Transform TRANSF075 Owner's Manual

3/4 hp high torque garbage disposer

Table of Contents

Quick Links

Download this manual

3/4 HP

HIGH TORQUE GARBAGE DISPOSER

NOTE: This product may require approval of the relevant regulators and/or the sewerage system operator. Waste disposal must be installed according

to AS/NZS 3500.2 requirements.

WMTS-028 / WM-022588

220-240V AC / 50-60Hz / 2.7 A / 560W

IAPMO R&T OCEANA

OWNER'S MANUAL

Rev. 20191114

# TRANSF075

Table of Contents

Need help?

Do you have a question about the TRANSF075 and is the answer not in the manual?

Questions and answers

Summary of Contents for Transform TRANSF075

Page 1 NOTE: This product may require approval of the relevant regulators and/or the sewerage system operator. Waste disposal must be installed according to AS/NZS 3500.2 requirements. WMTS-028 / WM-022588 220-240V AC / 50-60Hz / 2.7 A / 560W IAPMO R&T OCEANA OWNER’S MANUAL Rev. 20191114 # TRANSF075...
Page 2: Table Of Contents
. in place to reduce the risk of objects falling into the disposer . WARNING: Switch off or unplug the appliance before attempting SAVE THESE INSTRUCTIONS to free a jammed rotor with an implement . TRANSF075...
Page 3: Warranty
Warranty FIVE (5) YEAR LIMITED WARRANTY A thorough inspection must be made before installation and any damage must be promptly reported . We will not be liable for failures or damage that could have been discovered or avoided by proper inspection and testing prior to installation . ACM Pty Limited warrants this product to be free from defects in materials or workmanship for five (5) years from the date of purchase.
Page 4: Pre-Installation
Flange ring Screw Ring tool Includes: NOTE: This waste disposer is intended to be plugged Supporting plate into a grounded receptacle that is controlled by a Top supporting ring (with 3 screws) dedicated switch (usually wall mounted) . Cushion mount TRANSF075...
Page 5: Installation
Installation REMOVAL OF OLD UNIT CAUTION: Risk of electric shock . Turn off electric power at fuse box or circuit breaker before removing old unit . General instructions - your model may vary . NOTE: CAUTION: Be sure to support the disposer when removing the mounting ring or it may fall .
Page 6: Installation Of The Mounting Assembly
(see Fig. 8b). - Tighten the 3 top supporting ring screws sequentially until the flange is very securely fastened to the sink (see Fig. 8c). Top supporting Fig . 8b Fig . 8c ring screw TRANSF075...
Page 7: Attaching Discharge Elbow
Installation (continued) If at any time the bottom supporting ring becomes disengaged from the body of the waste disposer, then: Slot 1 . Align the slot in the bottom supporting ring with tab on the waste disposer body . 2 . Lower the bottom supporting ring and make the slot fit in the tab .
Page 8: Connecting Disposer To Mounting Assembly
Insert a screw driver into the tool mount for added leverage, if needed (see Fig 13 and 13a) . Fig.13 Fig.13a If you are unable to fully engage the bottom supporting ring, release and lower the waste disposer (see Fig . 13b) . Fig. 13b TRANSF075...
Page 9: Dishwasher Connection
Installation (continued) Fig. 13c Turn the bottom supporting ring 1/3 of a turn counter-clockwise and repeat the mounting procedure described above (see Fig 13c) . 1/3 turn - Connect the bottom of the elbow to the trap by tightening the slip nut (Fig .
Page 10: Operation
. GENERAL INSTALLATION DIMENSIONS 22 cm SINGLE BOWL DOUBLE BOWL CENTER OUTLET DOUBLE BOWL END OUTLET approx 26 cm 17 cm approx 26 cm approx 26 cm 38 .4 cm 8 .7 cm 14 .5 cm TRANSF075...
Page 11: Troubleshooting
Troubleshooting Before seeking repair or replacement, we recommend that you review the following: Problem Solution The disposer is making loud noises . Other than the noises during grinding of small bones and fruit pits, these are usually caused by accidental entry of a spoon, bottle cap or other foreign objects .
Page 12: Service Parts
Removable splash guard QHG114 Includes: Sink flange Rubber sink flange gasket QHG115 Flange ring Ring tool Includes: Supporting plate QHG117 Top supporting ring (with 3 screws) Cushion mount Bottom supporting ring QHG112 Includes: Elbow gasket Discharge elbow QHG120 Flange elbow Screw TRANSF075...
Page 13 ACM Pty Limited 47 Stonedon Drive, East Tamaki, Auckland 2013 New Zealand www.acmptyltd.com Customer Service Hotline Telephone : 0800 744 794 - 8.00am – 4.30pm Made in China...
