Titan
Quick installation guide
GAMING PC CASE
www.genesis-zone.com
800
EN
PL
V|20171130TITAN800

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Titan 800 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for Genesys Titan 800

  • Page 1 Titan Quick installation guide GAMING PC CASE www.genesis-zone.com V|20171130TITAN800...
  • Page 2: Specification

    Specification Material SPCC Steel, ABS Motherboard Support ATX, micro- ATX, mini-ITX 5,25" ODD Bays 3,5" HDD Bays 2,5" SSD Bays I/O Connctors USB 3.0 x2, USB 2.0 x2, HD Audio Jack x2 Expansion Slots Cooling Suport max. 4 fans Front 120mm x2 (2x LED installed) Rear 120mm x1 (1x LED installed)
  • Page 3: Installation

    PACKAGE CONTENTS 8x - Screw for 3x - Screw spacer 6x - Screw for PSU fan install for Motherboard 4x - Left-side 4x - Right-side 13x - Motherboard HDD Screw HDD Screw mounting screw 1x - PC case 1x - Speaker 1x - Installation guide 4x - Cable tie Installation...
  • Page 4 Photo 4-6. SSD Installation: Put SSD in designated area, then x it by screws. Side-cover is necessary to be removed. Photo 7-10. HDD Installation: HDD designated area instalation. Fix 2 supporting screws on left side of HDD. Install HDD in HDD tray. Fix right HDD side by screws.
  • Page 5 SPECYFIKACJA Materiał Stal SPCC, ABS Wspierane płyty główne ATX, micro- ATX, mini-ITX Zatoki ODD 5,25" Zatoki HDD 3,5" Zatoki SSD 2,5" Gniazda We/Wy. USB 3.0 x2, USB 2.0 x2, HD Audio Jack x2 Gniazda rozszerzeń Wsparcie chłodzenia max. 4 wentylatory Przód 120mm x2 (2x LED w zestawie) Tył...
  • Page 6 zawartość 8x - Śrubki do 3x - Dystanse do 6x - Śrubki do instalacji wentylatorów płyt głównych zasilacza 4x - Śrubki do dysku 4x - Śrubki do dysku 13x - Śrubki do płyt HDD lewa strona HDD prawa strona głównych 1x - Obudowa 1x - Głośnik 1x - Instrukcja obsługi...
  • Page 7 Zdjęcie 4-6. Instalacja dysku SSD: Zamontuj dysk SSD w wyznaczonym do tego miejscu, przykręć do obudowy za pomocą śrubek uprzednio demontując panel boczny. Zdjęcie 7-10. Instalacja dysku HDD: Wyznaczone miejsce na dyski HDD. Przykręć dwie śrubki wspierające z lewej strony dysku. Wsuń dysk do zatoki HDD a następnie przymocuj do zatoki za pomocą...
  • Page 8: Product & Support Information

    www.genesis-zone.com product & support information | please scan qrcode | © GENESIS. All rights reserved. GENESIS name and logo, and all related product and service names, design marks and slogans are the trademarks or registered trademarks of GENESIS. All other product and service marks contained herein are the trademarks of their respective owners.
