Summary of Contents for Savi STREAM.ONE
- Page 1 USER GUIDE STREAM.ONE www.hellosavi.com...
-
Page 2: Table Of Contents
4.2.2. Mac LAN setup ............................9 4.2.3. IP address and channel settings ......................10 5. Using with SAVI ............................... 11 6. Setting up a STREAM.One ............................12 6.1. Connections ..............................12 6.2. Logging into the Web UI ..........................12 6.3. Web UI Overview .............................. 13 6.3.1. -
Page 3: About This Guide
PRODUCT DESCRIPTION The STREAM.One comes in either the 4K or 2K editions. The 4K edition provides input support of up to 2160P60 resolutions and HDCP 1.3 while the 2K edition provides input support of up to 1080P60 resolutions and HDCP 1.3. -
Page 4: Parts List
Model Number Description 1 x SSE-02 STREAM.One Encoder Included AC to DC Power Adapter Unbalanced Stereo Phoenix Connector (3-pin) Chassis Mount Ears Optional Accessories 1 x SSC-01 STREAM.One Rack Mount Kit Page 3 hellosavi.com © 2023 SAVI Controls Rev 06/13/23... -
Page 5: Physical Layout
D. HDMI Loop-Output LED Indicator B. HDMI Input LED Indicator E. HDMI Loop-Output With Captive Screw C. HDMI Input With Captive Screw F. 12V DC Power Input G. Unbalanced 2 Channel Audio Output (Phoenix Connector) Page 4 hellosavi.com © 2023 SAVI Controls Rev 06/13/23... -
Page 6: Front Panel Button Shortcuts
FRONT PANEL BUTTON SHORTCUTS The STREAM.One offers a handful of shortcuts for performing basic functions. Each of these utilize the physical buttons on the front of the device. Except for Factory reset, all shortcuts are performed while the STREAM.One is powered on. -
Page 7: Getting Started
VLAN configuration. Check the current IP address of your STREAM.One by pressing the Menu button on the front of the device once. You may need to set your computer to be on the same subnet of the device in order to connect to it. While the interface and steps on achieving this will be different for each Operating System, they all require that you set the ipv4 settings of your LAN adapter. - Page 8 Option 2: Use the search window and type “Settings”. Select Network & internet from the list on the left-hand side. Select Ethernet. Once you are in the Ethernet properties, click Edit next to IP assignment. Page 7 hellosavi.com © 2023 SAVI Controls Rev 06/13/23...
- Page 9 When the Edit IP settings window appears, change the dropdown to Manual and enable IPv4. Enter an IP on the same subnet as the STREAM.One as well as the subnet itself. A gateway address is optional. IP information in images are examples.
-
Page 10: Mac Lan Setup
From the top menu bar, you can either click on the network symbol or click on the Apple icon in the upper left, and the select system preferences: Then select Network: Select the appropriate network adapter from the list in the left pane, and then set the correct IP subnet parameters. Page 9 hellosavi.com © 2023 SAVI Controls Rev 06/13/23... -
Page 11: Ip Address And Channel Settings
A network switch that supports PoE specification 802.3af is acceptable. However, please carefully review the full power budget capacity of the switch to make sure it can handle the number of STREAM.One units that you will populate the switch with. -
Page 12: Using With Savi
Before getting into the full User Interface, it is important to note that very little configuration is needed when using the STREAM.One with SAVI. Setting a static IP address is the only setup required on the STREAM.Ones before adding them to your project with Creator. We reccomend setting all units to consecutive IP addresses to make use of Creator’s Add Multiple feature. -
Page 13: Setting Up A Stream.one
Network: The STREAM.One supports standard category RJ45 connectivity. It is recommended to use CAT6a cabling to ensure best performance. Video: The STREAM.One accepts HDMI 1.3 video formats up to 1080P60 on 2K units and 2160P60 on 4K units. Audio Transmitter: The STREAM.One de-embeds the audio present on the HDMI. The included Phoenix connector may be used to connect this audio to a DSP or Amplifier. -
Page 14: Web Ui Overview
• Red = Stop, no video or audio streaming, splashscreen displayed • Splashcreen Active • Grey = no splashscreen displays • Green = splashscreen displayed C. Equipment Status: Reports main IC operating temperature, and runtime since last power cycle. Page 13 hellosavi.com © 2023 SAVI Controls Rev 06/13/23... -
Page 15: Transport Controls
*On 2K devices, there is only one video stream so it is named Video Stream. However, on the 4K device there are two video streams so they are named Main Stream and Second Stream respectively. Page 14 hellosavi.com © 2023 SAVI Controls Rev 06/13/23... -
Page 16: Encoder
• H.264 Level • Baseline: Lowest encoding, lowest processing power required • Main: Higher quality • High: HD quality • H.265 Level* • Main: High quality *Only available on the 4K edition. Page 15 hellosavi.com © 2023 SAVI Controls Rev 06/13/23... - Page 17 • Main Stream (H.265) RTSP Multicast: Full RTSP stream address. Disabled by default. • Second Stream (H.264) RTSP Multicast: Full RTSP stream address. Disabled by default. • Audio Only Multicast: Full RTP audio only stream address. Disabled by default Page 16 hellosavi.com © 2023 SAVI Controls Rev 06/13/23...
