Sony KP-53S65 Service Manual

Sony KP-53S65 Service Manual

Hide thumbs Also See for KP-53S65:
Table of Contents

Advertisement

Quick Links

Download this manual
When clicking an item, it's detail is displayed.
Date
SUP/COR No.
1998.08
Sup-1
HISTORY
Model Name : KP-41T65/46C65/48S65/53S65/61S65
Part No.
Description of SUP/COR
Change to PICTURE TUBE of KP-41T65(P98,105,106
108,109,110,111,112,113)
: 9-965-206-01
Change of
main text
NO

Advertisement

Table of Contents
loading

Related Manuals for Sony KP-53S65

Summary of Contents for Sony KP-53S65

  • Page 1 HISTORY Model Name : KP-41T65/46C65/48S65/53S65/61S65 Part No. : 9-965-206-01 When clicking an item, it’s detail is displayed. Change of Date SUP/COR No. Description of SUP/COR main text 1998.08 Sup-1 Change to PICTURE TUBE of KP-41T65(P98,105,106 108,109,110,111,112,113)
  • Page 2 SERVICE MANUAL RA-2A CHASSIS MODEL COMMANDER DEST. CHASSIS NO. MODEL COMMANDER DEST. CHASSIS NO. –––––––– ––––––––––––––– –––––– –––––––––––––– –––––––– ––––––––––––––– –––––– –––––––––––––– KP-41T65 KP-53S65 RM-Y136A SCC-N65D-A RM-Y136A SCC-N65A-A KP-41T65 KP-53S65 RM-Y136A Canadian SCC-N66B-A RM-Y136A SCC-N65A-B KP-46C65 KP-53S65 RM-Y136A SCC-N65E-A RM-Y136A...
  • Page 3 High-contrast protective screen 75-ohms unbalanced, sync SCN-46X1 (For KP-46C65) negative SCN-48X2 (For KP-48S65) AUDIO (phono jacks): 500 SCN-53X2 (For KP-53S65) mVrms (100% modulation) SCN-61X2 (For KP-61S65) Impedance : 47 kilohms Design and specifications are subject to change without notice. VIDEO IN 3...
  • Page 4 SAFETY CHECK-OUT ( US model only ) LEAKAGE TEST After correcting the original service problem, perfom the follow- ing safety checks before releasing the set to the customer: The AC leakage from any exposed metal part to earth ground and l.

  • Page 5: Table Of Contents

    MANUAL. FOLLOW THESE PROCEDURES WHENEVER CRIT- CRITIQUE POUR LA SÉCURITÉ DU FONCTIONNEMENT. NE ICAL COMPONENTS ARE REPLACED OR IMPROPER OPER- LES REMPLACER QUE PAR DES COMPOSANTS SONY DONT ATION IS SUSPECTED. LE NUMÉRO DE PIÉCE EST INDIQUÉ DANS LE PRÉSENT MANUEL OU DANS DES SUPPLÉMENTS PUBLIÉS PAR SONY.

  • Page 6: General

    Never use Model KP-53S65 is used for illustration purposes in this strong solvents such as thinner or benzine for cleaning. Optimum viewing area (Vertical) manual.

  • Page 7: Step 2: Hookup

    Step 2: Hookup Connecting an antenna/cable TV Connecting an antenna/cable TV system with a VCR system without a VCR For details on connection, see your VCR instruction After making these connections, you will be able to do manual. the following: To cable or antenna Before making the connection, disconnect the AC power •...
  • Page 8 To an S video equipped VCR Connecting a DBS receiver If your VCR has an S VIDEO output connector, make For details on connection, see the instruction manual of the following connections. the DBS (Digital Broadcasting Satellites) receiver. Whenever you connect the cable to the S VIDEO input connector, the projection TV automatically receives S To a projection TV video signals.
  • Page 9 Connecting a camcorder Connecting two VCRs for tape editing using MONITOR OUT Use this connection to view a camcorder picture. You can record input images displayed on the screen. (Front of projection TV) This type of connection should be used only when you connect from the line input of one VCR, and from the S VIDEO line output of a second VCR.

  • Page 10: Step 3: Setting Up The Remote Control

    Connecting a Sony SAVA series speaker system Step 3: Setting up Getting to know buttons on the remote control If you have a Sony SAVA series speaker system, connect * Manufactured under license from Dolby Laboratories the remote Licensing Corporation. Additionally licensed under Canadian...

  • Page 11: Step 4 : Setting Up The Projection Tv Automatically (Auto Set Up)

    (2) Press TV/VIDEO to select RED or BLUE. Press CHANNEL +/– or VOLUME + to select Step 4: Setting up Erasing or adding channels the on-screen menu language. TV/VIDEO CONVERGENCE : RED If you prefer Spanish or French to English, you can the projection TV After AUTO SET UP, you can erase unnecessary change the on-screen menu language.
  • Page 12 To erase and/or add other channels, repeat Press V, B, v, or b to move the cursor (z) to Press V or v to select CHANNEL ERASE/ADD, Setting cable TV on or off step 5. the symbol showing the line you want to and press adjust, and press The CHANNEL ERASE/ADD menu appears.

