  • Page 1 2017 TOMMY BAHAMA OWNER’S MANUAL...
  • Page 2 If and when new materials and production techniques are developed that can improve the quality of its product, or material substitutions are necessary due to availability, Airstream reserves the right to make such changes.

  • Page 3: Table Of Contents

    TABLE OF CONTENTS INTRODUCTION � � � � � � � � � � � � � � 1-1 SPRINTER VAN � � � � � � � � � � � � � � 7-1 SAFETY � � � � � � � � � � � � � � � � � 2-1 IMPORTANT SPRINTER INFORMATION .
  • Page 4 NOTES 2017 Tommy Bahama TC...

  • Page 5: Introduction

    RA-400 Patcher for UD Section 1 INTRODUCTION The Owner’s Manual for your new Airstream Tommy We have provided many important safety messages Bahama Touring Coach is designed to respond to in this manual. Always read and obey all safety the most frequent inquiries regarding the operation, messages.
  • Page 6 Introduction NOTES 2017 Tommy Bahama TC...

  • Page 7: Safety

    RA-400 Patcher for UD Section 2 SAFETY SAFETY � � � � � � � � � � � � � � � � � � � 2-1 Carbon Monoxide Alarm � � � � � � � � � � 2-4 This Carbon Monoxide SAFETY PRECAUTIONS �...

  • Page 8: Safety Precautions

    Safety Safety Precautions Generator Safety Do not operate the generator in an enclosed building or Many things can be construed as safety related, but in a partly enclosed area, such as a garage� Be sure to the most important is your common sense� If you are follow all instructions and warnings in this manual and careless with matches, cigarettes, flammable material, the generator manufacturer’s manual�...

  • Page 9: Alarms And Detectors

    Amounts released recreational vehicle� In addition to causing damage decrease over time� to your recreational vehicle, tobacco smoke releases Your Airstream touring coach was manufactured using formaldehyde and other toxic chemicals� low formaldehyde-emitting (LFE) wood products, Medical Advice the use of which is typical in the recreation vehicle industry�...

  • Page 10: Smoke Alarm

    Safety Smoke Alarm This Carbon Monoxide Alarm Is Not • Designed to detect smoke, fire, or any gas other than A smoke detector is provided with your touring coach� carbon monoxide� A manual pertaining to the detector is included in the paperwork given to you at the dealership�...

  • Page 11: What Is Carbon Monoxide

    Safety What Is Carbon Monoxide Symptoms of Carbon Monoxide Poisoning Carbon Monoxide (CO) is a highly poisonous gas that The following symptoms are related to CO is released when fuels are burned� It is invisible, has POISONING: no smell, and is therefore very difficult to detect with •...

  • Page 12: Regular Maintenance

    Safety Regular Maintenance Basic Safety Information The units have been designed to be as maintenance- 1� Never sleep in the vehicle with the generator running free as possible, but there are a few simple things without ensuring the carbon monoxide detector is you must do to keep them working properly�...

  • Page 13: Liquid Propane Gas (Lpg) Detector

    Safety Liquid Propane Gas (LPG) Detector WARNING Carbon Monoxide is poisonous and can cause confusion, unconsciousness, and death. Follow all instructions, cautions, and warnings in this section and the generator operator’s manual. NOTE The generator is located under the touring coach in front of the spare tire.

  • Page 14: Detector Test

    Safety Basic Safety Information Detector Test The Test/Reset button is used to verify proper alarm A warning label has been positioned in the cooking function� Executing the test function sounds the alarm area to remind you to provide an adequate supply of and illuminates the red LED�...

  • Page 15: Fire Extinguisher

    Safety Emergency Exit LP gas regulators must always be installed with the diaphragm vent facing downward� Regulators that There are three avenues of escape from the touring are not in compartments have been equipped with a coach in the event of an emergency, the driver’s door, protective cover�...
  • Page 16 Safety NOTES 2-10 2017 Tommy Bahama TC...

  • Page 17: General Information

    About Molds � � � � � � � � � � � � � � � 3-9 Airstream Limited Warranty Excludes � � � � � 3-4 What Are Molds � � � � � � � � � � � 3-9 What Factors Contribute Normal Wear �...

  • Page 18: Limited Warranty Policy

    (1) within 10 days of your discovery (ii) ONLY those portions of a NEW motorhome not of a defect you notify Airstream OR an authorized excluded under the section “What is Not Covered”, dealership of the defect; AND (2) you deliver your when sold by an authorized dealership;...

