Summary of Contents for Eluktronics LPP G2
- Page 1 User Manual...
-
Page 2: What's Included
LPP G2 User Manual Please read all instructions before using the LPP G2. 01 What's Included: 1. LPP G2 Liquid Cooling Unit 2. Liquid Tube Pipes with Mag-Valve Connectors* 3. DC to DC Power Cord x 1 4. Drain Tool x 1 5. - Page 3 02 Prepare your LPP G2 1. Read the quick guide or user manual before operating the LPP G2. 2. Verify the connectors are attached to the liquid tubes firmly. 3. Place the LPP G2 on a flat and level surface.
- Page 4 3. Connect your included laptop power adapter to the LPP G2 DC port (Figure 1). 4. Connect LPP G2 DC Cable to the laptop’s DC port (Figure 2). Please, don't power on your laptop just yet. Connect laptop’s DC port...
- Page 5 Horizontally insert the liquid tubes into the laptop. The connector will feel sturdy and in place if performed properly. As stated above, you will hear a light" click" sound. Note: Please pay attention to the following information regarding safe use of the liquid tubes. Please don't apply weight or objects on the cable...
- Page 6 04 Filling the LPP G2 1. Open the lid on the LPP G2 unit. Add distilled water to the MAX level indicator. 2. After filling in distilled water, hold the power button located on the LPP G2 for 4-5 seconds. The power button will glow in purple indicating it is entering in to “Liquid Injection Mode”.
- Page 7 06 Disconnect your LPP G2 1. Disconnect via the Eluktronics Control Center under the "Liquid Propulsion Package (LPP) Control" tab. 2. Press the power button to turn off your LPP G2. 07 Disconnect the Liquid Tubes To disconnect the LPP G2: 1.
- Page 8 08 Changing liquid or draining for travel 1. To ensure water clogs do not happen, please change the distilled water periodically. 2. When unplugging the water tubes, please always check for any water leakage and clean immediately with a towel if leakage occurs.
-
Page 9: Product Overview
09 Product Overview Left side view Front side view Right side view Back side view Power Button / LED Indicator* Power-IN (from wall) Power-OUT (to laptop) Mag-Valve (liquid ports) Top side view RGB Cooling Fan Liquid Tank (MAX/LOW level indicator marks) Liquid Tank Cap/Fill Port LED Color Codes... -
Page 10: Troubleshooting Guide
Please ensure the liquid tank cap is completely screwed down before trying this. If the LPP G2 is blinking orange OR you see a "Flow State Error" in the Liquid Propulsion section of the Eluktronics Control Center, press the power button on the LPP G2 to turn it off. - Page 11 2. Please, check all ports in case of liquid leakage before powering up the device. 3. Any changes or modifications not expressly approved by Eluktronics Inc. for compliance could void your warranty. Contact our support team if you need any assistance or have questions that weren't answered in our quick guide, this manual, or how-to videos online.
-
Page 12: Regulations Information
RF exposure compliance. CAUTION: Any hardware changes or modifications not expressly approved by Eluktronics Inc. could void the included warranty of both the LPP G2 and laptop if damage is caused.
