Mocbos DC 3600 XRi Manual

Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
MU 821.20/27
Manual Completo
Rev.00
DC 3600XRi
24/08/2023
DC 3600 XRi
VARIADOR DE VELOCIDAD
PARA MOTORES DE CC
Manual Completo
¡Descargar
D i r e c c i ó n: C a r l o s M . R a m í r e z 2 5 5 5 – C P 1 4 3 7 , B s. A s . , A R G E N T I N A
T e l : ( 0 0 5 4 1 1 ) 4 9 1 8 - 2 2 9 9 | W h a t s A p p : + 5 4 9 1 1 4 4 9 2 - 3 0 7 0
E - m a i l: i nf o @ m ocb o s . c o m | W e b Si te : www.mocbos.com
Mocbos
MOTORTECH S.A. / Enertronica Santerno

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the DC 3600 XRi and is the answer not in the manual?

Questions and answers

Summary of Contents for Mocbos DC 3600 XRi

  • Page 1 T e l : ( 0 0 5 4 1 1 ) 4 9 1 8 - 2 2 9 9 | W h a t s A p p : + 5 4 9 1 1 4 4 9 2 - 3 0 7 0 E - m a i l: i nf o @ m ocb o s . c o m | W e b Si te : www.mocbos.com Mocbos MOTORTECH S.A.
  • Page 2 MU 821.20/27 Manual Completo Rev.00 DC 3600XRi 24/08/2023 Mocbos MOTORTECH S.A. / Enertronica Santerno...
  • Page 3 PERSONAL INJURY AND/OR ELECTRICAL SHOCK HAZARD • • • • CAUTION! EQUIPMENT DAMAGE HAZARD • • • Installation • • • • Electromechanical safety is the responsibility of the user. Electrical devices can constitute a safety hazard. Mocbos MOTORTECH S.A. / Enertronica Santerno...
  • Page 4 This is achieved through basic insulation and protective earth grounding, or double- insulation to provide SELV Control Circuits. This protection allows a safe connection to other low voltage equipment. Earth bonding is the responsibility of the installer. Mocbos MOTORTECH S.A. / Enertronica Santerno...

  • Page 5: Table Of Contents

    Maximum Current Mode .................... 21 Quench Mode....................... 21 Stall Mode ........................23 Optional START (ramp to stop) ................... 24 FORWARD/REVERSE truth table ................. 24 9 Trouble shooting ....................26 10.2 Rating table ........................28 Mocbos MOTORTECH S.A. / Enertronica Santerno...

  • Page 6: Introduction

    • Control the shaft direction using linear voltage signals or pushbuttons. • The unit can directly connect to a PLC logic controller. • The unit has a comprehensive range of extra inputs and outputs. Mocbos Introduction MOTORTECH S.A. / Enertronica Santerno...

  • Page 7: Mechanical Dimensions

    3600XRi 3600XRi (90 mm : 36 A) 70 mm 200 mm terminals terminals 165 mm 175 mm terminals cover 100 mm heatsink earth screw side view plan view Figure 1 Mechanical dimensions Mocbos Mechanical dimensions MOTORTECH S.A. / Enertronica Santerno...

  • Page 8: Guide For Systems Used In The Eu

    BACKPLATE 24V LOGIC CONTROL CLEAN EARTH POINT METAL WORK INSULATED FROM METAL WORK DOORS 110V CONTROL INCOMING SAFETY EARTH Figure 2 Star point connections for multiple drives Mocbos Guide for systems used in the EU MOTORTECH S.A. / Enertronica Santerno...

  • Page 9: Requirements For Emc Compliance

    DRIVE DRIVE DRIVE ARMATURE CONTROL AC SUPPLY EARTH AND FIELD TERMINALS INPUTS TERMINAL OUTPUTS CONTROL AC SUPPLY SIGNAL FILTER FILTERS UNIT User’s metal enclosure Figure 3 Connections for EMC compliance Mocbos Requirements for EMC compliance MOTORTECH S.A. / Enertronica Santerno...

