- Page 1 OPERATOR’S MANUAL Model 61204 50 TON AIR HYDRAULIC TRUCK JACK PROFESSIONAL HYDRAULIC JACKS 1531 W. Mohawk Drive Phone 715-453-9602 Customer Service 800-995-2250 Tomahawk, WI 54487 Fax 715-453-6020 www.projacks.com...
- Page 2 Specifications Lift Saddle Overall Overall Overall Range Stroke Adapter Ext. Length Width Height Weight Min.11-1/2” 6” 1-3/4”,2-1/2”, 25” 14-1/4” 55” 165 lbs Max. 17-1/2” 4”,3/4” You will need the manual for the safety warnings and precautions, assembly instructions, operating and maintenance procedures, parts list and diagram. Keep your invoice with this manual. Write the invoice number on the inside of the front cover.
- Page 3 Operation 1.With the air compressor hose properly hooked up to the air valve assembly, the jack is ready to be used. Test the jack before attempting to lift a vehicle. 2.Remove the air valve assembly from the handle, and squeeze the lever to raise the piston by locking the lock lever in place;...
- Page 5 Parts List Item Description Part Item Description Part No Wheel shaft 120011 6.14 Spring washer 120614 Washer 120012 6.15 Lower cover 120615 Wheel shaft 120013 Packing washer 120071 Snap ring 120014 Muffler cover 120072 Piston rod assembly 120020 O-ring 120073 Piston rod 120021 Valve rod...
- Page 6 Spring pin 120045 12.1 Adapter A 120121 O-ring 120046 12.2 Adapter B 120122 Washer 120048 12.3 Adapter C 120123 4.10 Packing 120049 12.4 Adapter D 120124 4.11 Snap ring 120410 12.5 Holder adapter ass’y 120125 Handle assembly 120411 12.6 U-bolt 120126 5.1.1 Upper handle...
