Specification
CDN-2010B
Model
1/3" SONY Super HAD CCD
Pick up Element
Effective Picture Elements
NTSC:976(H)×494(V) PAL:976(H)x582(V)
(H×V)
Horizontal Resolution
700 TV Line
0.001 Lux/F1.2
Minimum Illumination
S/N Ratio
More than 52dB
Scanning System
2:1 interface
Synchronous System
Internal, Negative sync.
Auto Electronic Shutter
NTSC: 1/60s~1/100,000s, PAL: 1/50s~1/100,000s
Gama Characteristic
0.45
IR Distance
30 Meters (withØ 5x 36 PCS Infrared LED )
1Vpp, 75Ω
Video Output
Auto
Auto Gain Control
DC12V(+/-10%)/450mA
Power/Current
2.8-12mm Manual Zoom Lens
Ø 131x 93(H)
Dimension (mm)
800
Weight (g)
Storage Temperature
-30~+60℃ RH95% MAX
Operating Temperature
-10~+50℃ RH95% MAX
Packing List
No
Name
1.
Vandalproof
CDN-2010B
IR Dome Color Camera
2.
CDN-2010B
User Guide
II
Model
Number
1
1
Vandalproof IR Dome Color Camera
Notes:
Before providing power for the
please read this User Guide in detail!
Do not attempt to disassemble the camera. If the
camera can not work, please contact local
franchiser or our company.
camera,
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Summary of Contents for golmar CDN-2010B
- Page 1 Specification CDN-2010B Model 1/3" SONY Super HAD CCD Pick up Element Effective Picture Elements NTSC:976(H)×494(V) PAL:976(H)x582(V) (H×V) Horizontal Resolution 700 TV Line 0.001 Lux/F1.2 Minimum Illumination S/N Ratio More than 52dB Scanning System 2:1 interface Synchronous System Internal, Negative sync.
- Page 2 INTRODUCTION BRIEF OF PRODUCT CONNECTING Congratulations on your purchase of this product. * Sensor (CCD) This User Guide suits CDN-2010B product. We adopt the latest SONY technical of sensor and driver. The most Adopt SONY 1/3" CCD Sensor. Monitor Video...
