INTRODUCTION
To the owner or user: The service manual you
are reading is intended to provide you, and the
maintenance or service technician, with the
information needed to install, start up, clean,
maintain, and service this ice system.
Installation
Specifications . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2
Location . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4
For the Plumber . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6
For the Electrician . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
Final Check List . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9
Component Description . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10
Electrical Sequence . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14
Maintenance and Cleaning . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16
Reservoir and Bin Controls . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 24
Bearing and Breaker . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 25
Auger . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 26
Gearmotor . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 29
Fan Motor Assembly . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 30
Electronic Tester . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 31
Parts lists and wiring diagrams are in the center of this manual, printed on yellow paper.
TABLE OF CONTENTS
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 20
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 27
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 28
December, 1988
The FM800 is a modular ice system that fits a
variety of Scotsman ice storage bins.
It features: front service for the freezer,
gearmotor, control box, water reservoir, and
bin control; an electronic circuit for monitoring
ice and water level; a thermostatic expansion
valve; and R-502 as the refrigerant.
Page 1
FM800
Advertisement
Table of Contents
Related Manuals for Scotsman FM800
Summary of Contents for Scotsman FM800
-
Page 1: Table Of Contents
Electronic Tester ......... 31 Parts lists and wiring diagrams are in the center of this manual, printed on yellow paper. The FM800 is a modular ice system that fits a variety of Scotsman ice storage bins. -
Page 2: For The Installer
BACK VIEW: AIR COOLED WATER INLET 3/8" FLARE DRAIN 3/4" FPT The FM800 is designed to fit the following Scotsman storage bins: B590 and extensions (with bin top KBT18) BH800 using bin top KBT15 (one unit). BH800 (two units, no bin top required). - Page 3 Scotsman. Scotsman reserves the right to make design changes and/or improvements at any time. Specifications and design are subject to change without notice.
-
Page 4: Location
FM800 FOR THE INSTALLER Typical Storage Bin with Extension and Bin Top Location: After uncrating and inspection, the unit is ready for installation. It is important that the machine be installed in a location where it has enough space around it to be accessible for service, and minimum of 6"... -
Page 5: Two Units On One Bin
FM800 FOR THE INSTALLER: Location DO NOT STACK ANYTHING IN FRONT OF THE MACHINE(S) TWO UNITS ON ONE BIN ALLOW ROOM FOR AIR CIRCULATION AND SERVICE ACCESS December, 1988 Page 5... -
Page 6: For The Plumber
FM800 FOR THE PLUMBER CONFORM TO ALL APPLICABLE CODES Water Inlet Air Cooled Models: The recommended water supply is clean, cold water. Use 3/8" O.D. copper tubing, connect to the 3/8" male flare at the back of the cabinet. Install a hand valve near the machine to control the water supply. -
Page 7: For The Electrician
Voltage variation must remain within design limitations, even under starting conditions. All external wiring must conform to national, state, and local electrical codes. The use of a licensed electrician is required to perform the electrical installation. December, 1988 Page 7 FM800 POWER SUPPLY... -
Page 8: Final Check List
FM800 FOR THE INSTALLER 1. Is the ice system installed indoors in a location where the air and water temperatures are controlled, and where they do not exceed the design limitations? 2. Is there an electrical service disconnect within sight of the installed machine? Has the... -
Page 9: Start Up
9. Fill out the manufacturers registration card, and mail it to the Scotsman Factory. 10. Fill out the field quality audit form, and mail it to the Scotsman factory. December, 1988... -
Page 10: Component Description
450 psig. Reset Switch: A manual reset switch, used for restarting the ice machine should the ice discharge chute overfill with ice; the low pressure cut out switch open; or the high pressure cut out switch open. - Page 11 TRANSFORMER CIRCUIT BOARD Low Pressure Cut Out Switch: A manual reset control that shuts off the ice machine when the low side pressure drops below a preset point, 0-4 psig. Potential Relay: The compressor start relay. On/Off Switch: Manual control for the machine.
- Page 12 FM800 COMPONENT DESCRIPTION Evaporator: A refrigerated vertical tube filled with water and containing a water seal and auger. Auger: A solid stainless steel double spiral auger, it pushes the ice crystals up to the top of the evaporator. Water Seal: A two part "face" seal, the top half...
-
Page 13: Electrical Sequence
After it recloses the reset switch on the circuit board must be manually reset. The master switch is the manual control for the complete machine, but it is not a service disconnect. December, 1988 Page 13 FM800... -
Page 14: Operation
FM800 OPERATION: Water RESERVOIR STRAINER DRAIN Water enters the machine through the 3/8" male flare at the rear of the cabinet, goes to a strainer and then to the water reservoir which it enters through the float valve. The water then goes out the bottom of the reservoir tank to the bottom of the evaporator. - Page 15 After the evaporator, the refrigerant, now a low pressure vapor, goes through the suction line back to compressor, where the cycle is repeated. Refrigeration Schematic DISCHARGE LINE THERMOSTATIC EXPANSION VALVE COMPRESSOR December, 1988 Page 15 FM800 SUCTION LINE EVAPORATOR GEAR MOTOR...
