Summary of Contents for HANNspree Hanns.G HS221H
- Page 1 Questo manuale d’istruzione è fornito da trovaprezzi.it. Scopri tutte le offerte per Hannspree HANNS.G HS221HPB o cerca il tuo prodotto tra le migliori offerte di Monitor HS221H HS241H HS271H HSG1287 HSG1288 HSG1289 OSD[V6.1]...
- Page 2 User’s Manual OSD[V6.1] Before operating the monitor, please read this manual thoroughly. This manual should be retained for future reference. This device complies with requirement of EMC directive 2004/108/EC with regard to Electromagnetic Compatibility, and 2006/95/EC and 93/68/EEC with regard to Low Voltage directive.
- Page 3 User’s Manual Congratulations! This product is TCO Certified – for Sustainable IT TCO Certified is an international third party sustainability certification for IT products. TCO Certified ensures that the manufacture, use and recycling of IT products reflect environmental, social and economic responsibility. Every TCO Certified product model is verified by an accredited independent test laboratory.
- Page 4 User’s Manual RECYCLING INFORMATION We, the Hanns.G care very much about our environment protection strategy and firmly believe that it helps us have healthier earth via appropriate treatment and recycling of industrial technology devices at the end-of-life. These devices contain recyclable materials, which can be re-decomposed and re-integrated into brand-new marvels.
-
Page 5: Table Of Contents
User’s Manual TABLE OF CONTENTS SAFETY NOTICE ....................6 PRECAUTIONS....................6 SPECIAL NOTES ON LCD MONITORS ............7 BEFORE YOU OPERATE THE MONITOR ............8 FEATURES......................8 CHECKING THE CONTENTS OF THE PACKAGE ........8 INSTALLATION INSTRUCTIONS ..............9 POWER....................... 9 SETTING THE MONITOR ON THE WALL .......... -
Page 6: Safety Notice
User’s Manual SAFETY NOTICE 1. The changes or modifications not expressly approved by the party responsible for compliance could void the user's authority to operate the equipment. 2. Shielded interface cables and AC power cord, if any, must be used in order to comply with the emission limits. -
Page 7: Special Notes On Lcd Monitors
User’s Manual SPECIAL NOTES ON LCD MONITORS The following symptoms are normal with LCD monitor and do not indicate a problem. Due to the nature of the fluorescent light, the screen may flicker during initial use. Turn off the • Power Switch and then turn it on again to make sure the flicker disappears. -
Page 8: Before You Operate The Monitor
User’s Manual BEFORE YOU OPERATE THE MONITOR FEATURES Model: HS221H HS241H HS271H Size: 54.6cm/ 21.5” 60cm/ 23.6” 68.6cm/ 27” Wide Screen TFT Color LCD Monitor • Crisp, Clear Display for Windows • ® EPA ENERGY STAR • GP Green Product •... -
Page 9: Installation Instructions
User’s Manual INSTALLATION INSTRUCTIONS HS221 HS241 / HS271 INSTALL REMOVE INSTALL REMOVE Figure.1. Installing and Removing the Base INSTALLATION: 1. Align the monitor with the opening in the base. 2. Note that the longer section of the base points forward. 3. -
Page 10: Setting The Monitor On The Wall
User’s Manual SETTING THE MONITOR ON THE WALL DISSEMBLING THE STAND BASE: 1. Disconnect all the cables and cords from the Monitor to prevent breakage. 2. Carefully place the Monitor face down on a soft and flat surface (blanket, foam, cloth, etc) to prevent any damage to the Monitor. -
Page 11: Making Connections
User’s Manual MAKING CONNECTIONS HS221H CONNECTING TO A PC Turn off your computer before performing the procedure below. 1. Connect one end of the VGA cable to the back of the monitor and connect the other end to the computer’s VGA port. 2. - Page 12 User’s Manual HS241H / HS271H CONNECTING TO A PC Turn off your computer before performing the procedure below. 1. Connect one end of the VGA cable to the back of the monitor and connect the other end to the computer’s VGA port. 2.
-
Page 13: Adjusting The Viewing Angle
User’s Manual ADJUSTING THE VIEWING ANGLE For optimal viewing it is recommended to look at the full face of the monitor, then adjust the • monitor’s angle to your own preference. Hold the stand so you do not topple the monitor when you change the monitor’s angle. •... -
Page 14: Operating Instructions
User’s Manual OPERATING INSTRUCTIONS GENERAL INSTRUCTIONS HS221H Press the power button to turn the monitor on or off. The other control buttons are located on the front panel of the monitor (See Figure 5). By changing these settings, the picture can be adjusted to your personal preferences. - Page 15 User’s Manual HS241H / HS271H Press the power button to turn the monitor on or off. The other control buttons are located on the front panel of the monitor (See Figure 6). By changing these settings, the picture can be adjusted to your personal preferences.
