Page 1 BELLE 870/10004/2 09/18 RPC 30 Operators Manual Operators Manual Manuel De L'Opérateur Manual del Operador Manual de Operação Handleiding Betjeningsvejledning Bedienungshandbuch Manuale Dell'Operatore Bruksanvisning • Spare Parts Book • Pièces Détachées Betjene Håndbok • Libro Despiece Käyttöohje • Lista de Peças •...
Page 2: Declaration Of Conformity
EC DECLARATION OF CONFORMITY / DECLARATION CE DE CONFORMITE / DECLARACIÓN DE CONFORMIDAD CE / DECLARAÇÃO CE DE CONFORMIDADE / EG-VERKLARING VAN OVEREENSTEMMING / EF OVERENSSTEMMELSESERKLÆRING We, Belle Group Sheen UK, Sheen, Nr. Buxton, Derbyshire, SK17 0EU, GB, hereby certify that if the product described within this certificate is bought from an authorised Belle Group dealer within the EEC, it conforms to the following EEC directives: 2006/42/CE (This directive replaces directive 98/37/EC), Electromagnetic Compatibility Directive 2004/108/CE (as amended by 89/336/EEC, 92/31/EEC &...
Page 3 EGKONFORMITÄTSERKLÄRUNG / DICHIARAZIONE CE DI CONFORMITÁ / EG-VERKLARING VAN OVEREENSTEMMING / EC SAMSVARSERKLÆRING / EY-YHDENMUKAISUUSILMOITUS / DEKLARACJA ZGODNOSCI Z PRZEPISAMI UE Wir, Belle Group Sheen UK, Sheen, Nr. Buxton, Derbyshire, SK17 0EU, GB, bestätige hiermit, dass, wenn das Produkt innerhalb dieser Bescheinigung ist von einem gekauft zugelassen Belle Group-Händler innerhalb der EWG, so entspricht sie den folgenden EG-Richtlinien: 2006/42/CE (Diese Richtlinie ersetzt die Richtlinie 98/37/EG), elektromagnetische Kompatibilität Richtlinie 2004/108/EG (geändert durch 89/336/EWG, 92/31/EWG und 93/68 EWG).
Page 4 / EÜ VASTAVUSDEKLARATSIOON / ATBILSTĪBAS DEKLARĀCIJA / ES ATITIKTIES DEKLARACIJA / AVT Reliability, Unit 2 Easter Court, Europa Boulevard, Warrington, Cheshire, WA5 7ZB, GB. Belle Group Sheen UK, Sheen, Nr Buxton, Derbyshire, SK17 0EU, GB AVT Reliability, Unit 2 Easter Court, Europa Boulevard, Warrington, Cheshire, WA5 7ZB, GB. Müra Tehniline faile hoitakse Ray Neilson kell Belle grupi peakontor aadress, mis on märgitud eespool.
Page 5 My, Belle Group Sheen UK, Sheen, Nr. Buxton, Derbyshire, SK 17 0EU, Velké Británie AVT Reliability, Unit 2 Easter Court, Europa Boulevard, Warrington, Cheshire, WA5 7ZB, Velká Británie. Belle Group Sheen UK, Sheen, Nr. Buxton, Derbyshire, SK17 0EU, GB, AVT Reliability, Unit 2 Easter Court, Europa Boulevard, Warrington, Cheshire, WA5 7ZB, GB. Belle Group Sheen UK, Sheen, Nr.
Page 6: Table Of Contents
KNOW how to safely use the unit’s controls and what you must do for safe maintenance. (NB Be sure that you know how to switch the ALWAYS wear or use the proper safety items required for your personal protection. If you have ANY QUESTIONS about the safe use or maintenance of this unit, ASK YOUR SUPERVISOR OR CONTACT: Altrad Belle (UK): Contents How To Use This Manual ..................................
Page 7: Machine Description
Machine Description 1. Throttle lever. 2. Recoil Starter Handle. 3. Fuel Tank. 4. Lifting Point. 5. Handle Release Catch. 6. Forward / Reverse Control Handle. 7. Main Handle. 8. Belt Guard. Technical Data Model RPC 30/40 RPC 30/50 A - Plate Width (mm) B - Height (mm) 1265 1265...
Page 8: General Safety
Health & Safety Vibration Some vibration from the compaction operation is transmitted through the handle to the operator’s hands. The Altrad Belle RPC range PPE (Personal Protective Equipment) Suitable PPE must be worn when using this equipment i.e. Safety Goggles, Gloves, Ear Defenders, Dust Mask and Steel Toe capped equipment’s moving parts.
Page 9: Reasons For Compaction
Reasons For Compaction lead to one or more problems occurring. 3. Materials with voids are more susceptible to water seepage, leading to erosion. Water ingress may also cause the soil to building foundations and normally leads to the structure requiring underpinning. Compaction increases the density of the material and therefore increases its load bearing capacity.
Page 10: Operating Instructions
Operating Instructions • Take the compactor to where it is required. Where it is necessary to use lifting equipment to position the compactor, make sure the lifting equipment has a WLL (Working or slings ONLY to the lifting point on the top of the compactor. •...
Page 11: Trouble Shooting Guide
Service & Maintenance The Altrad Belle ‘RPC’ range of Reversible Plate Compactors are designed to give many years of trouble free operation. It is, however, important that the simple regular maintenance listed in this section is carried out. It is recommended that an approved Altrad Belle void your warranty.
Page 12: Service & Maintenance
Service & Maintenance Every 8 First Month / Routine Maintenance 50 Hours Hours Hours Hours Hours Check Level Engine Oil Change Check Condition / Clean Air Filter Replace when necessary / Every 12 months Spark Plug Change Drive Belt Tension Oil / Fuel Type &...
Page 13: Warranty
2. Alterations, additions or repairs carried out by persons other than Altrad Belle or their recognised agents. 3. Transportation or shipment costs to and from Altrad Belle or their recognised agents, for repair or assessment against a warranty claim, on any machine.