  • Page 19: What Is Not Covered

    Airstream; Acts of God or other a warranty failed of its essential purpose� Some states environmental conditions, such as lightning,...

  • Page 20: Obtaining Warranty Service

    Items such as curtains, upholstery, floor coverings, dealer, or may request that you bring your motorhome and window, door, and vent seals will show wear or to the Airstream factory in Jackson Center, Ohio for may even wear out within the 2-year warranty period, repairs�...

  • Page 21: Service

    Van as a touring coach, however, no information, Phone: (937) 596-6111 or (877) 596-6111 in whole or in part, in any Airstream manual should be interpreted as advice or directions to disregard or void the Warnings, Cautions, Notices, or other information contained in the Sprinter’s manuals�...

  • Page 22: Camping

    2� Y connection -- water hose; Safety Administration (NHTSA), in addition to notifying 3� Holding tank cleaner and deodorizer; Airstream, Inc� 4� Power cord adapter, 30-amp capacity; If NHTSA receives similar complaints, it may open an investigation, and if it finds that a safety defect exists 5�...

  • Page 23: Overnight Stop

    When you stop for the night, your Airstream Touring Coach is built to be safely parked in any spot that is relatively level and where the ground is firm. Your facilities are with you�...

  • Page 24: Effects Of Prolonged Occupancy

    General Information Effects of Prolonged Occupancy To avoid condensation problems, try to follow these tips to help alleviate excess moisture: Your touring coach was designed primarily for Allow excess moisture to escape to the outside when recreational use and short-term occupancy� If you bathing, washing dishes, hair drying, laundering, and expect to occupy the touring coach for an extended using appliances and non-vented gas burners�...

  • Page 25: About Molds

    General Information About Molds Waste Water System What are molds The main parts of the waste water system are the toilet, dual holding tanks, and tank dump valves (see Molds are microscopic organisms that naturally Section 9 - Maintenance for dump valve information)� occur in virtually every environment, indoors and The system is designed to provide complete self- out�...

  • Page 26: Drain Systems

    General Information Things Not to Put into Toilet or Drains Drain System (Lounge Models) • Facial tissues (they do not dissolve like toilet paper)� • Automotive antifreeze, ammonia, alcohols, or acetone� • Table scraps or other solids that may clog the drains� Winter Traveling Traveling in sub-freezing temperatures will require certain precautions to protect the plumbing system...

  • Page 27: Safety

    General Information Safety Some states do not allow LPG to be turned on while moving� While traveling in these states, simply use As always, safety should be a top priority� Ensure your common sense� How cold is it? How long will that you, and everyone traveling with you, can quickly it be before you can turn the heat back on? Is the operate the main door and the emergency exit window...
  • Page 28 General Information NOTES 3-12 2017 Tommy Bahama TC...

  • Page 29: Floor Plans And Specifications

    RA-400 Patcher for UD Section 4 FLOOR PLANS AND SPECIFICATIONS FLOOR PLANS AND SPECIFICATIONS . . . . . . . . . . . . . . . . 4-1 FLOOR PLANS .

  • Page 30: Floor Plans

    Floor Plans And Specifications Floor Plans Tommy Bahama Lounge BAR CABINET DINETTE GALLEY SEAT BATH W/SHOWER ENTRY STEP Tommy Bahama Grand Tour FRIDGE/ BATH FREEZER W/SHOWER REMOVABLE TABLE DINETTE SEAT GALLEY ENTRY STEP BAR CABINET T_TB1 T_TB2 2017 Tommy Bahama TC...

  • Page 31: Specifications

    100 Watt 100 Watt Backup Camera System w/Side Cameras Standard Standard Bed Size 70” X 82” 70” X 82” Airstream Warranty 3 Years/36,000 Miles 3 Years/36,000 Miles Mercedes-Benz® Warranty 3 Years/36,000 Miles 3 Years/36,000 Miles Mercedes-Benz® Engine Warranty 5 Years/100,000 Miles...

  • Page 32: Specification Tags

    Floor Plans And Specifications The Unit Base Weight (UBW) and Net Carrying The Vehicle Manufacturing tag lists the size of tires Capacity (NCC) weights listed in the Specification and wheel rims, maximum cold inflation pressures, the Chart are for the base unit with no options and fluids. Vehicle Identification Number (VIN), and GAWR.