  • Page 10: Installation

    Rating table, page 28). The fuse current rating must be at least 1. 75 times the armature current. The voltage rating must be suitable for the Mocbos Installation MOTORTECH S.A. / Enertronica Santerno...

  • Page 11: Typical Applications

    Figure 4 Basic connection connect START T13 directly to COM DANGER one fuse is necessary on the live ELECTRIC SHOCK RISK (L) for line-to-neutral operation COM must be earthed for protective class 1 Mocbos Installation MOTORTECH S.A. / Enertronica Santerno...

  • Page 12: Commissioning

    S1 and S2. The link for the MAX CURRENT potentiometer mode is in the POS I/ NEG I position. The 4Q TORQUE/2Q TORQUE/SPEED link is in the SPEED position. Mocbos Commissioning MOTORTECH S.A. / Enertronica Santerno...

  • Page 13: Block Diagram

    MU 821.20/27 Manual Completo Rev.00 DC 3600XRi 24/08/2023 Mocbos MOTORTECH S.A. / Enertronica Santerno...
  • Page 14 MU 821.20/27 Manual Completo Rev.00 DC 3600XRi 24/08/2023 Mocbos Commissioning MOTORTECH S.A. / Enertronica Santerno...
  • Page 15 MOTOR fwd/rev BRAKE fwd/rev FWD + and - REV + and - SPEED DANGER! ANTI-CLOCKWISE MID-WAY CLOCKWISE See the label on the side of the transformer for the model type. Figure 6 User adjustments Mocbos Commissioning MOTORTECH S.A. / Enertronica Santerno...

  • Page 16: Terminal Descriptions

    Tacho input 25-400 V - negative for forward rotation with positive setpoint. 10 N/C 11 N/O 12 C/O 8 COM N/C STOP pushbutton. STOP N/O START pushbutton. START START latch line (JOG). N/C FORWARD pushbutton. N/C REVERSE pushbutton. Mocbos Commissioning MOTORTECH S.A. / Enertronica Santerno...
  • Page 17 Auxiliary input to speed demand scaled ±10 V for ±100%. 70 IP Do not use if TORQUE/SPEED link is in the SPEED position as the auxiliary input function is already being used by the AUX (T6) auxiliary terminal. Mocbos Commissioning MOTORTECH S.A. / Enertronica Santerno...
  • Page 18 52, 53, 59, 60 Minimum coil resistance 2k8 Terminal 51 (-24 V) Figure 7 Relay circuits Motor armature connection (positive). Motor armature connection (negative). L2/N Line ac return; either neutral or L2. Line ac supply input. Mocbos Commissioning MOTORTECH S.A. / Enertronica Santerno...

  • Page 19: Preset, Switches And Links

    These two switches set the maximum current as a percentage of the rated current of the unit. The MAX CURRENT presets can then adjust the maximum current between this current to zero. % of rated 100% Mocbos Commissioning MOTORTECH S.A. / Enertronica Santerno...
  • Page 20 When S8 is ON, speed feedback is taken from the armature voltage. There must be no connection to terminal T9. 7.4.3 Links 7.4.3.1 Supply Voltage Selector HIGH 415 V 240 V 240 V 110 V LV60 60 V 30 V LV48 48 V 24 V Mocbos Commissioning MOTORTECH S.A. / Enertronica Santerno...
  • Page 21 Refer to "8.1 Torque Control Mode" on page 20. 7.4.3.4 4/20 mA and 0/20 mA Modes with T2 the input and T5 the return. is possible but only if the MIN SPEED preset is between T2 and T5. Mocbos Commissioning MOTORTECH S.A. / Enertronica Santerno...
  • Page 22 • If both the TIMER and STALL LEDs are illuminated then the timer has tripped and the drive has been quenched (provided that an appropriate quench mode has been selected – refer to "7.4.3.5 Quench Mode" on page 17). Mocbos Commissioning MOTORTECH S.A. / Enertronica Santerno...

