Crosley CR3110A - Octave Bluetooth Speaker Manual

Safety Instructions

Read and understand this entire manual before using this product. Keep these instructions for future reference.

  1. Do not use this product near water.
  2. This product should be operated only by the type of power source indicated on the marking label or in this instruction manual.
  3. Do not defeat the safety purpose of the polarized plug. A polarized plug has two blades with one blade wider than the other. This plug will fit into the power outlet only one way. If you are unable to insert the plug fully into the outlet try reversing the plug. If the plug should still fail to fit, contact your electrician.
  4. Protect the power cord from being walked on or pinched particularly at plugs, convenience receptacles, and the point where they exit from the product.
  5. Do not overload wall outlets, extension cords, or integral convenience receptacles as this can result in a risk of fire or electric shock.
  6. Never push objects of any kind into this product through openings as they may touch dangerous voltage points or short-out parts that could result in a fire or electric shock. Never spill liquid of any kind on the product.
  7. Do not attempt to service this product yourself as opening or removing covers may expose you to dangerous voltage or other hazards. Refer all servicing to qualified service personnel.
  8. Changes or modifications to this unit not expressly approved by the party responsible for compliance could void the user's authority to operate the equipment.
  9. Do not use attachments not recommended by the product manufacturer as they may cause hazards.
  10. A product and cart combination should be moved with care. Quick stops, excessive force, and uneven surfaces may cause the product and cart combination to overturn.
  11. Slots and openings in the cabinet are provided for ventilation and to ensure reliable operation of the product and to protect it from overheating. Do not block or cover these openings.
  12. Unplug the product during lightning storm or when unused for long periods of time.

Items in this package

Before throwing away any packaging materials, please check thoroughly and make sure you find the following items that come along with this package:

  • Bluetooth Speaker
  • Power cord

Please contact Crosley Customer Service if there is any accessory missing from the package. Retain the original packaging materials for exchange or return purposes.

Specifications

Power: AC 100-240V ~ 50/60 Hz
Power consumption: 25 W
Speaker: 5 W X 2 + 15W

warning Note:

  • Design and specifications are subject to change without notice.
  • To help save power consumption, some models will comply with ERP energy saving standard. When there is no audio input for 15 minutes, their powers will automatically cut-off. To turn power back on and resume playing, you will need to turn off the power and turn it on again.

Product Description

Product Description

  1. Aux In Jack
  2. Bluetooth Indicator
  3. AUX Indicator
  4. USB Indicator
  5. Standby Indicator
  6. USB Port
  7. Volume Knob
  8. Treble Knob
  9. Bass Knob
  10. Play/Pause Button
  11. Mode Button
  12. Forward & Backward Skip Button
  13. Power Jack

Initial Setup

Essential Setup

  1. Place the unit on a flat and level surface. The selected location should be stable and free from vibration.
  2. Connect the Power plug to the Power Jack of the unit.

Standby Operation

To put the unit in Standby Mode, long press the Mode Button. To exit Standby Mode, press the Mode Button again. The unit will automatically go to Bluetooth Mode once out of Standby Mode.

warning Note: The Standby Indicator will be red while in Standby Mode.

Bluetooth Operation

  1. Press the Mode Button to select the Bluetooth mode, you will hear an activation sound from the unit.
    warning Note: The Bluetooth Indicator will be blue.
  2. Turn on the Bluetooth feature of your audio device, search for "CROSLEY CR3110A" and pair.
  3. Once your device is successfully paired with the unit, you will hear a short confirmation sound from the unit.
  4. Play and stream music from your device to the unit.
  5. During playback, press the Play/Pause Button to suspend and resume song.
  6. During playback, short press the Forward & Backward Skip button to go to the next song. Long press the Forward & Backward Skip button to go to the previous song.
    warning Note: Bluetooth version - *2.1*

Aux Input Connection

You can connect an audio device to this unit and play your music through its speakers. To do this, press the Mode Button to Aux-In Mode (The Aux Indicator will be green), connect a 3.5 mm auxiliary cable (Not Included) between your audio device to the Aux In Jack of this unit and start playing the music.

USB Playback

  1. Press the Mode Button to select the USB mode.
    warning Note: The USB Indicator will be orange.
  2. Insert a USB device into the USB port.
  3. To Forward Skip, short press the Forward & Backward Skip button.
  4. To Backward Skip, long press the Forward & Backward Skip button.
  5. To stop and resume the playback, press the Play/Pause button.

warning Note:

  • Only use 32 GB or smaller USB

Troubleshooting

There is no power

  • No power at the power outlet.
  • Power adaptor is not connected correctly.

There is no sound

  • Make sure the volume is turned up.
  • Mode is in the Bluetooth position.
  • Make sure the volume on your third party device is turned up.

Questions, problems, missing parts?

Before returning to the store, call Customer Service
8 a.m. – 6 p.m., EST, Monday – Friday
1-888-CROSLEY www.crosleyradio.com