  • Page 33: Interior

    Section 5 INTERIOR INTERIOR � � � � � � � � � � � � � � � � � � 5-1 PLUMBING � � � � � � � � � � � � � � � � 5-8 GENERAL INFORMATION AND CLEANING �...
  • Page 34 Interior Section 5 Interior Magnum Inverter/Charger� � � � � � � � � 5-13 ENTERTAINMENT SYSTEMS � � � � � � � � 5-18 Monitor Panel � � � � � � � � � � � � � 5-13 TV Antenna �...

  • Page 35: General Information And Cleaning

    General Information and Cleaning Impala Suede Any excessive spills should be blotted up quickly after The interior of each Airstream Tommy Bahama Touring the spill occurs� Using a clean cloth or paper towel, Coach has been designed for comfort, convenience, wipe gently�...

  • Page 36: Counter Area

    Interior Counter Area NOTE Your Airstream is equipped with Corian countertops ® The use of certain cleaning agents, including which can be cleaned with common household but not limited to powdered abrasives, solvents, cleaners� For most residues use warm soapy water or industrial strength cleaners and power washing an ammonia-based household cleaner;...

  • Page 37: Wet Bath

    WARNING The driver and passenger heated seats are provided Keep your furniture and family safe from fires by Sprinter, sent out to be recovered by Airstream to caused by careless smoking. Do not smoke when match the interior decor� drowsy. Remove immediately any flowing ash The seat adjustment mechanism provided by Sprinter or a lighted cigarette which falls on furniture.

  • Page 38: Collapsing Clothes Rod

    Return table top and pedestal to their respective down manually by mistake� These presets are set at storage positions before moving vehicle. In a Airstream and shouldn’t need adjusted� The power emergency stop or accident the top and pedestal remote is also programmed beforehand and should could cause personal injury and/or death.

  • Page 39: Ceiling And Directional Lighting

    Interior Ceiling and Directional Lighting Bar Accent Lighting All lighting in the touring coach is LED and most will require a replacement fixture should it burn out or malfunction� Two sets of remote switches are located on the wall behind the second row passenger side captain’s chair or on the side of the galley when entering the touring coach, depending on the model�...

  • Page 40: Plumbing

    Interior Plumbing Drain and Waste System Your touring coach has a drain and waste system that Water System (Self-Contained) includes waste-holding tanks made from corrosion- The fresh water system consists of a city water hookup, free, molded plastic, with trouble-free dump valves� fresh water tank gravity fill, fresh water tank and drain The main (Black Water) holding tank enables you to valve, water pump, pump filter, hot and cold water...

  • Page 41: Electrical

    Faucet Cleaning and Care All that is needed to clean your faucet is a soft, damp The touring coach toilet in your Airstream is a design cloth� Airstream does not recommend the use of scour that has been used for many years�...

  • Page 42: 12-Volt Operation

    (#11 fuse) fuses and 120-volt breakers� 7� Thermostat display: Fused to 5-amp breaker on side of furnace� NOTE Most fuses will require a qualified technician to access and replace. Contact your dealer or Airstream Service Center. 5-10 2017 Tommy Bahama TC...

  • Page 43: Battery Disconnect Switches

    Interior Battery Disconnect Switches Battery Separator The Battery Separator is located at the base of the drivers side rear jumper seat, and is accessed by opening the decorative door� It is designed as a solenoid priority system to protect the chassis charging system from excessive loading, while allowing house batteries to be charged�...

  • Page 44: Energy Management

    Airstream� There are four positions available for circuit corner of the Load Meter on the Display module will be lit� breakers� These may be single or dual units� Airstream uses both single and dual breakers as needed In addition, this ENERGY MANAGEMENT SYSTEM according to the options ordered on a unit�...
  • Page 45 LPG tank level� draw even when turned off but the power consumption This is set at the Airstream factory for the tank on the will be even greater if left on� Tommy Bahama Touring Coach and needs no further adjustment�...
  • Page 46 Interior Display Panel 120-Volt Automatic Switch Over Box The switch over box automatically switches the 120- volt feed to the Energy Management System Module from shoreline to generator and back as you choose which way to power the touring coach� You simply decide whether to plug into a 120-volt shoreline or start the generator and the box will do the rest�...
  • Page 47 Interior 120-Volt Electrical System Converter The Airstream converter system enables you to use the City Power 12-volt lights and equipment whether operating on self- When your touring coach is hooked up to external AC contained battery power or hooked up to 120-volt city power, the converter system automatically charges power�...
  • Page 48 Interior Ground Fault Circuit Interrupter GFCI Receptacle Test Most states require touring coach’s with exterior 120-volt receptacles and receptacles close to a water sources, such as a faucet, to have a GFCI� When properly installed, the GFCI circuit breaker provides reliable overload and short-circuit protection, plus protection from ground faults that might result from contact with a HOT load wire and ground�...
  • Page 49 Interior Switch And Component Locations Front Roadside Roof Locker Monitor panel display At Sliding Door Entry Inverter remote switch Main battery disconnect Generator remote switch Lighted tank heat pad switch (fresh and gray water) Energy management system display Step-extend disable switch Water heater switch/display Patio light Solar standard...

