General Information
PLEASE READ THROUGH BEFORE BEGINNING ASSEMBLY.
IMPORTANT: Check boxes for Contents Listed
Check inside of parts as some parts are packaged
inside of others
In the event of missing, damaged or defective parts
please call our customer service dept. at 1-877-258-6020
When assembling components, place on a clean, flat
non-abrasive surface to avoid scratches
Tools Required
... Battery or Electric Drill
... Tape Measure
... Hammer or Rubber Mallet
... PVC, Super, or Crazy Glue
with #2 phillips bit
(recommended)
Melrose Trellis
11191
Model#
Part #
1
2" sq. x 74" Left Post
2
2" sq. x 74" Right Post
3
⅞ x 1½ x 35" Top/Bottom Cross Rail
4
⅞ x 1½ x 35" Center Cross Rail
5
⅞ x 1½ x 45" Bent Top
6
¼ x 1½ x 66" Vertical Slat
7
¼ x 1½ x 63" Vertical Slat
8
Hardware Bag
2" sq." Post Cap
⅞ x 1½" End Cap
1¼" Painted Screw
9
Trellis Ground Anchor Kit
16" Steel Ground Anchor (L-Shaped)
#8 - 1" Painted Self Tapping Screw
150 Birch Road
P.O. Box 122
Sheboygan Falls, WI 53085
Assembly Instructions
Description
(includes:)
(includes:)
1-877-258-6020
www.dura-trel.com
sales@dura-trel.com
Qty
1
1
1
5
1
2
2
1
2
2
6
1
2
4
1
Advertisement
Summary of Contents for Dura Trel Melrose Trellis 11191
- Page 1 Melrose Trellis 11191 Model# Assembly Instructions Part # Description 2" sq. x 74" Left Post 2" sq. x 74" Right Post ⅞ x 1½ x 35" Top/Bottom Cross Rail ⅞ x 1½ x 35" Center Cross Rail ⅞ x 1½ x 45" Bent Top ¼...
- Page 2 Warranty Statement 20 Year Guarantee Please call manufacturer direct with questions concerning missing or defective parts at Toll Free: 877-258-6020. Dura-trel, Inc. products are warranted to be free from manufacturing defects resulting in delaminating, peeling, flaking, corroding, cracking, crazing, or extreme amounts of fading or bleaching causing the PVC to change to its natural color for a period of 20 years from the date of purchase.
- Page 3 Lay out one right post (part 2). Starting at bottom, insert one bottom cross rail (part 3) and five center cross rails (part 4). Insert two 63" vertical slats (part 6) through outer holes of center cross rails and into bottom cross rail. Insert two 66" vertical slats (part 7) through inner holes of center cross rails and into bottom cross rail.
- Page 4 Insert bent top rail through left post (part 1), inserting center cross rails and bottom cross rail into left post. Using 1¼” kappet screws, screw together trellis. Be sure that all parts are fully inserted into posts before securing. Using PVC, super or crazy glue; glue post caps onto posts.
- Page 5 Melrose Trellis 11191 2" sq. x 74" MRT Left Post 1.00 2" sq. x 74" MRT Right Post 1.00 ⅞ x 1½ x 35" MR Top/Bottom 1.00 ⅞ x 1½ x 35" MR Center Rail 5.00 ⅞ x 1½ x 45" MRT Bent Top 1.00 ¼...