  • Page 13: Changing The Menu Larguage

    Operations Select the channel you want: Presetting channels Changing the Watching the TV To select a channel directly Press the 0 – 9 buttons, and press ENTER. You can preset TV channels easily by using the AUTO menu language For example, to select channel 10, press 1, 0 and PROGRAM feature.

  • Page 14: Watching Tow Programs At One Time-Pip

    Displaying on-screen information Watching a video input picture Watching two Changing the window picture input mode Press DISPLAY repeatedly until the desired Press TV/VIDEO repeatedly until the desired programs at one display appears. video input appears. Press TV/VIDEO (yellow labelled button) to Each time you press DISPLAY, the display changes as Each time you press TV/VIDEO, the display changes time —...

  • Page 15: Freezing The Picture (Freeze)

    Adjust the selected item: Changing the position of the window Freezing the picture Adjusting the (1) Press V, B, v, or b to adjust the item. picture picture VIDEO STANDARD (FREEZE) (VIDEO) Press POSITION. Each time you press POSITION, the window picture BRIGHTNESS will move counterclockwise on the screen.

  • Page 16: Adjusting The Color Temperature (Trinitone)

    Adjust the selected item: Adjusting the color Selecting the video Adjusting the (1) Press V, B, v, or b to adjust the item. temperature mode sound (TRINITONE) (VIDEO) (AUDIO) AUDIO BASS (2) Press The new setting appears in the AUDIO menu. The TRINITONE feature controls the color You can adjust the quality of the TV sound to suit your The video mode feature allows you to choose three...

  • Page 17: Using Audio Effect (Surround)

    The initial setting is stereo sound stereo system. Press V or v to select EFFECT, and press for stereo programs. (STEREO). If you connect the Sony SAVA series speaker system to AUDIO TREBLE BASS the AUDIO (VAR/FIX) OUT connectors, you can take...

  • Page 18: Setting Audio Out (Audio Out)

    SUN 12 : 00 AM MENU Note AUDIO TREBLE TIMER • This feature is only for Sony SAVA speaker system with an BASS DAYLIGHT SAVING:YES BALANCE CURRENT TIME SET Set the day. EFFECT : SURROUND ON/OFF TIMER...

  • Page 19: Setting The Timer To Turn The Projection Tv On And Off (On/Off Timer)

    (2) Press V or v to set the time (hour then minutes) Enter the letters (up to four) to caption the Customizing the Setting the timer to that you want to turn on the projection TV, and channel: press (1) Press V or v to select the first letter. channel names turn the projection ON/OFF TIMER...

  • Page 20: Blocking Out A Channel (Channel Block)

    Press V or v to select a favorite channel Blocking out a Setting your Setting video labels number, and press channel favorite channels FAVORITE CHANNEL (CHANNEL BLOCK) (VIDEO LABEL) MODE: MANUAL – – – – – – – – – –...

  • Page 21: Setting Caption Vision (Caption Vision)

    Some programs are broadcast with Caption Vision. To You can use the supplied remote control to operate 314, 336, 337 Dimensia Sony or non-Sony video equipment that has an infrared display Caption Vision, select either CC1, CC2, CC3, VIDEO 3 Emerson 319, 320, 316, 317, 318 remote sensor.

  • Page 22: Operating A Cable Box Or Dbs Receiver

    For more details on operating the cable box or control to operate the video equipment. equipment’s own remote control unit. DISPLAY* • The code numbers for Sony equipment are assigned at the DBS receiver Press VTR (FUNCTION) before operating the factory as follows: Refer to the operating instructions that come with the video equipment.

  • Page 23: Troubleshooting

    If the problem persists after trying the methods below, This section briefly describes the buttons and controls Double images or ghosts contact your nearest Sony dealer. on the projection TV and on the Remote control. For / Use a highly directional outdoor antenna or a...
  • Page 24 Remote control !¢ !∞ !§ !¶ !• !ª @º @¡ @™ @£ @¢ @∞ !º @§ @¶ !¡ @• !™ !£ 1 VTR (POWER) switch (page 36) !¶ TV (FUNCTION) button (pages 15, 19) 2 MUTING button (page 19) !• SWAP button (page 22) 3 VTR (FUNCTION) button (page 35) !ª...

  • Page 25: Disassembly

    SECTION 2 DISASSEMBLY 2-1. REAR BOARD REMOVAL 2 Rear board 1 Eight screws (KP-41T65) Nine screws (KP-46C65/48S65) Eleven screws (KP-53S65) Twelve screws (KP-61S65) (Tapping screw 4X20) 2-2. CHASSIS ASSY REMOVAL 1 Three screws (Head tapping screw 4X20) 2 Chassis assy 2-3.

  • Page 26: Ha Board Removal (Kp-41T65)

    2-4-1. HA BOARD REMOVAL (KP-41T65) 2 Control panel cap (L) 1 Six screws (Tapping screw 4X20) 4 Nine screws (+BVTP 3X12) 2 Control panel cap (R) 5 HA board 3 Control panel assy 2-4-2. HA BOARD REMOVAL (KP-46C65) 4 Eight screws (+BVTP 3X12) 5 HA board 2 Three screws...

