CAUTION
This mini bike was
shipped without engine
oil. Always fill with the
correct amount and
grade of engine oil as
POWERSPORTS
listed in the owner's
manual.
ASSEMBLY/PRE-RIDE
INSPECTION INSTRUCTIONS
RB100-PR
RB100
For questions about these Assembly Instructions, call
Coleman Powersports toll free 888-405-8725
WARNING
Never attempt to start this Mini Bike without reading and
understanding the Owner's/ Operator's manual. The Owner's/
Operator's manual provides information on safety, parts,
functions, pre-ride inspection, starting and maintenance.
111020

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the RB100-PR and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for Coleman RB100-PR

  • Page 1 INSPECTION INSTRUCTIONS RB100-PR RB100 For questions about these Assembly Instructions, call Coleman Powersports toll free 888-405-8725 WARNING Never attempt to start this Mini Bike without reading and understanding the Owner’s/ Operator’s manual. The Owner’s/ Operator’s manual provides information on safety, parts, functions, pre-ride inspection, starting and maintenance.
  • Page 2 PARTS M10 x 155 steering bolt Tool Kit M10 lock nut Front Fork Assembly Cable Ties M8 x 15 bolts Front Fender M6 x 15 bolts Front wheel M6 rubber washers M12 x 212 axle bolt M12 lock nut M12 x 68 wheel spacers M6 x 15 bolts Front panel...
  • Page 3 Tools Needed M10 steeriing bolt M10 lock nut 13mm 17mm 1. Install front Fork by inserting the M10 steering bolt through the top bracket of the forks, steering neck and bottom bracket of forks. Secure with M10 lock nut Note: Do not over tighten lock nut.

  • Page 4: Front Fender Installation

    FRONT FENDER INSTALLATION Tools Needed M6 x 15 bolts 5mm Allen Wrench M6 rubber Long M6 x 15 bolt M6 Rubber Washer...

  • Page 5: Front Wheel Installation

    FRONT WHEEL INSTALLATION Tools Needed M12 x 68 Spacers M12 lock nut 17mm 14mm tread pattern when looking from the top. Insert M12 axle bolt through the fork assembly in the following order: fork, M12 spacer, wheel, M12 spacer, fork snug Note: Do not over tighten lock nut.

  • Page 6: Handlebar Installation

    HANDLEBAR INSTALLATION ANDL BA NSTALLAT N M8 lock M8 x 44 Clamps Bolts Place handlebars on top of fork assembly with 2 of the Bottom clamps between the Clamps handlebars and top  of forks. Handlebars Top Clamps M8 x 44 Bolts 2.
  • Page 7 FRONT PLATE INSTALLATION FRONT PLATE NSTALL Tools Needed M6 x 15 bolts M6 rubber washers 5mm Allen Wrench M6 x 15 bolt M6 Rubber Washer...
  • Page 8 SECURE WIRES AND CABLES Cable cable Cable CLUTCH COVER INSTALL M8 x 15 bolts M8 x 15 Axle bolt...

  • Page 9: Oil And Fuel

    OIL AND FUEL Engine Oil...

  • Page 10: Tire Pressure

    TIRE PRESSURE using cinch nut (3)

  • Page 11: Brake Adjustment

    BRAKE ADJUSTMENT bolts by loosening nut (5) and pulling cable (6) tighter. Once tighened make sure to re tighten nut (5)

  • Page 12: Throttle Adjustment

    THROTTLE ADJUSTMENT...

  • Page 13: Starting Engine

    STARTING ENGINE forward...
  • Page 15 WARNING NEVER ATTEMPT TO START THIS MINI BIKE WITHOUT READING AND UNDERSTANDING THE OWNER’S/ OPERATOR’S MANUAL. THE OWNER’S/ OPERATOR’S MANUAL PROVIDES INFORMATION ON SAFETY, PARTS, FUNCTIONS, PRE-RIDE INSPECTION, STARTING AND MAINTENANCE POWERSPORTS (888) 405-8725 1775 E. University Dr., Tempe, AZ 85281 www.colemanpowersportsusa.com www.facebook.com/colemanpowersportusa.com www.instagram.com/colemanpowersports_usa...
