TR3200

Shower Trolley

Operating manual

Version 2021-01-01

Always study this manual carefully before operating

the shower trolley.

The operator/user must always have access to the

operating manual.

The shower trolley is intended for professional use

only where the patient will be under supervision of

trained personnel.

Mandatory to read the manual before using the equipment

Registered at Medical Products

Agency, Sweden as a MDR Class 1

product according to MDR 2017/745.

TR reserves the right to make design

changes and/or improvements without

notice.

Operating instructions and recommended

maintenance procedures are explained in the

following pages.

If you have any questions regarding the operation or

maintenance of your shower trolley and cannot find

the answer in this manual, please contact us.

The shower trolley is designed for years of trouble-

free operation, with proper use and maintenance.

Hygiene Equipment

Designed for People

Table of Contents

Need help?

Do you have a question about the TR3200 and is the answer not in the manual?

Questions and answers

Summary of Contents for Rt TR3200

Page 1 Hygiene Equipment TR3200 Designed for People Shower Trolley Operating manual Version 2021-01-01 Registered at Medical Products Agency, Sweden as a MDR Class 1 product according to MDR 2017/745. TR reserves the right to make design changes and/or improvements without notice.
Page 2: Table Of Contents
TR3200 TR3200-R Technical specifications Technical specifications Dimensions User instructions Before first use Height adjustment Tilt adjustment Audible tones TR3200 Audible tones TR3200-R Calibration/Initialization TR3200 Calibration/Initialization TR3200-R Charging instructions TR3200 Charging instructions TR3200-R Side rails Drainage Castors with brake Straight steering castors...
Page 3: Manufacturer
Hygiene Equipment Designed for People Manufacturer TR Equipment AB Rundelgatan 2 SE-573 35 Tranås Sverige Phone: +46 (0)140 38 50 60 www.trequipment.com info@trequipment.se Group subsidiaries: TR Group Inc. Phone: +1 (800) 7526900 www.trequipment.com information@trequipment.com United Kingdom: TR Equipment Ltd Phone: +44 (0) 844 335 8386 www.trequipment.com info@trequipment.co.uk Germany:...
Page 4: Introduction
Introduction Dear Customer, Thank you for choosing one of our quality products. We hope you enjoy the TR3200 shower trolley. This manual shall, in conjunction with staff training, ensure that the operator/user is always using and/or operating the TR3200 correctly.
Page 5: Unpacking
Lift the over the TR 3200-L/ -LR (2 people required). Unpack the TR3200/ -R bariatric shower trolley by removing the lower cardboard staples with a pliers. If the cardboard box is wrapped in plastic, carefully cut, and remove the plastic. DO NOT use any sharp tools that may scratch the shower trolley.
Page 6: Intended Use
Hygiene Equipment Designed for People Intended use Shower trolley TR3200 The TR 3200 shower trolley is a battery-operated shower trolley. The TR 3200 shower trolley is intended to ease transferring and caring of the patient. Typical situations where the TR 3200 shower trolley is used includes: Transporting the patient to and from a showering area.
Page 7: Safety Instructions
Make sure that all parts that comes in contact with the patient are intact and without sharp edges. Ensure that the Trolley can be moved, raised, or lowered safely to avoid any pinch injuries to patient. Castor brakes must be securely locked on the TR3200 before transferring a patient and once in position over a drain.
Page 8 Trolley should not be used if defects are noted. Prompt service is required. If you have questions regarding operation or maintenance of your TR3200 Shower trolley and cannot find the answer in this manual, please contact TR Equipment or your local TR Equipment representative.
Page 9: In Case Of Accident
Safety instructions In case of accident Note: In case of a serious incident when using the TR3200 shower trolley, this should be reported to the manufacturer and to the local authorities where you are established. TR Equipment AB Rundelgatan 2 SE-573 35 Tranås...
Page 10: Features And Controls
Hygiene Equipment Designed for People Features and controls TR3200/-L 10, 12 10, 12 11, 13 Grey or Blue Wedge pillow 15° (option) Lifting columns (2pcs) Grey or Blue Wedge pillow 30° (option) Mattress Battery box with Emergency stop Pillow Stretcher...
Page 11 Hygiene Equipment Designed for People Features and controls TR3200-R/-LR 10, 12 10, 12 11, 13 Lifting columns Grey or Blue Wedge pillow 15° (option) Mattress Grey or Blue Wedge pillow 30° (option) Pillow Removable battery Stretcher Castor with brake Straight steering castor...
Page 12: Product Description
