Settler 600 Series MKII
C600 MKII Ranch - Freestanding
I600 MKII - Inbuilt
C600 MKII - Freestanding
INSTALLATION
&
OPERATING INSTRUCTIONS
Serial Number of Heater: ________________________ Model: ___________________
SETTLER
WOODHEATERS ARE AUSTRALIAN OWNED & MANUFACTURED
BY
SHAMIC SHEETMETAL
(AUST.) PTY. LTD.
PO BOX 8, KILSYTH, VIC. 3136
PH: 03 9737 5300
https://shamic.com
Revised: 16/12/2022
1
Printed: 16/02/2022
Advertisement
Table of Contents
Summary of Contents for Shamic Sheetmetal 600 MKII Series
- Page 1 C600 MKII - Freestanding INSTALLATION & OPERATING INSTRUCTIONS Serial Number of Heater: ________________________ Model: ___________________ SETTLER WOODHEATERS ARE AUSTRALIAN OWNED & MANUFACTURED SHAMIC SHEETMETAL (AUST.) PTY. LTD. PO BOX 8, KILSYTH, VIC. 3136 PH: 03 9737 5300 https://shamic.com Revised: 16/12/2022 Printed: 16/02/2022...
- Page 2 SAVE THESE INSTRUCTIONS INSTALLATION AND OPERATION INSTRUCTIONS Have your heater installed by a registered or licensed installer, and advise your insurers for inclusion in your household contents policy. In some states the installer is required to issue a certificate of compliance on the installation; - ensure you obtain this if applicable! COONARA SETTLER Woodheaters should not be modified in any way! Do not operate the heater with the door open for extended periods.
- Page 3 INSTALLATION INSTRUCTIONS - FREESTANDING MODELS ONLY Select the position of your heater carefully, taking into consideration all combustible materials in the roof; eg. ceiling joists, roof trusses, etc. Floor Protector/Hearth Determine flue location through the ceiling: Position the hearth correctly, then place the heater on the hearth so that the flue spigot on the heater is correctly aligned with the flue location from the ceiling.
- Page 4 INSTALLATION OF INBUILT MODELS ONLY The heater must only be installed in either a sound concrete or masonry fireplace, connected to a chimney, both of which must be inspected for soundness and thoroughly cleaned before Shamic the heater is installed, or the tested and approved Zero Clearance Box in conjunction with a triple skin flue system.
- Page 5 Installation using the Shamic Zero Clearance Box A minimum 575mm deep x 745mm wide x 18mm thick floor protector (compressed board) should be used under the appliance, a minimum 1000mm wide x 500mm deep x 36mm thick floor protector (compressed board) must be used in front of the appliance base when installing the appliance (see joint AS/NZS 2918:2018 3.3.2).
- Page 6 Installation Diagram – Zero Clearance Box Revised: 16/12/2022 Printed: 16/02/2022...
- Page 7 Firebox Internal Set Up Step 1. Install the top baffle plate, place both hands underneath the plate lift either the right or left hand side of the plate up so it is on an angle. Lift up over the locating tab on the side of the firebox then lift up the other side and push the plate to the back of the firebox.
-
Page 8: First Fire
FIRST FIRE YOUR HEATER HAS BEEN SPRAYED WITH HIGH TEMPERATURE PAINT. TO ENSURE THAT THE PAINT IS PROPERLY “CURED IN”, PLEASE FOLLOW THESE STEPS WHEN LIGHTING THE FIRST FIRE IN THE HEATER: • ENSURE THE AIR CONTROL SLIDE IS FULLY OPEN. •... -
Page 9: Operating Information
Operating Information Fuel Ignition: A supply of firelighters or newspapers. Kindling: 10 mm – 20 mm diameter light, split, pieces of dry wood. Start-up wood: 30 mm – 75 mm diameter medium size, split pieces of dry wood. “BURN ONLY HARDWOOD”. Starting a fire Fully open the air slide, lift the door handle upward and open the door slowly. - Page 10 Use of the fan Coonara heaters are fitted with a 3-speed fan for efficient distribution of warmth. Operating the fan in your wood heater is critical at all stages of use except at startup, where the follow steps apply: • When the fire has been underway for 30 minutes turn the fan on to low •...
-
Page 11: Replacement Parts
Preparing for a low (overnight) burn For an extended low burn ensure a maximum fuel load is placed into the heater, following the reloading procedure outlined previously. The greater the fuel load the longer the burn. After reloading close the door and leave the air inlet fully open (high) until the load is alight. The air inlet should then be turned down to the low setting. -
Page 12: Maintenance
Maintenance Paint surfaces After the curing process has taken place, little maintenance is required other than dusting off with a cotton cloth. Most marks can be buffed out with a cotton cloth without the need for retouching. NOTE: Do not use abrasive cleaners or harsh solvents (such as methylated spirits). -
Page 13: Door Adjustment
Door adjustment The door is unlikely to become misaligned unless it is knocked and attempts at adjustment may cause rather than solve a problem. Always consult your Coonara dealer before attempting any adjustment to the door. 1. Remove door by opening fully and lifting door up off the hinge. (Freestanding models require top panel to be propped up prior to lifting door). - Page 14 We recommend the use of a qualified service agent to perform fan maintenance for inbuilt models. Accessing the fan involves removal of the door and the fascia surround. If you wish to conduct this maintenance yourself, please contact Shamic Sheetmetal (Aust) Pty Ltd on phone (03) 9737 5300 for detailed instructions.
- Page 15 Baffle plate removal The baffle plate is held in place with four locating tabs – 2 either side, front and rear of the firebox. WARNING: ALLOW THE HEATER TO COOL IF HOT BEFORE ATTEMPTING BAFFLE PLATE REMOVAL. Cast Iron Baffles Removal of firebricks may be necessary if fitted.
- Page 16 TABLE 1: FIREWOOD SPECIES AND THEIR PROPERTIES Firewood Forest Type Heat Density Splitting Ignitability Coals Sparks Avail. Species Avail. (Dry Air) Per Unit Ib/ft3/ Volume Kg/m3 Mallee Roots Mallee Difficult Poor Excellent Good Belah, Buloke Mallee 70 / Good Poor Excellent Limited Box-Ironbark...
-
Page 17: How To Make A Warranty Claim
6. Provide the details that your retailer requests to complete a Warranty Claim Form. This must include the heater model, serial number and installation compliance certificate, if applicable in your State. 7. Your retailer will forward your claim to Shamic Sheetmetal (Aust) Pty Ltd, the manufacturer of the above heater brands 8. - Page 18 Revised: 16/12/2022 Printed: 16/02/2022...
- Page 19 See exclusions and qualifications below for further information on product coverage. WARRANTY: Shamic Sheetmetal (Aust) Pty. Ltd, warrants the firebox to be free of defects in materials and workmanship of a period of ten (10) years from the date of purchase.
