HEAVY DUTY ELECTRIC FRYERS

FRYER MUST BE KEPT CLEAR OF COMBUSTIBLES AT ALL TIMES

Do not store or use gasoline or other flammable vapors and liquids in the vicinity of

this or any other appliance.

Improper installation, adjustment, alteration, service or maintenance can cause

property damage, injury or death. Read the Installation, Operating and Maintenance

Instructions thoroughly before installing or servicing this equipment

Initial heating of oven may generate smoke or fumes and must be done in a

well-ventilated area. Overexposure to smoke or fumes may cause nausea or

dizziness.

This equipment has been engineered to provide you with year-round dependable service when used

according to the instructions in this manual and standard commercial kitchen practices .

(214) 421-7366 Phone

(914) 576-0605 Fax

INSTALLATION AND OPERATING INSTRUCTIONS

Models: TSHEF-15Si, TSHEF-30Ti

INTENDED FOR OTHER THAN HOUSEHOLD USE

RETAIN THIS MANUAL FOR FUTURE REFERENCE

FOR YOUR SAFETY

WARNING

Tri-Star Manufacturing Company

1307 N. Watters Rd. #180

Allen, TX 75013

P/N 8822395 8/13

(800) 462-1340 Toll Free

www.Tri-StarMfg.com

Table of Contents

Need help?

Do you have a question about the TSHEF-15Si and is the answer not in the manual?