Battery operated and height adjustable shower trolley including: Castors with brake (2 pcs), Straight steering castors (2pcs), Lifting columns (2pcs), Hand control, Battery, Battery charger, Blue mattress, Blue pillow, Drainages 2pcs, Drainage plugs (2pcs) and Drainage hose 1M. TR3200 are available in two different sizes: TR3200 TR3200-L...
Page 13: Tr3200-R
Castors with brake (2 pcs), Straight steering castors (2pcs), Lifting columns (2pcs), Hand control, Removable battery, Battery charger, Blue mattress, Blue pillow, Drainages 2pcs, Drainage plugs (2pcs) and Drainage hose 1M. TR3200-R are available in two different sizes TR3200-R TR3200-LR...
Page 14: Technical Specifications
500 – 900mm / 19,7” – 35,4” Lifting speed 12mm/s Mattress and pillow IP Class IP X5 Floor clearance 160mm / 6,3” Battery TR3200/-L 24VDC 7Ah (Lead-acid, rechargeable) Battery TR3200-R/-LR 24VDC 4Ah (Li-ion rechargeable) Battery charger input 100-240VAC 50/60Hz Battery charger out put 24VDC...
Page 15: Dimensions
Hygiene Equipment Designed for People Technical specifications TR3200/TR3200-R TR3200L/TR3200-LR Drawing mm Drawing Inch...
Page 16: User Instructions
Hygiene Equipment Designed for People User instructions Before first use TR3200 Onboard batteries Clean mattress and pillow. Make sure the Emergency stop is released. Charge the battery for 24hours. See instructions in table of contents. Calibrate/initialize the lifting columns. See instructions in table of contents.
Page 17: Height Adjustment
Hygiene Equipment Designed for People User instructions TR3200/TR3200-R – Height and tilt adjustment Always make sure that the patient is comfortably positioned on the stretcher mattress, with side rails securely locked before raising, lowering, or tilting the shower trolley. Use the hand control to raise and lower the stretcher to desired height.
Page 18: Audible Tones Tr3200
Hygiene Equipment Designed for People User instructions TR3200 – Audible tones One short tone When the stretcher reaches the horizontal position after being tilted a short audible tone will be heard. One long and one short tone When the batteries need to be charged, one long and two short tones will be heard.
Page 19: Calibration/Initialization Tr3200
Hygiene Equipment Designed for People User instructions TR3200 – Calibration/Initialization Use the hand control to calibrate/initialize the lifting columns. Press the DOWN button and run the lifting columns DOWN to the lowest position. When the lifting columns are in the lowest position press the DOWN button again.
Page 20: Charging Instructions Tr3200
Designed for People User instructions TR3200 – Charging instruction onboard batteries Charge the battery daily for at least 8 hours or when the low battery audible tone sounds, when using the hand control. The batteries cannot be overcharged. The battery charger is equipped with a magnetic connector to avoid damages on the charger if the shower trolley will be moved during charging.
Page 21: Charging Instructions Tr3200-R
Designed for People User instructions TR3200 – Charging instruction removable battery Charge the battery daily for at least 8 hours or when the low battery audible tone sounds, when using the hand control. The batteries cannot be overcharged. The battery charger is equipped with a magnetic connector to avoid damages on the charger if the shower trolley will be moved during charging.
Page 22: Side Rails
Hygiene Equipment Designed for People User instructions Side rails The “bed side rail” (transfer side) is easily lowered to a horizontal position for a safe patient transfer and raised again before transport. Pull the rail to a vertical position (1), lift the rail to release the two locks at the end of the rail (2) and swing it down to a horizontal position (3).
Page 23: Drainage
The drainage plug for each outlet is fastened with a nylon string on the stretcher frame. Castors with brake: The TR3200 is equipped with two castors with brake. Castors with brake has a Grey pedal (5). To activate the brake, press the Grey pedal DOWN with your foot.
Page 24: Straight Steering Castors
Hygiene Equipment Designed for People User instructions Castors with straight steering function The TR3200 is equipped with two straight steering castors (6) with Black pedal. To activate the straight steering function, press the Black pedal DOWN with your foot. Only activate the straight steering function on the front castor.
Page 25: Patient Handling
Hygiene Equipment Designed for People User instructions Patient handling – Introduction Warning Never leave the patient unattended Warning Always check the water temperature by hand before showering the patient. Warning Always check the water temperature by hand before showering the patient. Warning Always use the hose holder to prevent dripping on the floor during transport.
Page 26: Transfer From Sling Lift Onto Shower Trolley