-
Page 16: Maintenance And Cleaning
FM800 MAINTENANCE AND CLEANING ////////////////////////////////////////////////////////////////////////////////////////////////////////////////////////////////////////////////////////// A Scotsman Ice System represents a sizable investment of time and money in any company’s business. In order to receive the best return for that investment, it MUST receive periodic maintenance. It is the USER’S RESPONSIBILITY to see that the unit is properly maintained. It is always preferable, and less costly in the long run, to avoid possible down time by keeping it clean;... - Page 17 2. The ice machine senses water level by a probe located in the water reservoir. At least twice a year, the probe should be removed from the reservoir, and the tip wiped clean of mineral buildup.
- Page 18 FM800 MAINTENANCE: Air Cooled ///////////////////////////WARNING///////////////////////////// Disconnect electrical power before beginning. ////////////////////////////////////////////////////////////////////////// 5. Clean the air cooled condenser. The air flow on this model is from front to back, so the inside of the machine will have to be available to clean the air cooled condenser.
- Page 19 Clean the auger and evaporator as required. DO NOT HONE THE EVAPORATOR. 8. Replace the water seal. 9. Reverse to reassemble. December, 1988 Page 19 FM800 ALLEN SCREWS BREAKER & BEARING & AUGER ASSEMBLY...
-
Page 20: Service Diagnosis
FM800 SERVICE DIAGNOSIS: Condition - No Ice Being Produced A. Check: Voltage to the unit, restore it if there is none. Compare to the nameplate. B. Check: The master switch, switch ON if off. C. Check: The 3 reset switches, (circuit board, high and low pressure): depress and release each switch. - Page 21 If the bin empty light is still OFF, check the circuit board. 1. Unplug “opto trans” and “LED” connectors from the circuit board. 2. Plug “opto trans” and “LED” connectors from the Scotsman Electronic Control Testor Model NM1 into the circiut board.
- Page 22 FM800 SERVICE DIAGNOSIS: Condition - No Ice Produced STATUS: GEARMOTOR OPERATES, COMPRESSOR DOES NOT A. Check the compressor relay. The relay is on the circuit board, if it does not supply power to the contactor coil, the compressor will not run.
- Page 23 The compressor should pull down to 25 inches of vacuum and hold there for three to five minutes. December, 1988 Page 23 FM800...
-
Page 24: Removal And Replacement: Water Reservoir & Bin Controls
FM800 REMOVAL AND REPLACEMENT: Water Reservoir & Bin Controls WATER RESERVOIR 1. Shut off the water supply to the icemaker. 2. Remove front panel and reservoir cover. 3. To remove float only, pry the mounting flanges apart enough to lift one float pivot pin out of the flange hole, and pull float up and out of the reservoir. -
Page 25: Bearing And Breaker
7. Reverse to reassemble: specific tools and materials are required to install properly. a. Add food grade grease such as Scotsman part number 19-0569-01 to the seal area before installing on the auger. b. Check the seal to shaft areas for cuts, or rough spots: none are permitted. -
Page 26: Auger
Scrub the auger with ice machine cleaner and hot water. ///////////////////////////WARNING////////////////////////////// Ice machine cleaner is an acid. Handle it with extreme care, keep out of the reach of children. ////////////////////////////////////////////////////////////////////////// 2. -
Page 27: Water Seal
REPLACING THE WATER SEAL 4. Place a small bead of food grade silastic WATER SEAL sealant (such as 732 RTV or Scotsman part number 19-0529-01) on the area of the auger RETAINING where the water seal is to be mounted. -
Page 28: Evaporator
FM800 REMOVAL AND REPLACEMENT: Evaporator ///////////////////////////////////////////////////////////////////////////WARNING////////////////////////////// ////////////////////////////////// Disconnect electrical power before begining removal procedures. ///////////////////////////////////////////////////////////////////////////////////////////////////////////////////////////////////////////////////////////// To Replace the Evaporator: (Assuming all the steps for removal of the thrust bearing, breaker, auger, and water seal have been performed.) 1. Discharge the refrigerant from the ice maker. -
Page 29: Gearmotor
WATER SHED SEAL COVER & OUTPUT GEAR ASSEMBLY GEAR CASE December, 1988 Page 29 FM800 CENTRIFUGAL SWITCH AUGER DRIVE MOTOR ROTOR BEARING SEAL D) After replacing parts as required, (if any) reassemble the gearcase. The... -
Page 30: Fan Motor Assembly
If the Bin Empty light does not come ON, the circuit board should be replace. PHOTO TRANS LIGHT GOES SWITCH TO “BIN EMPTY” December, 1988 Page 31 FM800 LIGHT GOES LIGHT GOES OFF... -
Page 31: Electronic Tester
CIRCUIT BOARD TESTING Water Level 1. Unplug “water sen” connector from control board. 2. Plug “water sen” connector from Scotsman tester into circuit board. a. Move “water” switch on tester to No Water position. The No Water light on the circuit board should go ON.