  • Page 27: Beznet Assy Removal (Kp-41T65)

    2-5-1. BEZNET ASSY REMOVAL (KP-41T65) 1 Nine screws (Tapping screw 4X20) 2 Beznet assy 2 Two screws (Tapping screw 4x20) 2-5-2. BEZNET ASSY REMOVAL (KP-46C65/48S65/53S65) 1 Ten screws (KP-46C65) Twelve screws (KP-48S65/53S65) (Tapping screw 4X20) 3 Beznet assy 2 Three screws (Tapping screw 4X20) 2-5-3.

  • Page 28: Mirror Cover Assy Removal (Kp-41T65)

    1 Fifteen screws (Tapping screw 4X20) 2-6-2. MIRROR COVER ASSY REMOVAL (KP-46C65/48S65/53S65) 2 Mirror cover assy 1 Eighteen screws (KP-46C65) Twenty screws (KP-53S65) Twenty four screws (KP-48S65) (Tapping screw 4X20) 2-6-3. REFLECTION MIRROR REMOVAL (KP-61S65) 4 Mirror board 5 Reflection mirror...

  • Page 29: High-Voltage Cable Installation And Removal

    2-7. HIGH-VOLTAGE CABLE INSTALLATION AND REMOVAL (1) Remover (2) Installation 1 Rubber cap 1 HV cable 2 HV cable Hook turn 90˚ Gutter 2-8-1. PICTURE TUBE REMOVAL (KP-41T65) CAUTION: Removing the arrow-marked screws is strictly prohibited. If removed, it may cause liquid spill. Lens 1 Four screws (Head tapping screws 4X20)

  • Page 30: Service Stay Assy How To Use And Carry Back Service Stay Assy

    2-9-1. SERVICE STAY ASSY HOW TO USE AND CARRY BACK SERVICE STAY ASSY. SERVICE STAY ASSY X-3702-036-1 Side board (L) Side board (R) 4-057-612-01 4-057-613-01 Screw (+BVTP 4X12) 7-685-661-14 Chassis stay 4-058-638-01 2-9-2. PICTURE TUBE BRACKET ASSY REMOVAL (KP-41T65) 3 Eight screws (Head tapping screw 4X20) 4 Picture tube bracket assy...

  • Page 31: Picture Tube Bracket Assy Removal (Kp-46C65/48S65/53S65/61S65)

    2-9-3. PICTURE TUBE BRACKET ASSY REMOVAL (KP-46C65/48S65/53S65/61S65) • Disassemble HA board and speaker cord. • Disassemble all the harness from purse lock. 3 Two screws (Tapping screw 4X20) 4 Shield board 6 Picture tube bracket assy 5 Eight screws (Head tapping screw 4X20) 7 Two screws (+BVTP 4X12) 8 X-RAY shield (L)

  • Page 32: Setting Of Service Stay Assy (Kp-46C65/48S65/53S65)

    2-9-4. SETTING OF SERVICE STAY ASSY. (KP-41T65/46C65/48S65/53S65) 2 Six screws (+BVTP 4X12) Picture tube bracket assy Notch Hook 4 Six screws (+BVTP 4X12) Hook Notch 1 Side board (L) 3 Side board (R) 1) Lift up picture tube bracket assy and fit the hook of 1 side board (L) to the notch on the assy. Then fix then with 2 six screws (+BVTP 4X12).

  • Page 33: Set-Up Adjustments

    SECTION 3 SET-UP ADJUSTMENTS 3-1. SCREEN VOLTAGE ADJUSTMENT 3-3. SCREEN (G2) ADJUSTMENT 1. Select VIDEO mode without signals. (ROUGH ALIGNMENT) 2. Connect an oscilloscope to the TP701(KR), TP731(KG) and 1. Receive the Monoscope signal. TP761(KB) of CR board, CG board and CB board. 2.
  • Page 34 3-5. DEFLECTION YOKE TILT ADJUSTMENT 3-7. 4-POLE MAGNET ADJUSTMENT 1. Set to receive the Monoscope signal. 1. Set in service mode. 2. Set in service mode. 2. Set to receive the Dot signal. 3. Use VP on the service mode menu to show only the green 3.
  • Page 35 2. MEMORY WRITE CONFIRMATION METHOD 3-9. ELECTRICAL ADJUSTMENT BY REMOTE 1. After adjustment, remove the plug from AC outlet, and then COMMANDER replace the plug in AC outlet again. 2. Turn the power switch ON and set to Service Mode. 3.
  • Page 36 – 35 –...
  • Page 37 – 36 –...
  • Page 38 – 37 –...
  • Page 39 – 38 –...
  • Page 40 • H-SHIFT adjustment 3-10. CONVERGENCE ADJUSTMENT • When replacing the deflection yoke, always perform VP HPOS “DEFLECTION YOKE TILT ADJUSTMENT” before adjusting the convergence. Adjustment procedure • H-SIZE adjustment VSP MAIN Finely adjust with SUB MSIZ. VP HSIZ R GH (SUB), R GV (SUB) R RH (SUB), R RV (SUB) •...
  • Page 41 [GREEN SUB ADJUSTMENT] SCREEN CENTER SECTION GREEN HORIZONTAL LINE SCREEN CENTER SECTION GREEN VERTICAL LINE ADJUSTMENT ADJUSTMENT 1. Finely adjust the center position of the vertical line at the 1. Finely adjust with GH CENT, GH BOW, GH SKEW. center of the screen with GV CENT. Adjust by watching out for the GH CENT screen center sec- 2.
  • Page 42 GREEN HORIZONTAL SIZE ADJUSTMENT GREEN VERTICAL SIZE ADJUSTMENT 1. Adjust with RGH MSIZE so that the sizes of both ends and 1. Adjust with GV MSIZE so that the sizes for the top and bot- of both sides of the center section of the screen are equal. tom sections of the screen and for both sides of the center 2.
  • Page 43 GREEN HORIZONTAL QUATERNARY ADJUSTMENT GREEN HORIZONTAL SYMMETRICAL PIN DISTORTION ADJUSTMENT 1. Correct the quaternary distortion with GH 4PIN. 1. Adjust the pin distortion at both sides of the center section of 2. While balancing, correct the quaternary distortion of both the screen with GH MPIN.
  • Page 44 GREEN VERTICAL QUATERNARY DISTORTION GREEN VERTICAL ASYMMETRICAL PIN DISTORTION ADJUSTMENT (SECONDARY DISTORTION) ADJUSTMENT 1. Correct the quaternary distortion of the horizontal lines at 1. Correct the asymmetrical pin distortion at the top and bot- the top and bottom sections of the screen with GV 4PIN. tom sections of the screen with RGV SBOW.
  • Page 45 GREEN AND RED REGISTRATION ADJUSTMENT (RRH, RRV) 1. Receive a cross-hatch signal. 2. Adjust so that the red lines lay on the green lines. Adjust with the same procedure as the GREEN SUB adjust- ment. Notes: 1. The main correction is not carried out during red registration adjustment.

