frequency according to the accessories used and the respective application. High oscillation frequency: Sanding, sawing, rasping and polishing stone and metal. Low oscillation frequency: Polishing varnishes. 200W MULTI-CUTTER ENB518HTL...
- Page 14 6. SANDING Typical application: wood, metal; small areas, especially corners, edges and places difficult to access. Select high oscillation frequency. Sand with a constant movement and light pressure. Heavy pressure does not increase the removal – the sanding sheet merely wears faster. 7.
-
Page 15: Working Hints For Your Tool
2002/96/CE. It will then be recycled or dismantled in order to reduce the impact on the environment. Electric and electronic equipment can be hazardous for the environment and for human health since they contain hazardous substances. For further information visit www. recyclemore.co.uk 200W MULTI-CUTTER ENB518HTL... - Page 16 UK PLUG REPLACEMENT The fuse in the main plug of your power tool should always be replaced with one of identical rating. Check the voltage given on your power tool matches the supply voltage. The power tool is supplied with a fitted plug, however if you should need to fit a new plug follows the instruction below.
- Page 17 Standards and technical specifications referred to EN 60745-1:2009 + A11:2010 EN 60745-2-4:2009 + A11: EN55014-1:2006+A1:2009+A2:2011 EN 55014-2:2015 EN 61000-3-2:2014 EN 61000-3-3:2013 Date: 20/01/2016 Signature: Name / title: Peter Harries / Quality Manager Powersmith (UK) LTD. Trade House , Mead Avenue ,BA22 8RT 200W MULTI-CUTTER ENB518HTL...
