CareCo DL14036 Quick Start Manual

Instructions

A
I
USB
C
II
G
III
H
4cm
IV
V
Note:
1. The charging port must be covered when not in use to prevent water ingress.
Water damage is not covered by the warranty.
2. The power is automatically turned off when charging. Reboot after a full charge.
www.careco.co.uk
User Set-Up Guide
DL14036 - Vivo Auto Foaming Soap Dispenser
B
Figure I
A. Switching machine keys and mode keys
B. Indicators
Figure II
C. USB charge port
E
D. Inlet port
E. Sensor and nozzle
F
F. Bottle screw
D
Figure III
G. Power button
Press the power button. The red light will turn on.
To adjust dispensing volume, short press the blue light for one
flash (two-step switching adjustment).
To turn off, long press the purple light until it flashes three times.
Figure IV
H. Sensor area (approximately 4cm)
Move hand downwards once foam begins dispensing. The foam
will not stick to the black induction zone (shaded area on Figure III).
Figure V
I. USB charging port
Unplug the USB port cover. Insert the USB charging cable. The red
light will light up when charging. A blue light displays when fully
charged. Low battery is indicated by the red light.
CareCo, Hubert Road, Brentwood, Essex, CM14 4JE
