Owner's Manual
Model: UTL-60-7-TSC (2152366)
General Information
Thank you for purchasing this product. The purpose of this
manual is to assist you in operating and maintaining your utility
cart sprayer. Please read it carefully, as it furnishes information
which will help you achieve years of trouble-free operation.
Warranty/Parts/Service
For home usage, products are warranted for one year from date
of purchase against manufacturer or workmanship defects.
Commercial users have a 90 day warranty.
Your authorized dealer is the best source of replacement parts
and service. To obtain prompt, efficient service, always
remember to give the following information...
- Correct Part Description and/or part number.
- Model number/Serial number of your sprayer.
Part descriptions and part numbers can be obtained from the
illustrated parts list section(s) of this manual.
Whenever you need parts or repair service, contact your
distributor/dealer first. For warranty work, always take your
original sales slip, or other evidence of purchase date, to your
distributor/dealer.
(60 Gallon Utility Sprayer w/ 7-Nozzle Boom Assembly)
Technical Specifications
• 60 Gallon Corrosion-Resistant Polyethylene Tank
• Deluxe Pistol-Grip Handgun w/25 Ft. Hand Gun Hose
• 7-Nozzle Boom Assembly - 140" Spray Coverage
• Adjustable Boom Height
• 12 Volt, 3.8 GPM Diaphragm Pump
Assembly
The sprayer is fully assembled at the factory. The only
assembly necessary is to thread the pressure gauge in
place, and to hook up the wiring to an existing 12 volt power
source.
The red wire of the two wire set must be connected to the
positive post on the battery or the "Hot" connection on a
switch or to the ammeter. The brown wire may be grounded
or connected to the negative battery post. Install all parts of
the boom assembly to the boom brackets as shown in the
exploded view drawing. The in-line switch turns the unit on
and off. Running the pump dry will not harm the pump for
short periods of time.
Read the operating instructions and then run the sprayer
using only water for testing. When everything tests all right,
add the desired chemical mixture and water combination
and start the spraying operation.