  • Page 46: Safety Relatedp Adjustments

    SECTION 4 SAFETY RELATED ADJUSTMENTS [ G BOARD] 4-2. HV HOLD DOWN CIRCUIT OPERATION 4-1. HV REGULATION CIRCUIT CHECK AND CHECK AND ADJUSTMENT ADJUSTMENT When replacing the following components marked with When replacing the following components marked with the schematic diagram always check hold-down voltage and if the schematic diagram always check HV regulation, and if nec- necessary re-adjust.
  • Page 47 SECTION 4 SAFETY RELATED ADJUSTMENTS 4-4. +B OVP CONFIRMATION 1. Remove CN651 connector. 2. Connect a voltmeter to TP135V, and TP (PROT) and ground. 3. Connect a 220kΩ variable resistor, across pin 3 and pin 5 of IC651 set to maximum value. 4.

  • Page 48: Circuit Adjustments

    SECTION 5 CIRCUIT ADJUSTMENTS 5-1. RF AGC 5-4. SUB-HUE AND SUB-COLOR ADJUSTMENT 1. Input a color-bar signal. (SHUE, SCOL) 2. Adjust AGC VR of TU1101 so that snow noise, and 1. Receive the color-bar signal. crossmodulation disapper from the picture. 2.
  • Page 49 SECTION 5 CIRCUIT ADJUSTMENTS 5-6. P IN P SUB CONTRAST ADJUSTMENT (PCON) 1. Receive the color-bar signal. 2. PICTURE : maximum COLOR : minimum BRIGHTNESS : minimum 3. Set to service mode. 4. Connect an oscilloscope between 9 pin of CN303 (A Board) and ground.

  • Page 50: Diagrams

    SECTION 6 DIAGRAMS 6-1. BLOCK DIAGRAM (1) TO PT BOARD CN5101 CN304(1/2) CN304(2/2) IC301 VIDEO CN305(1/2) IC201 SUB V TO PT BOARD CN305(2/2) AV SW CN5101 PR Y ERY IN CN303 TU1101 TO PT BOARD BUFFER P BY EBY IN R OUT BFFER V BUFFER...

  • Page 51: Block Diagram (2)

    BLOCK DIAGRAM (2) BLOCK DIAGRAM (3) IC5101 D COMB FILTER CN1434 (DY/VM) (R OUT) CN5101(1/2) CN5101(2/2) G-H(+) BUFFER BUFFER BUFFER V IN AD IN Y OUT Q5101 Q5108,5105 Q5102,5106,5109,FL5101 G-H(-) IC701 TO A BOARD VIDEO AMP V901 CN1461 PICTURE TUBE CN304 BUFFER VM DRIVE...

  • Page 52: Frame Schematic Diagram

    6-2. FRAME SCHEMATIC DIAGRAM CN707 CN701 :FASTON :FASTON CN703 CN1304 ANT SW WHT-L (CRT-GND) :S-MICRO :S-MICRO TO A:CN402 TO A:CN303 (AS-2F) CN1302 CN1301 CN705 WHT-L WHT-L :S-MICRO :S-MICRO BLK-L :S-MICRO TO A:CN1101 TO A:CN002 CRT(R) CN706 CN5051 :S-MICRO CN5101 H(+) CN702 TO CG:CN736 :B TO B-S...
  • Page 53 A BOARD IC VOLTAGE LIST REF. VOL. REF. VOL. REF. VOL. REF. VOL. REF. VOL. %§ !¢ @¡ %¶ !∞ @™ TU1101 TU1102 CN001 FSS BTF-WA404 BTF-LA402 CN002 CN303 %• !§ @£ MAIN TUNER SUB TUNER :S-MICRO :S-MICRO %ª !¶ @¢...