- Page 18 • RTSP Unicast: Full RTSP stream address. Disabled by default. • RTSP Multicast: Full RTSP stream address. Disabled by default. • Audio Only Multicast: Full RTP audio only stream address. Disabled by default Page 17 hellosavi.com © 2023 SAVI Controls Rev 06/13/23...
- Page 19 • Select Broadcast Channel: Range 0 to 999, impacts Main and Audio addresses • For simplicity, the STREAM.One encoder provides intuitive ‘channel’ selections, making it easy to set many encoders quickly. The ‘channel’ number translates to a specific IP address for the Main Video/ Audio Transport Stream (TS), and a different specific IP address for the Audio Only RTP/SDP PCM stream.
-
Page 20: Network
• Username: Select User or Admin • Old Password: The old password is required when changing the password • New Password: Enter new password • Confirm Password: Confirm new password Ensure you SAVE your settings. Page 19 hellosavi.com © 2023 SAVI Controls Rev 06/13/23... -
Page 21: System
• Factory Reset: Reset to Factory defaults: • Firmware Update: Select and upload firmware • DHCP addressing file (.bin only). • Encoding on • Firmware Version: Current firmware version. • Clear splashscreen file Page 20 hellosavi.com © 2023 SAVI Controls Rev 06/13/23... -
Page 22: Edid
This block of code is the EDID table. This data will change depending on which selection is chosen from the EDID Selection list. EDID Details This scrollable window displays a detailed collection of information about the EDID. *Only available on the 4K edition. Page 21 hellosavi.com © 2023 SAVI Controls Rev 06/13/23... -
Page 23: Image Capture
• User Label: The name of the device. • Channel: The assigned channel of the device. • MAC Address: The physical identifier of the device. • Product: The edition of the device (2K or 4K). Page 22 hellosavi.com © 2023 SAVI Controls Rev 06/13/23... -
Page 24: Diagnostics
• HDMI loop out status • Product temperature • Product total run hours • EDID detail • Device Discovery of all encoders on network/ subnet • Firmware version • Serial number • User label Page 23 hellosavi.com © 2023 SAVI Controls Rev 06/13/23... -
Page 25: Application Programming Interface (Api)
While most users will utilize the SAVI Stream.One within a SAVI System, the following API commands are available via TCP Client to be used outside of a SAVI system. Access is achieved using the device’s IP address and port number 24. Telnet access is available logging in with device IP address and port 25. -
Page 26: Version 1.10.10
Get encoder resolution *SETTSMULTICAST_ Set TS Multicast Enable on/off TION! [xxx]! xxx=ON xxx=OFF *GETENCODER- Get encoder h264 level *SETRTSPMULTICAST_ Set RTSP Multicast Enable on/off H264LEVEL! [xxx]! xxx=ON xxx=OFF *GETENCODERGOP! Get encoder gop Page 25 hellosavi.com © 2023 SAVI Controls Rev 06/13/23... - Page 27 Set front pane menu button lock [xxx]! on/off xxx=ON xxx=OFF Set input mute xxx = ON xxx = *SETSIGNALMUTE_[xxx]! *REBOOT! Set reboot the device *SETFACTORYDEFAULT! Set reset the device *HELP! Show all Get/Set Commands Page 26 hellosavi.com © 2023 SAVI Controls Rev 06/13/23...
