Scotsman ND550 Service Manual

INTRODUCTION
To the owner or user: The service manual you are
reading is intended to provide you, and the
maintenance or service technician with the
information needed to install, start up, clean,
maintain, and service this ice maker-dispenser.
The ND550 is a combination nugget ice maker and
countertop dispenser, with the option of wall
mounting. A water station may be added, if desired.
The ND550 ice making section is equipped with
the following features: electronic controls for bin

TABLE OF CONTENTS

For the Installer
Specifications . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2
Environmental Limitations . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3
Wall Mount Kit . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5
Glass Filler Kit . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6
Soda Valve Kit . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
For the Plumber . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8
For the Electrician
Final Check List . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10
Start Up . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11
Component Description
Electrical Sequence . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13
Operation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16
Maintenance and Cleaning . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 19
Service Diagnosis
Removal and Replacement
Water Reservoir
Bin Controls
Breaker and Bearing . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 28
Auger . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 29
Water Seal
Evaporator . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 31
Gearmotor . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 32
Electronic Tester . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 34
Parts Lists and Wiring Diagrams are printed on yellow paper in the center of this manual.
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 22
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 27
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 27
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 30
December, 1988
level and low water; thermostatic expansion valve;
front service for most components; and R502
refrigerant. The ice dispensing section is a
seamless plastic storage bin, with a stainless steel
ice agitator at the bottom to sweep the ice into the
dispensing chute.
Page 1
ND550