  • Page 54: A Board

    A BOARD : IC007 ST24C04FM6TR TUNER, AV SW, Y/C/J, AUDIO OUT, V OUT AV INPUT – A Board – A BOARD Q006 A-11 DIODE Q007 D001 – Q008 D002 – Q009 A-11 D003 – Q013 D004 – Q015 D007 – Q016 D010 –...

  • Page 55: G Board

    [POWER SUPPLY, HV, RGB CONV, H/V WAVE GNE] G BOARD : IC801, 802 PA0053B – G Board – G BOARD D849 G-11 – DIODE D850 H-14 – D501 F-10 – D852 H-12 – D502 – D853 H-11 – D503 – D854 H-12 –...
  • Page 56 • G BOARD * MARK LIST R583 PROT 8.2k R561 0.7Vp-p (H) 2.5Vp-p (V) 15.0Vp-p (V) 0.2Vp-p (H) KP-41T65/48S65/ KP-46C65/53S65 KP-53S65 (US) 53S45/61S65 (CND) C514 390PF 2KV :B 390PF 2KV :B 1000P 2KV :B C536 0.033 : PT 0.033 : PT 0.047 : PT C869 0.022 : PT...
  • Page 57 PT BOARD : IC5052 SDA9288X-GEG FB5108 0.45UH BL02RN1 C5129 C5138 R5158 IC5103 :CHIP NJM78M05FA F:CHIP 5V-REG D5101 R5102 R5104 C5108 R5120 UDZ-TE-17-5.6B 0.01 PROT :CHIP :CHIP F:CHIP :RN-CP C5072 D.GND L5003 0.1 25V F:CHIP C5135 47µH 0.01 :FLR50 L5004 F:CHIP 47µH C5071 :FLR50...

  • Page 58: Board

    DIGITAL COMB FILTER, PIP PROCESSOR, SUB DEC, 4FSC GNE – PT Board – PT BOARD DIODE D5053 D5101 TRANSISTOR Q5001 A-10 Q5002 Q5003 Q5004 Q5005 Q5051 Q5052 Q5053 Q5054 Q5055 Q5056 Q5057 Q5101 Q5102 Q5103 Q5104 Q5105 Q5106 F-10 Q5107 F-10 Q5108 Q5109...
  • Page 59 •All voltage are in V. B-SS553.<U..>-CG. • CR BOARD WAVEFORM •Pin number which are not • CR BOARD * MARK LIST described are not used. KP-41T65/48S65/ KP-46C65/53S65 KP-53S65 (US) 53S45/61S65 (CND) • CG BOARD WAVEFORM • CG BOARD * MARK LIST C702 CN707 –––––...
  • Page 60 910 :RN R770 C762 R767 R765 2.4k D763 MTZJ-10 SLICE B-SS553.<U..>-CB. • CB BOARD WAVEFORM • CB BOARD * MARK LIST KP-41T65/48S65/ KP-53S65 (US) KP-46C65/53S65 53S45/61S65 (CND) CN767 ––––– ––––– FASTON R761 100 1/2W 100 1/2W 470 1/2W 170Vp-p (H) –...

  • Page 61: Z Board

    Z BOARD TRANSISTOR VOLTAGE LIST REF. VOL. CN1434 DY(R) T0 G:CN504 DY(G) DY(B) T0 G:CN502 4P :VH R-H(+) T0 G BOARD CN503 B-H(+) Q1431 G-H(+) H(MID) H(MID) H(MID) DY(H) DY(H) DY(H) 67.2 R-H(-) B-H(-) 134.4 H.IN H.IN G-H(-) H.IN Q1432 138.4 V.IN V.IN...

  • Page 62: Ha Board

    [VM, DY] [IN / OUT SELECT] – Z Board – CN1304 WHT-L :S-MICRO TO A:CN402 CN1301 WHT-L :S-MICRO R1313 STBY5V TO A BOARD CN002 JW(5) STÆ BY 5V R1305 R1306 C1304 SIRCS R1314 D1304 SLR-325VCT31 R1310 R1304 4.7k D1309 POWER R1303 R1302 R1307...

  • Page 63: Semiconductors

    6-5. SEMICONDUCTORS BH3856FS-E2 CXP85112B-613S PST9143NL UPC4558G2 2SC4632LS-CB7 D1NS4 ERC06-15S CXP85856A-009S HZS9.1NB2 ERD29-08J C06P~C98P Chip C04H~C06H C08S ~ C98S MTZJ-T-77-15 C06P~C98P MTZJ-T-77-36B MTZJ-13 CATHODE MTZJ-30A TOP VIEW TOP VIEW MTZJ-33B Dual In-line Package TOP VIEW Chip Type Small Outline L-leaded Package Pin 6~98 Pin 4~6 MTZJ-7.5B...