  • Page 50: Entertainment Systems

    Winegard’s RoadStar™ omnidirectional antenna Airstream does not have the capability to access any provides excellent reception of VHF/UHF TV data contained within the profile at any time. Please channels�...

  • Page 51: Appliances

    Interior Appliances TV Wall Plate Power Supply All appliances are delivered to Airstream, Inc�, with in- depth owner’s manuals� Those manuals are included in the delivery case supplied by your dealer� The manuals may contain Warnings, Cautions, and operating instruction that should be read and followed before operating the appliances�...
  • Page 52 If they should become misplaced, new literature can be ordered The roof A/C used on Airstream Touring Coach’s directly from the manufacturer or your Airstream dealer� are one of the most popular on the market today� In The manufacturer also offers a detailed service guide your owner’s packet is a set of literature covering all...
  • Page 53 Interior NOTE High Volume Roof Vent Fan motor will not start if temperature selected is warmer than interior temperature of the coach. Cleaning Instructions 1� Turn fan motor off� 2� Remove eight painted flat head Phillips screws around perimeter of screen insert only� 3�...
  • Page 54 Interior Microwave Ovens Start up Turn the power on and set the thermostat between 3 Refer to the Certified Performance Checkout sheet, and 4� You can make further adjustments to suit your included in your owner’s packet, for manufacturer, personal requirements after the box has cooled down� model, and serial number information�...
  • Page 55 Interior Thermostat Water Heater Safety If your water system is full and cold, and the water heater is ignited, the system can see pressures as high as 120 psi before the relief valve starts to open� Since the water system normally operates in the 40-psi range, the expanding water puts unusual stress on the system�...
  • Page 56 Interior NOTES 5-24 2017 Tommy Bahama TC...

  • Page 57: Exterior

    RA-400 Patcher for UD Section 6 EXTERIOR EXTERIOR � � � � � � � � � � � � � � � � � �6-1 ROADSIDE EXTERIOR FEATURES � � � � � �6-6 WAXES AND POLISHES � � � � � � � � � � �6-2 CURBSIDE EXTERIOR FEATURES �...

  • Page 58: Waxes And Polishes

    Sprinter manual� The following additional information is with the proper training and equipment� Most polishes provided by Airstream to help you understand the finish and waxes are designed to clean and polish in one and its care� Following these instructions will provide application�...

  • Page 59: Washing Your Touring Coach

    “elbow grease�” Once again, after removing stubborn stains The body kit provided by Airstream is made from state- immediately rinse with clean water� of-the-art high impact plastic� The same material is...

  • Page 60: Windows

    Service� remove all soap so it will not spot� Towel drying will NOTE help this as well� Use only power cords recommended by Airstream. CAUTION Many campgrounds provide less than 30-amp service When using a power washer, maintain a proper and your hookup may blow their fuse or circuit breaker�...

  • Page 61: City Water Hookup

    Exterior City Water Hookup Exterior Sliding Step The curbside sliding door has a sliding step with auto The city water hookup is located on the side of the retract, step out warning buzzer, and a lock extended touring coach. For consistent water flow and plumbing switch located just inside the sliding door�...

  • Page 62: Roadside Exterior Features

    Exterior Roadside Exterior Features (Lounge) Roadside Exterior Features 5� Utility hatch contains the switches for the dump valves, macerator pump and macerator pump high- NOTE pressure hose reel� This is a basic explanation of the location and 6� Electronic ignition water heater door and vent is function of exterior features.

  • Page 63: Curbside Exterior Features

    Exterior Curbside Exterior Features (Lounge) Curbside Exterior Features 4� Sliding step with auto retract has a step out warning buzzer and a lock extended switch for NOTE easy entry into the touring coach� This is a basic explanation of the location and 5�...

