- Page 1 Smart WiFi Battery Camera User Manual Security Expert for Your Home and Business...
-
Page 2: Table Of Contents
Contents 1. Packing List 2. Product Appearance 3. Quick Start 4. Set Up the Camera 5. Install the Camera 6. Share the Camera 7. Charge the Camera 8. Indicator Light Status 9. Camera's Specification 10. Solar Panel's Specification 11. Firmware Upgrade 12. -
Page 3: Packing List
Packing List Camera Solar Panel Bracket for Camera Bracket for Solar Panel Screws Bag USB Charging Cable User Manual Product Appearance Camera WiFi Antenna Lens White Light Microphone Indicator Light Human Body Infrared Sensor... - Page 4 Bracket Micro-USB Port Speaker Micro-SD Card Slot Power Button Reset Button...
- Page 5 Solar Panel Solar Panel ( 3W ) Bracket Power Cable (Micro-USB Port) How to install the bracket?
-
Page 6: Quick Start
Quick Start The wireless smart battery camera operates on the built-in internal batteries and can also be powered using the included AC-Power supply or solar panel. 1. Download and install the App The wireless smart battery camera supports Android and iOS devices using the mobile App. - Page 7 2. Add camera Sign in to the App, tap on the Green "+" symbol on the upper right hand corner then tap on "Add a New Camera" and follow the prompts displayed on screen (please bring the camera and device close to the router when initially configuring).
-
Page 8: Set Up The Camera
Set Up the Camera Step 1) After pressing the camera switch for 3 seconds, the camera will turn on. The camera will emit the scanning sound "Ding Dong Ding Dong" after it is turned on ( if you do not hear it, please quickly press the power button twice). - Page 9 Step 4) On the next page select your desired 2.4GHz WiFi network from the drop down menu under "WiFi Name (SSID)" then enter the password. To ensure a longer connection range, the camera only supports 2.4GHz WiFi with stronger wall penetration capability and does not currently support enterprise level authentication.
- Page 10 Step 5) Point the lens of the camera at the QR code generated by the App about 7inches away until you hear a "Ding" sound. About 7 inches (20cm)
- Page 11 Step 6) After a few moments the camera will provide a prompt sound indicating that the connection was successful. At this point the App will request that you place the camera at the location you wish to set it up at (you do not need to mount it at this point). Please check the signal strength to ensure that it is adequate for this location then tap on "Next Step".
- Page 12 Wi-Fi connection troubleshooting: lf you hear "WiFi Password Error" from the camera, please check whether the WiFi password you entered into the App is correct. Some common issues the first letter of the password getting auto-capitalized on some devices. lf you hear "WiFi not found" please check whether your selected WiFi network has the correct name and make sure to place the camera as well as the device you installed the App on is near the router.
-
Page 13: Install The Camera
Install the Camera (1) Select a good spot for your camera Select a good spot for your camera, please install the camera in a position where its view is not blocked and ensure that it is within the coverage of the WiFi network. The PIR infrared sensor is more sensitive to movements across the camera's field of view than movements toward or away from the camera. - Page 14 (2) Install the bracket 1) Bracket installation: Use the drilling tool to punch holes on the wall according to the hole distance of the base. It is recommended to mark the holes on the wall with a pencil before drilling. Screw the expansion nut into the holes on the wall, and then connect the bracket to the expansion nut with screws to complete the fixing.
-
Page 15: Share The Camera
Share the Camera You can provide access to the camera live stream as well as previously recorded footage to family and friends using the camera share function. Only the administrator account that initially set up the camera can invite other users to share. Find the camera you want to share on the App homepage or camera setting page. - Page 16 2) Click "Invite", and a QR code will be generated for sharing. 3) For the members you need to share, find "Add Friend's Camera" in the "User" page to enter the scanning page.
- Page 17 4) Scan the QR code on your mobile phone, and you will receive the confirmation notification after success. The sharing will be completed after you agree.
-
Page 18: Charge The Camera
Charge the Camera App will remind you to charge your camera when the battery is low. Please use the Micro USB cable to plug into the 5V/1.5A charging adapter to charge the camera. During charging, the camera's indicator light is solid yellow, and when the camera is fully charged, the indicator light will turn into solid green. -
Page 19: Solar Panel's Specification
Solar Panel's Specification: Item Specification Power Working voltage ≥4.5V Working current ≥570mA Interface Micro-USB Size 173x120x13.5(mm) Firmware Upgrade When you connect your camera through the App, it will prompt you if the latest firmware is available. You can also manually check the firmware upgrade in the settings of the App. - Page 20 NOTE: This equipment has been tested and found to comply with the limits for a class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates radiate radio frequency energy, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications.
-
Page 21: Faq
1.Q:Camera permission management: How to invite family and friends to use my camera together? A: Open the App and select your camera on the home page. Click the share button on the home page or the "Share" in the camera settings to enter the sharing page, and then click "Invite"... - Page 22 5.Q:How far should the camera be placed from the router? A: After testing, the WiFi connection distance can normally reach up to 150 meters in the open area. However, the actual situation depends on the strength of WiFi and its surrounding environment (thick walls, electromagnetic devices, large metal objects will all cause interference to the WiFi signals).
- Page 23 All rights reserved. No part of this publication may be reproduced by any means without written permission from Techage. The information in this publication is believed to be accurate in all respects. Techage can not assume responsibility for any consequences resulting from the use thereof.