  • Page 64: Exploded Views

    KP-41T65/46C65/48S65/53S65/61S65 RM-Y136A RM-Y136A RM-Y136A RM-Y136A RM-Y136A Les composants identifies par The componants identified by une trame et une marque shading and mark are criti- SECTION 7 sont critiques pour la securite. cal for safety. Ne les remplacer que par une Replace only with part number The componants identified by EXPLODED VIEWS...

  • Page 65: Cover (Kp-46C65/48S65/53S65)

    X-4034-457-1 GRILLE ASSY, SPEAKER (KP-46C65) 4-059-346-01 CUSHION, GRILLE X-4035-410-1 GRILLE ASSY, SPEAKER (KP-48S65/53S65) * 4-048-152-01 HOLDER (S), SCREEN (KP-46C65/48S65) * 4-048-152-11 HOLDER (S), SCREEN (KP-53S65) 4-838-438-00 LATCH (KP-46C65) X-4034-456-1 PANEL ASSY, CONTROL (KP-46C65) * 4-048-159-01 HOLDER (L), SCREEN (KP-46C65/48S65) 4-057-605-01 DOOR, CONTROL...

  • Page 66: Cover (Kp-61S65)

    KP-41T65/46C65/48S65/53S65/61S65 RM-Y136A RM-Y136A RM-Y136A RM-Y136A RM-Y136A Les composants identifies par The componants identified by une trame et une marque shading and mark are criti- sont critiques pour la securite. cal for safety. Ne les remplacer que par une Replace only with part number piece portant le numero specifie.

  • Page 67: Chassis (Kp-41T65)

    KP-41T65/46C65/48S65/53S65/61S65 RM-Y136A RM-Y136A RM-Y136A RM-Y136A RM-Y136A Les composants identifies par The componants identified by une trame et une marque shading and mark are criti- sont critiques pour la securite. cal for safety. Ne les remplacer que par une Replace only with part number piece portant le numero specifie.

  • Page 68: Chassis (Kp-46C65/48S65/53S65/61S65)

    * A-1190-265-A PT BOARD, COMPLETE (KP-46C65/53S65 (US (N65A-A), CND)) ! 8-598-339-00 TUNER BTF-LA402 ! 8-598-340-00 TUNER BTF-WA404 * A-1316-367-A G BOARD, COMPLETE (KP-41T65/48S65/61S65) * 1-557-056-31 CABLE, P-P * A-1316-379-A G BOARD, COMPLETE 1-556-945-21 CABLE, P-P (KP-53S65(US (N65A-B))) 8-598-414-00 ANTENNA SWITCH AS-2F – 93 –...

  • Page 69: Picture Tube (Kp-41T65)

    KP-41T65/46C65/48S65/53S65/61S65 RM-Y136A RM-Y136A RM-Y136A RM-Y136A RM-Y136A Les composants identifies par The componants identified by une trame et une marque shading and mark are criti- sont critiques pour la securite. cal for safety. Ne les remplacer que par une Replace only with part number piece portant le numero specifie.

  • Page 70: Picture Tube (Kp-46C65/48S65/53S65/61S65)

    ! 1-451-455-31 DEFLECTION YOKE (R) (B) ! A-1501-310-A COUPLER (R) ASSY, PICTURE TUBE ! 1-452-790-21 NECK ASSY ! 1-451-454-11 DEFLECTION YOKE (G) (KP-53S65(US (N65A-B))) ! 8-733-539-05 PICTURE TUBE 07MXC2 (R) (KP-46C65) * A-1390-843-A Z BOARD, COMPLETE ! 8-733-553-05 PICTURE TUBE 07MXC3 (R)