  • Page 23: Pre-Operation Motor Check List

    If the motor does not achieve rated output volts, stop the drive and adjust switches S3 and S4. For example, if the motor armature volts is 180 Vdc, set SW3 to OFF and SW4 to ON (refer to "Figure 6 User adjustments" on page 10). Mocbos Commissioning MOTORTECH S.A. / Enertronica Santerno...

  • Page 24: Bi-Directional Operation

    (T4) - refer to the Alternative basic connection, "Figure 4 Basic connection" on page 6. • Alternatively, wire a speed setting potentiometer to MAX (T4) and MIN (T2) to give a speed Refer to "7.3 Terminal descriptions" on page 11. Mocbos Commissioning MOTORTECH S.A. / Enertronica Santerno...

  • Page 25: Options

    (brake) (motor) can be used for load (brake) (motor) sharing by inputting the modulus current signal from SP69 on a master drive. Mocbos SCHEMATIC OF STALL TIMER Options MOTORTECH S.A. / Enertronica Santerno SCHEMATIC OF STALL TIMER DETECTOR...

  • Page 26: Maximum Current Mode

    (fast) link. WARNING! PERSONAL INJURY AND/OR EQUIPMENT DAMAGE HAZARD RUN must not be relied upon during hazardous operations. Mocbos Options MOTORTECH S.A. / Enertronica Santerno...
  • Page 27 RAMP QUENCH CONDITION The speed ramp will be quenched by de-energised stall or run. The drive will quench occurs total Mocbos 1 second after speed remains at zero. quench Options MOTORTECH S.A. / Enertronica Santerno set by DOWN RAMP...

  • Page 28: Stall Mode

    150% 210% 470K 150% 187% 150% 166% OPEN 100% 150% 150% WARNING! PERSONAL INJURY AND/OR EQUIPMENT DAMAGE HAZARD RUN is in electronic inhibit function. RUN must not be relied upon during hazardous operations. Mocbos Options MOTORTECH S.A. / Enertronica Santerno...

  • Page 29: Optional Start (Ramp To Stop)

    * Opening the FORWARD push button momentarily selects the +10 V output which is maintained after releasing the push button, until the REVERSE push button is opened momentarily which returns the output to -10 V. Releasing the REVERSE pushbutton does not affect the output. Mocbos Options MOTORTECH S.A. / Enertronica Santerno...

  • Page 30: Trouble Shooting

    Reduce ramp rates Current set too high Motor response Loose tacho couplings Improve tacho coupling has speed-related Misaligned tacho Re-align the tacho instability Eccentric load Balance load Rotate STAB clockwise Mocbos Trouble shooting MOTORTECH S.A. / Enertronica Santerno...
  • Page 31 Dw (Watts) = 3 x armature current (approximately) dissipation Environment Altitude 3000 m maximum for full rating. Derate 1% / 100 m above 3000 m Ambient 40 °C maximum for full rating. Derate 2.5% per °C above 40 °C Mocbos MOTORTECH S.A. / Enertronica Santerno...
  • Page 32 Negative bridge Stall timer tripped Dimensions Width 200 mm Depth 175 mm Fixings 4 / 8 / 16 / 32 A units M5 x 35 mm bolts 36 A unit M5 x 50 mm bolts Mocbos MOTORTECH S.A. / Enertronica Santerno...

  • Page 33: Rating Table

    Nominal output is based on a maximum Form Factor (ratio of RMS ac supply current to dc output) of 1.5. SERVICIO TECNICO Dirección: Carlos M. Ramírez 2555– C.A.B.A. Argen�na Teléfono: (011) 4918 – 2299 E-mail: info@mocbos.com Web: www.mocbos.com MOTORTECH S.A. Mocbos MOTORTECH S.A. / Enertronica Santerno...