  • Page 64: Roadside Exterior Features (Gt)

    Exterior Roadside Exterior Features (Grand Tour) Roadside Exterior Features 5� Utility hatch contains the switches for the dump valves, macerator pump and macerator pump high- NOTE pressure hose reel� This is a basic explanation of the location and 6� Electronic ignition water heater door and vent is function of exterior features.

  • Page 65: Curbside Exterior Features (Gt)

    Exterior Curbside Exterior Features (Grand Tour) Curbside Exterior Features 4� LP tank remote fill and shutoff location. NOTE 5� Sliding step with auto retract has a step out warning buzzer and a lock extended switch for This is a basic explanation of the location and easy entry into the touring coach�...

  • Page 66: Screen Doors

    Exterior Screen Doors Folding Screen Door (Lounge) CAUTION Check that the screen door is open before closing the exterior door. Failure to follow this caution could result in damage to the screen door. Sliding Screen Door (GT) CAUTION Check that the screen door is open before closing the exterior door. Failure to follow this caution could result in damage to the screen door.

  • Page 67: Power Awning

    Exterior Power Awning CAUTION The awning manufacturer provides a complete Owner/ After closing the awning with the manual override, Operator Manual for the Carefree Awning located in the lead rail may move out from the case 1/4”-1/2”. your owner’s packet� The switch for the power awning This is normal and the awning is secure for travel is located on the passenger seat pedestal under the until power is restored or repairs are completed.

  • Page 68: Hitch Cover

    Exterior Hitch Cover 1� Kneel down behind the rear bumper� There are two slide latches on the rear cover located on the How To Remove The Hitch Cover lower backside of the cover� Both will need to be slid to the inside to be unlatched properly as shown Before Removal below�...

  • Page 69: Sprinter Van

    Airstream Components Serviced By INSTALLING AND REMOVING A WHEEL � � � � 7-8 Airstream Or Its Suppliers � � � � � � � 7-2 Mounting The New Wheel � � � � � � � � � 7-8 Cab Area �...

  • Page 70: Important Sprinter Information

    Cab door windows and use of the Sprinter Van as a touring coach; however, windshield Drive axle and hubs no information in the Airstream manual should be AM/FM radio antenna interpreted as advice or directions to disregard or Steering assembly,...

  • Page 71: Tires

    Label NOTE The TIRE AND LOADING INFORMATION placard Please contact Airstream or Onan for a service supplies information on the size and the cold tire location if repairs are need for the generator. inflation pressure for the original equipment tires supplied with your vehicle�...

  • Page 72: Proper Tire Inflation

    Sprinter Van Proper Tire Inflation • It may be necessary to inflate your tires at a truck stop or truck service center in order to achieve The level of air in your tires affects your vehicle’s adequate air pressure for your coach’s needs overall performance.

  • Page 73: Changing A Tire

    Sprinter Van Changing A Tire WARNING (Partially excerpted from the Sprinter Van Operator’s Manual) Always replace wheel nuts that are damaged or rusted. Never apply oil or grease to wheel After changing a wheel, the wheel nuts must be nuts. Damaged wheel hub threads should be tightened once the vehicle has been driven for about repaired immediately.

  • Page 74: Flat Tire

    Yoke w/pins threads� Winch Tire Yoke Airstream remounts the spare tire and installs the spare tire winch assembly on all units that do not have the optional air ride suspension� The spare tire is located under the rear of the touring coach against the bottom of the chassis floor structure .

  • Page 75: Jack

    The yoke pins must be placed failure. Please contact your dealer or Airstream in the lug holes to prevent the wheel assembly from Customer Service if you have any questions on the sliding against the cable during transit and possibly use of this equipment.

  • Page 76: Installing And Removing A Wheel

    Sprinter Van Installing and Removing A Wheel WARNING • Loosen the wheel nuts� Only certain tires meeting the tire size/load/speed • Jack up the vehicle until the wheel is clear of the index ratings contained in the Tire Pressure ground� Tables, found in the Index Section of the Sprinter’s •...

  • Page 77: Tire Rotation

    Sprinter Van Tire Rotation Correct Front and rear tires perform different jobs and can wear Duals differently depending on the types of roads driven, driving habits, etc� To obtain the longest tire life, you should inspect and rotate your tires regularly� Many automotive dealers and tire dealers will perform a free tire inspection to look for uneven or abnormal tire Dual Tire Foot Print...

