WheelchairManualCover_IB
12/4/12
10:37
17
22
6
1
20
7
3
Useful
21
18
Part Numbers
1
Right armrest
YK-024-1
2
Left armrest
YK-024-2
3
Right brake
YK-027-1
4
Left brake
YK-027-2
5
Nylon seat base
YK-016
6
Nylon seat back
YK-021
7
24" rear wheel complete with tyre
and bearing
YK025
8
Rear wheel bearing
YK-032
9
Rear wheel axle
YK-033
10 Front wheel
YK-023
11 Front wheel bearing
YK-034
12 Front fork
YK-035
13 Front wheel pivot bearing
YK-036
14 Right footplate complete
YK-012-1
15 Left footplate complete
YK-012-2
16 Heel strap (nylon)
HMA214
17 Handgrip (push handle)
YK-039
18 Arm rest release button
YK-040
19 Front post
YK-041
Page 3
2
5
19
4
13
15
16
14
12
10
20 Seat guide (rear)
YK-042
21 Front post guide
YK-045
22 Backrest folding hinge (Complete)
YK-048
23 Right footplate lock clip
(complete with spring)
YK-049
24 Left foot plate lock clip
(complete with spring)
YK-050
25 Brake lever handgrip
YK-051
26 Brake friction pad
YK-052
27 Footplate mounting pin
(set of 2 pins for one side)
YK-053
28 Backrest hinge lever( plastic parts)
YK-047
30 Lap belt
HMA213
Optional Extras
29 Anti tip bars (pair)
YK-001
Advertisement
Table of Contents
Summary of Contents for Harvest Healthcare HMS300B
- Page 1 WheelchairManualCover_IB 12/4/12 10:37 Page 3 Useful Part Numbers Right armrest YK-024-1 Left armrest YK-024-2 Right brake YK-027-1 Left brake YK-027-2 20 Seat guide (rear) YK-042 Nylon seat base YK-016 21 Front post guide YK-045 Nylon seat back YK-021 22 Backrest folding hinge (Complete) YK-048 24”...
- Page 2 It is very important that you se- curely tighten the lock nut after this adjustment and before use. The maximum user weight or mass for the HMS300B Self Pro- pel Wheelchair is 120Kg (18 3/4 Stone).
- Page 3 INTRODUCTION fig. 4. The HMS300B Wheelchair is quality checked The HMS300B Wheelchair is now ready for use. and tested before leaving the factory. However Fig 2. it is important you check that all parts are in-...
- Page 4 Bradmarsh Business Park feet whilst the chair is in motion or use. Rotherham S60 1BW - UK The maximum user weight or mass for the HMS300B T: +44(0)1709 377172 Self Propel Wheelchair is 120Kg (18 3 / 4 Stone). Do not exceed this limit! E: sale@harvesthealthcare.co.uk...