Questions and answers

Summary of Contents for Tri-Star TSHEF-15Si

Page 1 INSTALLATION AND OPERATING INSTRUCTIONS HEAVY DUTY ELECTRIC FRYERS Models: TSHEF-15Si, TSHEF-30Ti INTENDED FOR OTHER THAN HOUSEHOLD USE RETAIN THIS MANUAL FOR FUTURE REFERENCE FRYER MUST BE KEPT CLEAR OF COMBUSTIBLES AT ALL TIMES FOR YOUR SAFETY Do not store or use gasoline or other flammable vapors and liquids in the vicinity of this or any other appliance.
Page 2: Table Of Contents
Maintenance ....... 7 Warranty ........18 Tri-Star Manufacturing takes pride in the design and quality of our products. When used as intended and with proper care and maintenance, you will experience years of reliable operation from this equipment. To ensure best results, it is important that you read and follow the instructions in this manual carefully.
Page 3 3" breathing space behind fryer. WARNING: A factory authorized agent should handle all maintenance and repair. Before doing any maintenance or repair, contact Tri-Star Manufacturing. WARNING: Never clean any electrical unit by immersing it in water. Turn off before cleaning surface.
Page 4: General Information
CAUTION: This product when stacked has more than one power supply connection point. Disconnect all power supplies before servicing. CAUTION: Suitable for installation on combustible floor when installed with legs or casters provided. WARNING: SHOCK HAZARD - Do not open any panels that require the use of tools. IMPORTANT FOR FUTURE REFERENCE Please complete this information and retain this manual for the life of the equipment.
Page 5: Description
3. Is power switch “ON” and pilot light glowing? 4. Check rating label. Are you operating unit on proper voltage? If the above checks out and you still have problems, call an Tri-Star authorized service agency. 3. DESCRIPTION Electric Fryers: These electric units are designed for countertop operation.
Page 6: Thermostat Calibration
5. THERMOSTAT CALIBRATION Checking Thermostat Calibration: The fryer thermostat is carefully calibrated at the factory so that dial settings match actual frying compound temperatures. Field re-calibration is seldom necessary unless the unit has been mishandled in transit or abused. Re-calibration should not be resorted to unless considerable experience with cooking results definitely proves that the control is not maintaining the temperature to which the dial is set.
Page 7: Maintenance
7. MAINTENANCE Fill Fry Tank: Fill the fry tank half way between the MAX and MIN marks on the tank with approximately 15 lbs. of liquid or melted frying compound. Do not fill past the MAX. NOTE: This fryer is not equipped with a melt cycle option. Air holes caused when packing solid frying compound into the fryer can cause hot spots on the heating element sheath, resulting in momentary overheating of some of the frying compound and premature frying compound breakdown.
Page 8: Cleaning
8. CLEANING 1. The frequency of cleaning should depend on the load conditions. Set a definite cleaning schedule corresponding to how hard the kettle is used. Cleaning should be done at least once a week. Turn the thermostat to “OFF” and allow unit to cool down. Lift the elements to drain position.
Page 9: Specifications
SPECIFICATIONS...
Page 10: Wiring Diagrams
WIRE VOLTS WATTS AMPS WIRE MODEL # VOLTS WATTS AMPS WIRE VOLTS WATTS AMPS WIRE TSHEF-15Si 5700 23.8 4280 20.6 TSHEF-30Ti 11400 47.6 8560 41.2 TSHEF-15Si- Wire sizes listed above are for reference only. Check local 5700 27.5 codes or the National Electrical Code for sizes to be used.
Page 11 CHECK DATA PLATE & CONNECT TO 208 OR 240V AS INDICATED CHECK DATA PLATE & CONNECT TO 208 OR 240V AS INDICATED MODEL # VOLTS WATTS AMPS WIRE VOLTS WATTS AMPS WIRE MODEL # VOLTS WATTS AMPS WIRE TSHEF-30Ti-230 11400 55.0 TSHEF-30Ti 11400...
Page 12: Troubleshooting Guide
11. TROUBLESHOOTING GUIDE Possible Cause Problem Excessive and premature foaming. Greasy food/excessive frying compound absorption. “Objectionable” odor or flavor of frying compound. “Objectionable” flavor of fried food. Excessive smoking of frying compound. Excessive darkening of frying compound. Frying compound won’t hold heat.
Page 13 12. SUGGESTED TEMPERATURES & TIMES CONTROL CONTROL TIME IN TIME IN FOOD SETTING FOOD SETTING MINUTES MINUTES (FAHRENHEIT) (FAHRENHEIT) DOUGHNUTS SEAFOOD Cake Type 375° 1 ½ - 2 Fish Cakes 350° 2 - 3 Yeast Raised 375° 2 - 2 ½ Clams 350°...
Page 14: Replacement Parts
13. REPLACEMENT PARTS CONTROL HEAD (Models: TSHEF-15Si & HEF-30Ti) Item P/N Description Item Description CONTROL HEAD, ELECTRIC 218100-95 64285901 CLAMP BULB FRYER W/A 1439729 HEATING UNIT ASSEMBLY 8944100 CLIP LEAD 13801-00 SWITCH, HI-LIMIT 8837018 LABEL RESET 8130000 8-32 X 3/8 TYPE T...
Page 15 BAFFLE, INTERIOR 8415500 WING NUT 10-32 S/S 21810040 DOOR ELECTRIC FRYER 89670-00 BUSHING, SNAP HEYCO .5" I.D. 2065852 LOGO, TRI-STAR 3" CAST 21810010 FAT CONTAINER AY 43813103 LABEL, WRNG, HOT SURFC 3101230 BASKET, 1/2 SIZE 43813149 LABEL, WRN HOT SURF...
Page 16 LABEL, WRN HOT SURF (FRNCH) 89785-00 BUSHING, 1" SNAP, HEYCO 43813103 LABEL, WRNG, HOT SURFC 8415500 WING NUT 10-32 S/S 2065852 LOGO, TRI-STAR 3" CAST 21810285 HEAD SUPPORT, INSIDE ASSY. 21810040 DOOR ELECTRIC FRYER 21810275 HEAD SUPPOR, OUTSIDE ASSY. 21828038...
Page 17 SCREW, 10-32x1/2, TYPE AB 2901051 CARTON, RSC 39.25X19.87X20.18 21810023 BRACKET HANDLE 21810010 FAT CONTAINER AY 21810022 ELEMENT HANDLE 2065852 LOGO, TRI-STAR 3" CAST 8141400 8-32 x 1/2 MS 8408300 #8-32 HEX NUT, KEPS, NI 84104-00 NUT,HEX, 8-32 S/S 8825300 DECAL, LEG 22295117...
Page 18 SCREW, MACH, 6-32 X 1/4" LG. 21810010 FAT CONTAINER AY 21810040 DOOR ELECTRIC FRYER 21810150 CONTROL AY. 208/240 °C 2065852 LOGO, TRI-STAR 3" CAST 21810096 COVER HEAD 1305612 SWITCH, ROCKER 20 AMP 8170700 SCREW, 10-32x1/2, TYPE AB 43813103 LABEL, WRNG, HOT SURFC...
Page 19 NOTES:...
Page 20: Warranty
TRI-STAR shall not be liable whether in contract or in tort or under any other legal theory, for loss of revenue or profit, or for any substitute use or performance, or for incidental, indirect, special or consequential damages, or for any other loss or cost of similar type.