  • Page 71: Electrical Parts List

    KP-41T65/46C65/48S65/53S65/61S65 RM-Y136A RM-Y136A RM-Y136A RM-Y136A RM-Y136A Les composants identifies par The componants identified by une trame et une marque shading and mark are criti- sont critiques pour la securite. cal for safety. SECTION 8 Ne les remplacer que par une Replace only with part number piece portant le numero specifie.
  • Page 72 KP-41T65/46C65/48S65/53S65/61S65 RM-Y136A RM-Y136A RM-Y136A RM-Y136A RM-Y136A Les composants identifies par The componants identified by une trame et une marque shading and mark are criti- sont critiques pour la securite. cal for safety. Ne les remplacer que par une Replace only with part number piece portant le numero specifie.
  • Page 73 KP-41T65/46C65/48S65/53S65/61S65 RM-Y136A RM-Y136A RM-Y136A RM-Y136A RM-Y136A Les composants identifies par The componants identified by une trame et une marque shading and mark are criti- PT A sont critiques pour la securite. cal for safety. Ne les remplacer que par une Replace only with part number piece portant le numero specifie.
  • Page 74 KP-41T65/46C65/48S65/53S65/61S65 RM-Y136A RM-Y136A RM-Y136A RM-Y136A RM-Y136A Les composants identifies par The componants identified by une trame et une marque shading and mark are criti- sont critiques pour la securite. cal for safety. Ne les remplacer que par une Replace only with part number piece portant le numero specifie.
  • Page 75 KP-41T65/46C65/48S65/53S65/61S65 RM-Y136A RM-Y136A RM-Y136A RM-Y136A RM-Y136A Les composants identifies par The componants identified by une trame et une marque shading and mark are criti- sont critiques pour la securite. cal for safety. Ne les remplacer que par une Replace only with part number piece portant le numero specifie.
  • Page 76 KP-41T65/46C65/48S65/53S65/61S65 RM-Y136A RM-Y136A RM-Y136A RM-Y136A RM-Y136A Les composants identifies par The componants identified by une trame et une marque shading and mark are criti- sont critiques pour la securite. cal for safety. Ne les remplacer que par une Replace only with part number piece portant le numero specifie.
  • Page 77 KP-41T65/46C65/48S65/53S65/61S65 RM-Y136A RM-Y136A RM-Y136A RM-Y136A RM-Y136A Les composants identifies par The componants identified by une trame et une marque shading and mark are criti- sont critiques pour la securite. cal for safety. Ne les remplacer que par une Replace only with part number piece portant le numero specifie.
  • Page 78 KP-41T65/46C65/48S65/53S65/61S65 RM-Y136A RM-Y136A RM-Y136A RM-Y136A RM-Y136A Les composants identifies par The componants identified by une trame et une marque shading and mark are criti- sont critiques pour la securite. cal for safety. Ne les remplacer que par une Replace only with part number piece portant le numero specifie.
  • Page 79 KP-41T65/46C65/48S65/53S65/61S65 RM-Y136A RM-Y136A RM-Y136A RM-Y136A RM-Y136A Les composants identifies par The componants identified by une trame et une marque shading and mark are criti- sont critiques pour la securite. cal for safety. Ne les remplacer que par une Replace only with part number piece portant le numero specifie.
  • Page 80 1-130-489-00 MYLAR 0.033µF (KP-41T65/46C65/48S65/53S65 (US (N65A-A), CND) /61S65) TU1101 8-598-340-00 TUNER, FSS BTF-WA404 TU1102 8-598-339-00 TUNER, FSS BTF-LA402 C536 1-137-374-11 FILM 0.0047µF 5% (KP-53S65 (US (N65A-B))) C537 1-104-665-11 ELECT 100µF 20% 25V <CRYSTAL> C538 1-104-665-11 ELECT 100µF 20% 25V C539 1-162-114-00 CERAMIC 0.0047µF 2KV...
  • Page 81 20% 16V (KP-41T65/46C65/48S65/53S65 (US (N65A-A), CND) /61S65) C806 1-126-934-11 ELECT 220µF 20% 16V C869 1-130-489-00 MYLAR 0.033µF C807 1-137-374-11 FILM 0.047µF (KP-53S65 (US (N65A-B))) C808 1-137-374-11 FILM 0.047µF C809 1-137-374-11 FILM 0.047µF C871 1-101-880-00 CERAMIC 47PF C872 1-101-880-00 CERAMIC 47PF...
  • Page 82 CN804 * 1-774-182-11 CONNECTOR, BOARD TO BOARD10P D845 8-719-991-33 DIODE 1SS133T-77 D846 8-719-991-33 DIODE 1SS133T-77 CN805 * 1-691-134-11 PIN, CONNECTOR (PC BOARD) 2P CN806 1-695-915-11 TAB (CONTACT) (KP-53S65 (US)) D847 8-719-982-19 DIODE MTZJ-30A D848 8-719-923-86 DIODE MTZJ-T-77-15 D849 8-719-110-22 DIODE RD11ESB2 <DIODE>...