-
Page 16: Front Panel Control
User’s Manual FRONT PANEL CONTROL Power Button: • Press this button to switch ON/OFF of monitor’s power. Power Indicator: • HS221H Green — Power On mode. Flicker — Power Saving mode. HS241H / HS271H Green — Power On mode. Orange — Power Saving mode MENU / RETURN: •... - Page 17 User’s Manual 4. Change Preset Mode: [The availability of this function depends upon the selected model] Press【MENU】key for 3 seconds to select one of the following modes「PC」,「MOVIE」, 「GAME」,「ECO」. Default is「PC」. Resolution 640×400@70Hz ↔ 720×400@70Hz 640×400@85Hz ↔ 720×400@85Hz 640×480@60Hz ↔ 720×480@60Hz 1024×768@70Hz ↔...
-
Page 18: How To Adjust A Settings
User’s Manual HOW TO ADJUST A SETTINGS BRIGHTNESS/ CONTRAST Adjust the brightness value of the display according to your preference. Select「BRIGHTNESS」option to adjust the BRIGHTNESS brightness value. Adjust the contrast value of the display according to your preference. Select「CONTRAST」option to adjust the contrast CONTRAST value. - Page 19 User’s Manual display, which does not ensure the image is shown as is or in initial scale. 「FIT」 indicates scaling by the proportion of original images, which may cause the screen showing black bands. [The availability of this function depends upon the selected model] Select the 「H-POSITION」...
- Page 20 User’s Manual the OSD. Enter the option and adjust the level. Select 「OSD TIME-OUT」option to set the OSD time out from OSD TIME-OUT 10 to 100 seconds. Enter the option and adjust the level. To choose the color combination of the OSD window, select 「OSD COLOR」...
-
Page 21: Plug And Play
User’s Manual PLUG AND PLAY Plug & Play DDC2B Feature This monitor is equipped with VESA DDC2B capabilities according to the VESA DDC STANDARD. It allows the monitor to inform the host system of its identity and, depending on the level of DDC used, communicate additional information about its display capabilities. -
Page 22: Technical Support (Faq)
User’s Manual TECHNICAL SUPPORT (FAQ) Q & A FOR GENERAL PROBLEMS PROBLEM & QUESTION POSSIBLE SOLUTION *Check if the Power Switch is in the ON position. Power LED is not on *Power Cord should be connected. *Check if the PC system is Plug & Play compatible. *Check if the Video Card is Plug &... - Page 23 User’s Manual INPUT as a PC option, and make sure PC audio output cable is connected to monitor’s LINE IN port(or AUDIO IN port). [For HDMI Input only] Addendum related to Windows 7/Windows 8 When you encounter display problem under Windows 7/Windows 8, you need to do the following: 1.
-
Page 24: Error Message & Possible Solutions
User’s Manual ERROR MESSAGE & POSSIBLE SOLUTIONS CABLE NOT CONNECTED: 1. Check that the signal-cable is properly connected, if the connector is loose, tighten the connector’s screws. 2. Check the signal-cable’s connection pins for damage. INPUT NOT SUPPORT : Your computer has been set to unsuitable display mode, set the computer to display mode given in the following table. - Page 25 User’s Manual 1360×768 @60Hz 47.712 60.015 ▲ ▲ ▲ 1440×900 @60Hz 55.469 59.901 ▲ ▲ ▲ 1440×900 @75Hz 70.635 74.984 ▲ ▲ ▲ 1400×1050 @60Hz 64.744 59.948 ▲ ▲ ▲ 1680×1050 @60Hz 65.290 59.954 ▲ ▲ ▲ 1920×1080 @60Hz 67.500 60.000 ▲...
-
Page 26: Appendix
User’s Manual APPENDIX SPECIFICATIONS HS221HPB Driving system TFT Color LCD LCD Panel Size 54,6cm / 21.5” Diagonal Pixel pitch 0,248mm(H) × 0,248mm(V) H-Frequency 30KHz – 83KHz Video V-Frequency 56Hz – 75Hz Display Colors 16.7M Colors Max. Resolution 1920 × 1080 @60Hz VESA DDC2B Plug &... -
Page 27: Specifications
User’s Manual SPECIFICATIONS HS241HPB Driving system TFT Color LCD LCD Panel Size 60cm / 23.6” Diagonal Pixel pitch 0,271mm(H) × 0,271mm(V) H-Frequency 30KHz – 83KHz Video V-Frequency 56Hz – 75Hz Display Colors 16.7M Colors Max. Resolution 1920 × 1080 @60Hz VESA DDC2B Plug &... -
Page 28: Specifications
User’s Manual SPECIFICATIONS HS271HPB Driving system TFT Color LCD LCD Panel Size 68.6cm / 27” Diagonal Pixel pitch 0,311mm(H) × 0,311mm(V) H-Frequency 30KHz – 83KHz Video V-Frequency 56Hz – 75Hz Display Colors 16.7M Colors Max. Resolution 1920 × 1080 @60Hz VESA DDC2B Plug &...