  • Page 78: Air Ride Suspension

    Sprinter Van Air Ride Suspension Manual Adjustments A remote, located on the B-pillar next to the drivers The Sprinter Van is available with rear axle air seat, can be used to manually adjust the air suspension� The Sprinter is extremely suited for this air suspension system and is only available as an option suspension�...

  • Page 79: Driving

    RA-400 Patcher for UD Section 8 DRIVING DRIVING � � � � � � � � � � � � � � � � � � � 8-1 Loading A Trailer � � � � � � � � � � � � � 8-5 LOADING �...

  • Page 80: Loading

    To arrive at “THE COMBINED WEIGHT OF permissible trailer weight to be towed� OCCUPANTS AND CARGO SHOULD NEVER EXCEED” number, Airstream weighs the vehicle as Trailer Tongue Weight Rating (TWR) is the maximum finished and adds the weight of full tanks of LP and permissible weight of the trailer tongue�...

  • Page 81: Procedure For Weighting A Touring Coach

    Driving Front Axle GAWR GVWR Rear Axle GAWR GCWR - GVW SCALE WEIGHT Optional Tow Weight ___________ ___________ ___________ ___________ STEP 3a STEP 1 STEP 2 STEP 3 Tow Weight minus Front Axle GAW Rear Axle GAW Weight of Trailer or Vehicle Towed GAWR = Gross Axle Weight Rating INDIVIDUAL WHEEL POSITION WEIGHT...

  • Page 82: Safety

    Driving Safety Child restraint devices are designed to be secured with lap or lap/shoulder belts� All instructions supplied Seat belts by the restraint manufacturer must be followed� Statistics have shown children are safer when properly Federally approved seat belts are provided for the restrained in a rear seating position than in a front use of the driver, the right front passenger, the second seating position�...

  • Page 83: Trailer Towing And Driving Tips

    To assist in attaining good handling of the vehicle/trailer below carefully to assure safe trailer operation. Ask combination, it is important that the tongue weight your authorized Sprinter or Airstream dealer if you be maintained at approximately 10-15 percent of the require an explanation of information contained in loaded trailer weight, but not to exceed the hitch rating�...

  • Page 84: Towing A Trailer

    You may also use these corners to practice from the tow vehicle� Please consider using a trailer backing and parking� sway control system� For further information, see your authorized Sprinter or Airstream dealer� 2017 Tommy Bahama TC...

  • Page 85: Tracking

    Driving Tracking Brake Controller The brake controller (if so equipped) is activated when you apply the brakes of the tow vehicle� Your tow vehicle brakes will automatically apply the trailer brakes first when properly adjusted. This will help keep your tow vehicle and trailer in a straight line and make you stop as if you were driving the tow vehicle alone�...

  • Page 86: Backing Up

    Driving Backing Up WARNING In BACKING UP the important thing to remember is to DO EVERYTHING SLOWLY and to correct On slippery pavement, do not use engine drag to immediately if you see the trailer turning the wrong help slow down as this may cause the rear wheels way�...

  • Page 87: Towing Your Touring Coach

    Driving Rearview and Side Monitor System Parking Your Touring Coach An LCD digital mirror monitor comes standard on all To reduce the risk of personal injury or damage to Tommy Bahama models and replaces the existing rear the vehicle power train as a result of vehicle/trailer view mirror�...

  • Page 88: Safety Check List

    Safety Check List Interior Check List (Before Driving) 1� It is important that all doors be completely closed Your Airstream Touring Coach should be given a and locked during travel� thorough safety check before a trip� Regular use of the following list will provide safe operation of your 2�...

  • Page 89: Maintenance

    RA-400 Patcher for UD Section 9 MAINTENANCE Emptying The Black And Gray MAINTENANCE � � � � � � � � � � � � � � � � 9-1 Water Holding Tanks � � � � � 9-12 MAINTENANCE SCHEDULE � � � � � � � � � 9-2 Macerator Impeller Release Feature �...

  • Page 90: Maintenance Schedule

    Maintenance Maintenance Schedule WARNING Failure to maintain your touring coach can cause premature and unexpected parts breakage and/or erratic operation that may be hazardous. NOTE See appliance manufacturer’s literature for further information. Every 1,000 miles or 60 days Every 10,000 miles or 6 months Tires Inspect and rotate�...

  • Page 91: Suggested Maintenance And Replacement Parts

    Maintenance Suggested Maintenance and Replacement Parts (Part numbers listed are Airstream part numbers and can be ordered by calling a certified Airstream dealer.) WARNING Always replace the bulb or light fixture with the correct bulb for that light or matching fixture. Failure to heed this warning could cause fire, property damage, personal injury, or death.

