- Page 1 ESP-07S User Manual REV:1.0 2016.3.15...
- Page 2 ESP-07S User Manual FCC STATEMENT This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference. (2) This device must accept any interference received, including interference that may cause undesired operation.
-
Page 3: Table Of Contents
ESP-07S User Manual Table Of Contents 1. Preambles ................................2 1.1. Features ............................... 3 1.2. Parameters ............................4 Pin Descriptions ..............................5 2.1. Interfaces ............................. 6 2.2. Pin Mode .............................. 8 2.3. Antenna interface ..........................8 Package information and OEM installation method ..................9 3.1. -
Page 4: Preambles
ESP-07S User Manual 1. Preambles ESP-07S WiFi module is developed by AI-Thinker Co.,Ltd, core processor ESP8266 in smaller sizes of the module encapsulates Tensilica L106 integrates industry-leading ultra low power 32-bit MCU micro, with the 16-bit short mode, clock speed support 80 MHz, 160 MHz, supports the RTOS, integrated Wi-Fi MAC/BB/RF/PA/LNA, on-board antennas. -
Page 5: Features
ESP-07S User Manual Features 1.1. • 802.11 b/g/n • Integrated low power 32-bit MCU • Integrated 10-bit ADC • Integrated TCP/IP protocol stack • Integrated TR switch, balun, LNA, power amplifier and matching network • Integrated PLL, regulators, and power management units •... -
Page 6: Parameters
ESP-07S User Manual Parameters 1.2. Table 1 below describes the major parameters. Table 1 Parameters Categories Items Values 802.11 b/g/n WiFi Protocles WiFi Paramters 2.4GHz-2.5GHz (2400M-2483.5M) Frequency Range UART/HSPI/I2C/I2S/Ir Remote Contorl Peripheral Bus GPIO/PWM 3.0~3.6V Operating Voltage Average value: 80mA... -
Page 7: Pin Descriptions
ESP-07S User Manual Pin Descriptions There are altogether 16 pin counts, the definitions of which are described in Table 2 below. Figure 2 ESP-07S pinout Table 2 ESP-07S pin description Pin number Pin name function Reset module A/d conversion result. Input voltage range 0~1V, value range: 0~1024 Chip enable pin. -
Page 8: Interfaces
ESP-07S User Manual GPIO15 GPIO15; MTDO; HSPICS; UART0_RTS GPIO2; UART1_TXD GPIO2 GPIO0 GPIO0 GPIO4 GPIO4 GPIO5 GPIO5 RXD0 UART0_RXD; GPIO3 TXD0 UART0_TXD; GPIO1 Interfaces 2.1. Table 3 Descriptions of Interfaces Description Interface Pin Name IO12(MISO), IO13(MOSI) SPI Flash , display screen, and MCU can be connected using HSPI... - Page 9 ESP-07S User Manual products. IO14(SCL), I2C interface can be used to connect external sensor products and IO2(SDA) display screens, etc. Devices with UART interfaces can be connected with the module. Downloading: U0TXD+U0RXD or GPIO2+U0RXD Communicating: UART0: U0TXD, U0RXD, MTDO (U0RTS), MTCK...
-
Page 10: Pin Mode
2.3. Antenna interface ESP-07S Modules through the IPEX interface to connect to external antenna. The antenna must be in line with the 802.11g/802.11b IEEE standard, and the antenna parameters are shown in the following table： Table 5 Antenna parameters... -
Page 11: Package Information And Oem Installation Method
Package information and OEM installation method The external size of theESP-07S WiFi module is 16mm*17mm*3mm, as is illustrated in Figure 4 below: Figure 3 Top View of ESP-07s WiFi Module Figure 4 Dimensions of ESP-07s WiFi Module Table 5 Dimensions of ESP-07s WiFi Module... -
Page 12: Package Information
3.2. Using ESP-07S module Please reference in front of the package information in the Layout on the main board for OEM factory .Please pay more attention Module's direction and the antenna close to the edge of board is better ,the Components and layout should not be on the bottom of antenna then soldering the module.when the module be... -
Page 13: Absolute Maximum Ratings
Supply voltage 4.2.AT commend Testing 1.Hardware connection As shown in Figure 7, ESP-07S via a USB to TTL Tool connected to the computer, software tool through the serial port on the computer can be AT instruction test Figure 7 ESP-07S connect with computer Shenzhen Ai-Thinker Technology Co., Ltd... -
Page 14: At Commend
ESP-07S User Manual 4.3.AT commend Espressif AT instruction set functions and methods of use AT commands set is divided into: Basic AT commands, WiFi related AT commands, TCP / IP AT 4.3.1.AT Command Description Table 8 Each Command set contains four types of AT commands. - Page 15 ESP-07S User Manual Table9 basic AT commands AT – Test AT startup The type of this command is "executed". It's used to test the setup function of your wireless WiFi module. Shenzhen Ai-Thinker Technology Co., Ltd http://www.ai-thinker.com...
- Page 16 ESP-07S User Manual AT+RST – Restart module The type of this command is "executed". It’s used to restart the module. AT+GMR – View version info This AT command is used to check the version of AT commands and SDK that you are using, the type of which is "executed".
- Page 17 ESP-07S User Manual ATE – AT commands echo This command ATE is an AT trigger command echo. It means that entered commands can be echoed back to the sender when ATE command is used. Two parameters are possible. The command returns "OK"...