  • Page 83 8-729-823-81 TRANSISTOR 2SC4632LS-CB7 R539 1-249-377-11 CARBON 0.47 1/4W F Q505 8-729-931-45 TRANSISTOR IRF614 R540 1-249-377-11 CARBON 0.47 1/4W F (KP-53S65 (US (N65A-B))) Q506 8-729-119-78 TRANSISTOR 2SC2785-HFE Q507 8-729-032-61 TRANSISTOR 2SC5022-02 R540 1-249-379-11 CARBON 0.68 1/4W F Q651 8-729-119-76 TRANSISTOR 2SA1175-HFE...
  • Page 84 (KP-41T65/46C65/48S65/53S65 (US (N65A-A), CND)/61S65) R672 1-249-421-11 CARBON 2.2K 1/4W R556 1-260-123-11 CARBON 100K 1/2W R673 1-249-413-11 CARBON 1/4W (KP-53S65 (US (N65A-B))) R675 1-215-417-00 METAL 1/4W R557 1-216-490-11 METAL OXIDE R676 1-216-369-00 METAL OXIDE 2W F R558 1-216-490-11 METAL OXIDE R677...
  • Page 85 R856 1-247-807-31 CARBON 1/4W (KP-41T65/46C65/48S65/53S65 (US (N65A-A), CND)/61S65) R857 1-247-807-31 CARBON 1/4W R921 1-249-431-11 CARBON 1/4W R858 1-215-455-00 METAL 1/4W (KP-53S65 (US (N65A-B))) R859 1-215-455-00 METAL 1/4W R922 1-215-445-00 METAL 1/4W R860 1-215-455-00 METAL 1/4W R923 1-249-425-11 CARBON 4.7K 1/4W...
  • Page 86 1-215-445-00 METAL 1/4W CN705 ! 1-251-182-11 SOCKET, CRT R986 1-215-451-00 METAL 1/4W CN706 * 1-564-512-11 PLUG, CONNECTOR 9P R987 1-249-408-11 CARBON 1/4W CN707 1-695-915-11 TAB (CONTACT) (KP-53S65 (US)) R988 1-215-445-00 METAL 1/4W R989 1-249-425-11 CARBON 4.7K 1/4W R990 1-249-429-11 CARBON 1/4W <DIODE>...
  • Page 87 CN736 * 1-564-512-11 PLUG, CONNECTOR 9P CN763 * 1-508-784-00 PIN, CONNECTOR (5MM PITCH) 1P CN737 * 1-564-512-11 PLUG, CONNECTOR 9P CN764 ! 1-251-182-11 SOCKET, CRT CN738 1-695-915-11 TAB (CONTACT) (KP-53S65 (US)) CN765 * 1-564-512-11 PLUG, CONNECTOR 9P CN766 1-564-513-11 PLUG, CONNECTOR 10P <DIODE>...
  • Page 88 <IC> <RESISTOR> IC1301 8-742-088-10 HYB IC SBX1780-51(10) R761 1-219-743-11 CARBON 1/2W (KP-41T65/46C65/48S65/53S65 (US (N65A-A), CND)/61S65) R761 1-219-745-11 CARBON 1/2W <JACK> (KP-53S65 (US (N65A-B))) R762 1-260-132-11 CARBON 560K 1/2W J1301 1-770-361-11 TERMINAL BLOCK, S R763 1-215-420-00 METAL 1/4W R764 1-249-426-11 CARBON 5.6K...
  • Page 89 D1433 8-719-991-33 DIODE 1SS133T-77 <CONNECTOR> ************************************************************* DY1431 1-451-454-11 DEFLECTION YOKE MISCELLANEOUS ***************** ! A-1501-310-A COUPLER (R) ASSY, PICTURE TUBE <COIL> (KP-53S65(US (N65A-B))) ! A-1501-311-A COUPLER (B) ASSY, PICTURE TUBE L1431 1-410-478-11 INDUCTOR 47µH L1432 1-410-478-11 INDUCTOR 47µH (KP-53S65(US (N65A-B))) ! A-1501-312-A COUPLER (G) ASSY, PICTURE TUBE (KP-53S65(US (N65A-B))) <TRANSISTOR>...
  • Page 90 * 4-047-555-01 PLATE, TOP (KP-61S65) * 4-047-774-01 PLATE, TOP (KP-53S65) * 4-049-155-01 BAG, PROTECTION (KP-41T65) * 4-056-291-01 INDIVIDUAL CARTON (KP-53S65) * 4-056-292-01 CUSHION (UPPER) (ASSY) (KP-53S65) * 4-056-293-01 CUSHION (LOWER) (ASSY) (KP-53S65) * 4-056-298-01 BOARD, BOTTOM (KP-553S65) * 4-056-300-01 TRAY (KP-53S65)
  • Page 91 REF. NO. PART NO. DESCRIPTION REMARK REF. NO. PART NO. DESCRIPTION REMARK –––––––– ––––––––– ––––––––––––– ––––––––– –––––––– ––––––––– ––––––––––––– ––––––––– English 98CR74376-1 Sony Ichinomiya Corporation Printed in USA 9-965-206-01 Quality Assurance Division ©1998.3 – 116 –...
  • Page 92 RA-2A SERVICE MANUAL CHASSIS MODEL MODEL COMMANDER DEST. CHASSIS NO. COMMANDER DEST. CHASSIS NO. KP-41T65 KP-53S65 RM-Y136A SCC-N65D-A RM-Y136A SCC-N65A-A KP-41T65 KP-53S65 RM-Y136A Canadian SCC-N66B-A RM-Y136A SCC-N65A-B KP-46C65 KP-53S65 RM-Y136A SCC-N65E-A RM-Y136A Canadian SCC-N66C-A KP-46C65 KP-61S65 RM-Y136A Canadian SCC-N66D-A RM-Y136A...
  • Page 93 KP-41T65/46C65/48S65/53S65/61S65 RM-Y136A RM-Y136A RM-Y136A RM-Y136A RM-Y136A Les composants identifies par The components identified by une trame et une marque shading and mark are criti- sont critiques pour la securite. cal for safety. Ne les remplacer que par une Replace only with part number piece portant le numero specifie.
  • Page 94 KP-41T65/46C65/48S65/53S65/61S65 RM-Y136A RM-Y136A RM-Y136A RM-Y136A RM-Y136A Les composants identifies par The components identified by une trame et une marque shading and mark are criti- sont critiques pour la securite. cal for safety. Ne les remplacer que par une Replace only with part number piece portant le numero specifie.
  • Page 95 * A-1331-813-A CB BOARD, COMPLETE (VAR) ! 1-451-455-31 DEFLECTION YOKE (R) (B) 4-052-894-01 SCREW (4X20), HEAD TAPPING ! 1-451-455-11 DEFLECTION YOKE (G) * A-1390-867-A Z BOARD, COMPLETE English Sony Ichinomiya Corporation 98HN02377-1 Printed in JAPAN Quality Assurance Division 9-965-206-81 © 1998.8...