  • Page 92: Exterior Care

    Maintenance Exterior Care Replacement Rivets The following exterior care products are recommended Interior by Airstream� Read and follow label directions� Exterior Part Number 330127-03 330149 sealant should be checked and resealed once a year� Rivet Name AD43ABS ADS46ABSR Walbernize Super Seal (PN - 28433W) - Use to clean...

  • Page 93: Tire Care

    Maintenance Tire Care Tire Inspection and Storage Before taking your touring coach on a trip or when The most important function of tires is to provide removing it from an extended storage period, make traction while moving and grip when steering or it a practice to inspect the overall condition of your stopping�...

  • Page 94: Battery (Maintenance Free)

    Battery (Maintenance Free) Battery Cleaning Battery maintenance is an important issue� Maintain a Your Airstream Touring Coach is factory-equipped with clean battery top and check terminals and cables for a 12V, deep cycle AGM GPL-24T Lifeline battery� tightness and cleanliness� A dirty battery will dissipate Battery Amp Draw and Testing its charge through surface contamination�...

  • Page 95: Lpg System

    Always shut off the LPG gas when refueling the immediately and call on a qualified LPG service touring coach. center or Airstream Service Center. CAUTION Moisture in the LPG tank will cause a malfunction of the regulator in controlling proper pressure.

  • Page 96: Water System (Self-Contained)

    Maintenance LPG Regulator To Operate the System with the Water Pump The LPG regulators used on Airstream Touring Coach’s Fill the water tank by opening the exterior gravity are designed for low-pressure service, with a normal feed water fill door. A high-pressure RV/Marine FDA outlet pressure setting of 11�5-in�...

  • Page 97: Water Pump And Strainer

    Maintenance Water Pump and Strainer Sanitizing The water pump and strainer are located under the Potable water systems require periodic maintenance galley accessed by removing the galley drawer, or to deliver a consistent flow of fresh water. Depending below the refrigerator and accessed by removing the on use and the environment the system is subject to, panel, depending on the model�...

  • Page 98: Drain Valve Locations

    Maintenance Drain Valve Locations (Lounge) 1 Water Heater 2 Drain Valves Bypass Valve Under Galley Under Driver Side Lounge/Bed BAR CABINET DINETTE GALLEY SEAT BATH W/SHOWER ENTRY STEP 2 Drain Valves Under Curbside Lounge/Bed The fresh water system has four fresh water line low point drain valves� There are two under the galley accessed by removing the drawer below the microwave and two under the curbside lounge or bed accessed by removing the cup holders�...

  • Page 99: Drain And Waste System

    A rubber ring is also provided Pump to lodge into a non-threaded inlet� If the rubber ring seems loose when used, Airstream recommends using Toilet some type of weight to further secure the hose� Holding Tank...

  • Page 100: Emptying The Black And Gray Water Holding Tanks

    Maintenance Emptying the Black and Gray Water Holding Tanks Macerator Impeller Release Feature Impeller Release Feature After long periods of non-use, a stuck impeller can 1� Remove the high pressure waste hose by opening the hose reel compartment door, putting the switch be easily broken loose with a screwdriver inserted in the motor shaft slot�...

  • Page 101: Winterizing And Storage

    Twice a year, or after a long storage period, we with water with the black tank flush, and then drive suggest you take your unit into your Airstream dealer the touring coach for a few miles� Don’t wait until the for a check-up and cleaning of the gas-operated tank is packed solid�...

  • Page 102: Touring Coach Winterization

    Maintenance Touring Coach Winterization 8� Remove the house batteries from your touring coach and store in a cool dry place where there 1� Level the touring coach from side to side and front is no danger of freezing� It is very important for to rear, turn the water pump off, and disconnect the optimum life of your battery to check it periodically city water�...

  • Page 103: Restoring Service

    Restoring Service 1� Re-install the fully charged house battery� The RV toilet in your Airstream is a design that has been used for many years. To flush, press down on the 2� Close the low point drain valves, holding tank...

  • Page 104: Maintenance

    Maintenance Maintenance Toilet Winterizing If the bowl-sealing blade does not operate freely after Draining Method: Turn off touring coach’s water supply� extended use, it may be restored to its original, smooth Drain toilet bowl� Disconnect supply line at water valve� operating condition by applying a light film of silicone Completely drain the toilet’s water supply line�...

