Summary of Contents for IN2CORE ScreenPort SDI Pro

  • Page 1 ScreenPort SDI Pro User Guide version 1.6...
  • Page 2: Table Of Contents

    Table of Contents SCREENPORT SDI PRO USER GUIDE ............0 LOAD ....................8 INTRODUCTION ..................2 SELECT .................... 8 FEATURES ....................3 DELETE .................... 9 BOX CONTENTS ..................3 PLAYBACK ................... 9 CONNECTORS AND CONTROLS ............3 SLIDER .................... 9 POWER OPTIONS ..................
  • Page 3: Introduction

    INTRODUCTION ScreenPort SDI Pro is a 3rd generation of the unique ScreenPort hardware line, used primarily as an SDI video, audio and metadata capture card for iPad, iPhone and Mac. Latest iteration replaces battery slots with LEMO power connectors to provide seamless operation when mounted directly on the camera body.
  • Page 4: Features

    Waveform, vectorscope, and histogram analysis • Focus peaking and customizable false color • Future-proof design upgradable by firmware BOX CONTENTS ScreenPort SDI Pro package includes: • ScreenPort SDI Pro device • Two WiFi dual-band antennas • Power adapter with international plugs •...
  • Page 5: Power Options

    ScreenPort SDI Pro offers multiple power options for its operation: USB-C POWER ADAPTER When portability is not a requirement, ScreenPort SDI Pro can be powered using included AC/DC power adapter. Moreover, power will be passed to iOS devices allowing users to charge it. The power...
  • Page 6: Lemo 2-Pin Power Connectors

    18 W. USB-C POWER BANK Alternative powering option is an external battery or power bank connected to USB-C port of the ScreenPort SDI Pro device. The compatibility requirement for the power bank is a 5V 3A power output. COMPUTER USB When used with a computer, you can use a USB connection to transfer data and power, so no additional power source is needed for ScreenPort SDI Pro operation.
  • Page 7: Getting Started

    GETTING STARTED Follow these steps to use ScreenPort SDI Pro connected via USB cable to an iOS device or Mac: 1. Install ScreenPort or QTAKE Monitor application on your iOS device. 2. Connect a power source to the ScreenPort SDI Pro device using a USB-C power connector or Lemo 2-pin power connector.
  • Page 8: Operation

    New devices ship with Access Point Mode enabled by default. To enable Access Point Mode on your existing ScreenPort SDI Pro device, tap SETUP in the ScreenPort app, then tap Network and set Access Point to ON. If you need to connect to an on-set Wi-Fi network, set Wi-Fi to ON instead. It will automatically turn Access Point off but will retain your settings for future use.
  • Page 9: Screenport App

    LIVE signal. During playback, meters will show the audio levels of the playback. METADATA If the SDI signal contains camera metadata, ScreenPort SDI Pro will extract it and display it in UI toolbars. Timecode and clip name are located in the bottom part of the screen. Camera and lens metadata is located in the top part of the screen.
  • Page 10: Delete

    Switching the INFO/FUNC button to function mode provides access to various functions of the ScreenPort app. SDI SOURCE This field identifies the connected camera. ScreenPort SDI Pro can extract timecode, clip name, and other camera and lens metadata from ARRI, Sony, Canon, Panasonic, and RED digital cinema cameras.
  • Page 11: Network

    QTAKE Monitor can display up to 4 views, and they can display different content. To set the active view to SDI input, tap the button in the top right corner and select ScreenPort SDI Pro. If the device is not listed, refer to the troubleshooting page.
  • Page 12: Record Sdi Input

    In addition to manual recording, some cameras send SDI record flags to initiate automatic recording. Refer to the Device Settings section to set the ScreenPort SDI Pro auto-record mode. SET IN/OUT RANGE Each clip in QTAKE Monitor can have multiple ranges to allow only selected parts of the media file to play.
  • Page 13: Firmware Update

    You will see the update progress via the playback slider. Your device will restart twice. TROUBLESHOOTING The following table provides instructions on solving the most common problems related to the use of ScreenPort SDI Pro. If your problem is not on the list, contact the manufacturer or your reseller. Problem Possible reason Solution Power LED does not light up.
  • Page 14: Important Safety Instructions

    COMPLIANCE If for import of ScreenPort SDI Pro to or its operation within any country other than Slovakia it is required to fulfill additional legal requirements than those provided by the manufacturer herein,...
  • Page 15: Copyright And Legal Notices

    COPYRIGHT AND LEGAL NOTICES ScreenPort SDI Pro is a trademark of IN2CORE s.r.o. All other trademarks are the property of their respective owners. August 21, 2023...