Patient handling – From sling lift onto shower trolley Lower the TR3200 to the lowest position by pressing the Down button on the hand control. Position and lock the castor brakes by pressing the central locking control bar downwards until it clicks into position.
Page 27: Transfer From Wheelchair Onto Shower Trolley
Hygiene Equipment Designed for People User instructions Patient Transfer from Wheelchair onto Shower trolley You can raise or lower the Shower Trolley using the hand control to match wheelchair height and thus ease the transfer of wheelchair patients. Two attendants are recommended. Tilt the stretcher to a flat position using the hand control and lower the side rail.
Page 28: Transfer From Bed Onto Shower Trolley
Hygiene Equipment Designed for People User instructions Patient Transfer from Bed onto Trolley Follow the recommended procedures. Do not omit any steps. Stay in sequence. Make sure the bed guard rail is raised on the side of the bed opposite from the Trolley. Turn the patient to his/her side, facing away from the trolley.
Page 29: Showering The Patient
Hygiene Equipment Designed for People User instructions Patient handling – Showering the patient When showering, the patient must remain on the shower trolley stretcher with the side rails securely locked at all times. Always physically ensure that the water temperature is as desired before and during showering or bathing.
Page 30: Labels & Symbols
Hygiene Equipment Designed for People Labels & symbols Label TR Equipment logotype Medical equipment according to MDR 2017/745 CE marking Production date Factory address Article number Serial number Mandatory to read the manual before using the equipment...
Page 31 Labels & symbols Never sit on the side parts of the stretcher Maximum working load 200kg / 440 lbs Charging information TR3200-R Symbol on battery charger TR3200: Class II, double insulated Internally powered medical equipment Use only battery charger supplied by TR...
Page 32: Routine Maintenance
It’s good practice to establish these procedures and then adjust the frequency as your conditions indicate. Before every use Visual inspection of the TR3200 shower trolley: Make sure that it stands securely on the floor. Make sure that it is possible to raise and lower the shower trolley.
Page 33: Annual Maintenance
Hygiene Equipment Designed for People Routine maintenance Annual maintenance: Repeat Before every use, Daily maintenance, and Monthly maintenance. Thorough inspection of all steps mentioned above. We recommend that the annual maintenance is performed by approved and designated staff If you don’t have the Service and maintenance manual, contact TR Equipment or your TR Equipment representative to get a new one.
Page 34: Maintenance Every 3 Years
Maintenance recommendations for Maintenance every 3 years, Maintenance every 5 years, and Maintenance every 10 years are based on Home Care use and Public use from SS-ISO 17966:2016. If your TR3200 will be used in an institution, contact TR Equipment for a customized maintenance schedule. Maintenance every 3 years Repeat Before every use, Daily maintenance, Monthly maintenance, and Annual maintenance.
Page 35: Recycling
Hygiene Equipment Designed for People Disposal / Recycling Recycling of the equipment Pillow and mattress shall be recycled as flammable material. Plastic plate shall be recycled as flammable material. Chassis parts and fasteners parts shall be recycled as Metal materials. Castors are produced in Polyurethane and shall be recycled as flammable materials.
Page 36: Cleaning Instructions
Hygiene Equipment Designed for People Cleaning instructions General guidelines for cleaning detergent Nonabrasive type of detergent Less than 5 Wt% chloride content Less than 3 Wt% alcohol content Warning Never use solvent based or strong alkaline cleaning liquids, which can damage or stain the mattress and pillow surfaces.
Page 37 Hygiene Equipment Designed for People Cleaning instructions Select cleaning interval according to the degree of contamination. Contaminations should be removed as soon as possible to prevent material damage. Do not clean material with tools which might damage surfaces. Use a towel, sponge, or a soft brush.
Page 38 Hygiene Equipment Designed for People Cleaning instructions The User/operator is responsible for selecting the detergents and additives. Please read the detergent supplier’s instruction manual and find out whether the product is suitable or not. The shower trolley must be cleaned immediately after every use. Dry the unit well before fastening the mattress.
Page 39: Training Record
Hygiene Equipment Designed for People Training record Date: Participants: Signed by:...
Page 40: Maintenance Record
Hygiene Equipment Designed for People Maintenance record Date: Participants: Signed by:...