  • Page 105: Electrical Diagrams

    Maintenance Electrical Diagrams 12-Volt Main Schematic N/C RED 9-17 2017 Tommy Bahama TC...

  • Page 106: 12-Volt Schematic

    Maintenance 12-Volt Schematic 9-18 2017 Tommy Bahama TC...
  • Page 107 Maintenance 12-Volt Schematic 9-19 2017 Tommy Bahama TC...
  • Page 108 Maintenance 12-Volt Schematic 9-20 2017 Tommy Bahama TC...
  • Page 109 Maintenance 12-Volt Schematic 9-21 2017 Tommy Bahama TC...
  • Page 110 Maintenance 12-Volt Schematic 9-22 2017 Tommy Bahama TC...
  • Page 111 Maintenance 12-Volt Schematic 9-23 2017 Tommy Bahama TC...

  • Page 112: 12-Volt Standard Parts List

    Maintenance 12-Volt Standard Parts List 9 VOLT BATTERY DEVICES: REMOTE DEVICES: 9-24 2017 Tommy Bahama TC...

  • Page 113: 30-Amp 120-Volt Schematic

    Maintenance 30-Amp 120-Volt Schematic 9-25 2017 Tommy Bahama TC...

  • Page 114: 30-Amp 120-Volt Standard Parts List

    Maintenance 30-Amp 120-Volt Standard Parts list 9-26 2017 Tommy Bahama TC...

  • Page 115: Audio/Video Schematic

    Maintenance Audio/Video Schematic HDMI HDMI HDMI HDMI TVb2 (CATV/SATV #2) HDMI 9-27 2017 Tommy Bahama TC...

  • Page 116: Audio/Video Standard Parts List

    Maintenance Audio/Video Standard Parts List ALL MODELS W/ REAR TV LOUNGE GRAND TOUR GRAND TOUR MODELS STD: LOUNGE ADDITIONAL ON THESE MODELS ONLY w/ FRONT TV: LOUNGE PLUS 9-28 2017 Tommy Bahama TC...

  • Page 117: Standard 30-Amp Circuit Breaker Layout

    Maintenance Standard 30-Amp Circuit Breaker Layout 20 20 20 20 GROUND BUSS Circuit 1� 30 amp, main Circuit 2� 20 amp, water heater Circuit 3� 20 amp, air conditioner Circuit 4� 20 amp, inverter Circuit 5� 20 amp, microwave, EMS Circuit 6�...

  • Page 118: Solar Panel Wiring

    A manual on the use of the solar system is included All wires are located under the roadside jumper seat� with the Airstream Owner’s Packet� Please read and To access remove the decorative door at the bottom of understand all information before operating the system�...

  • Page 119: Faqs And Answers

    Turning the corner or stopping quickly while oil is low can cause this to happen� Answer: No, your Airstream is equipped with a built in regulator rated for 65 psi� 4. What size batteries are in my Airstream Touring Coach? 2.
  • Page 120 Do this a couple times until Appliances the tank is clear� (Do not run macerator pump if tank is 1. I am planning for a trip in my Airstream. How empty�) should I get the refrigerator cooled down? 6.
  • Page 121 Maintenance NOTES 9-33 2017 Tommy Bahama TC...
  • Page 122 Maintenance NOTES 9-34 2017 Tommy Bahama TC...
  • Page 123 RA-400 Patcher for UD Index Air Conditioner 5-20 FAQs and Answers 9-31 Air Ride Suspension 7-10 Faucets 5-9 Alarms 2-3 Fire Extinguisher 2-9 Antennas Floor Plans 4-2 TV 5-18 Furnace 5-20 Satellite 5-18 Appliances 2-2, 5-19 Awning 6-11 Generator 5-14 Backing Up 8-8 Hitch 8-5 Battery...
  • Page 124 Index Plumbing 5-8 Thermostat 5-21, 5-23 Power Center 5-10 Toilet 5-9 Power Control System Winterizing 9-16 Display Panel 5-14 Towing Power Shades 5-6 A Trailer 8-6 Your Touring Coach 8-9 Tires 7-3 Care 9-5 Range 5-22 Changing 7-5 Receptacles 5-16 Rotation 7-9 Refrigerator 5-22 Vent 5-21...
  • Page 126 428 West Pike Street Jackson Center, OH. 45334-0629 Phone: (937) 596-6111 Fax: (937) 596-6539 www.airstream.com...

Table of Contents
