Summary of Contents for DB Drive WDX GO Series
- Page 1 WDX8G0.4 | WDX10G0.4 | WDX12G0.4 USER MANUAL Due to continuous improvement of the product, specifications are subject to change without notice.
- Page 2 Congratulations on your purchase of a DB Drive state-of-the-art subwoofer. Your selection of a DB Drive car audio product indicates a true appreciation of fine musical reproduction. Whether adding to an existing system or including your DB Drive subwoofer in a new system, you are certain to notice immediate performance benefits.
- Page 3 PRODUCT FEATURES • High Temperature Voice coil • Stamped Cast basket • Reinforced paper cone • Rubber gasket trim ring • Double stitched foam surround • Large gauge compression terminals • Dual poly-cotton dampeners • Protective magnet cover WDX8G0.4 WDX10G0.4 WDX12G0.4 Structure: 8”...
- Page 4 PRODUCT DIMENSIONS Frame Diameter Mounting Depth Cutout Diameter WDX8G0.4 WDX10G0.4 WDX12G0.4 8.42 in. 10.70 in. 12.40 in. Frame Diameter: 214 mm 272 mm 315 mm 4.62 in. 5.84 in. 6.51 in. Mounting Depth: 117.50 mm 148.50 mm 165.50 mm 6.90 in. 9.07 in.
- Page 5 RECOMMENDED ENCLOSURES Sealed Vented ENCLOSURES: WDX8G0.4 WDX10G0.4 WDX12G0.4 6.90 in. 9.07 in. 10.85 in. Woofer Cut-out: (175.38 mm) (230.57 mm) (275.79 mm) 4.62 in. 5.84 in. 6.51 in. Mounting Depth: (117.50 mm) (148.50 mm) (165.50 mm) 0.7 cu ft. 0.8 cu ft 1.4 cu ft.
- Page 6 DVC WIRING CONFIGURATIONS You can change the wiring configuration of your speakers ( Series, Parallel and Series / Parallel ) to match the impedance loads that maximize the power output of your amplifier. Wiring the same woofer or multiple woofers in these three different wiring configurations will result in different impedance loads. Series: Is the method of wiring of alternate positive with negative terminals ( string method ) ( Illustration below ).
- Page 7 NOTES...
- Page 8 (1) year. This warranty applies to the original purchaser only. DB Drive™ will either repair or replace (as its option) any unit that has been found to be defective and under warranty provided the defect occurs within the one (1) year warranty period.
