- Page 1 CS-19 Conversion Set Juno HT.1 1:72 Airbus H135 Scale...
- Page 2 Two small plasticard strips Step made from Plastic rod Aerial stays Airbus H135 Juno HT.1 Drg No: CS-019 -01 Drawn: Gary Madgwick Copyright Gary Madgwick 1/72 Scale @ A5 12/08/2021 Air-Graphic Models 2022...
- Page 3 Cabin Assembly Kit part Kit parts Kit floor with seat risers sanded off. Optional kit/resin parts Two thin plasticard strips which were Sanded right down to almost nothing. *Note, 2 small plasticard strips with hes in on end. Kit part Kit parts.
- Page 4 Cockpit Continued Above: Front cabin seats are black with light grey cushions. Note* two bars behind seats which will need to be made Above: Rear seats, note cabin colour From sprue, wire or plastic rod. These fit into the strip behind and seat colours.
- Page 5 Fuselage Modifications Area cut back Kit clear parts Part 9 cabin roof Instrument panel position Kit part...
- Page 6 Tail detailing Tail as per kit parts Apart from part 15 Above right & below left: Completed fuselage and Tail boom skid. tail during clean up process. Modification to Fin top. Note, tail planes do not have the vertical Planes. Remove these...
- Page 7 Final Detailing Step made from plastic rod. Note square end plates. Note* Bear claw Part No 18 Not shown fitted for clarity Note, tail planes should not be fitted. Note, tail planes should Not be fitted. Plasticard aerial Kit part Thin plastic rod stays to tail aerial...
- Page 8 • Not suitable to children under 14 years of age. Thank you for purchasing this Air-Graphics product which forms part of a range of accessories, conversion sets, decals & kits all to 1/72 Scale.
