- Page 1 ILD-5xx and ILD-4xx Camera Web Interface User Guide Firmware version: 2.2.0...
-
Page 2: Table Of Contents
Contents Overview ..............................3 Live ................................5 Playback ..............................6 3.1. Search and playback ......................... 6 3.2. Saving images and video export ....................... 7 Settings ..............................9 4.1. System / Device ..........................9 4.2. System / Network ..........................10 4.3. System / Users .......................... -
Page 3: Overview
SD card. The web interface comes especially handy when installing the camera, since the required image quality can be adjusted through connecting the camera to a laptop. All we need to be able to use the web interface of Intellio ILD cameras is an internet browser. Supported browsers: ... - Page 4 The following menu is available on the web interface for camera settings: 1. Live The live images of the camera can be viewed. 2. Playback The footage stored on the SD card can be played back. 3. Settings a) System: the device, network, user and memory card storage settings can be accessed, and the active connections can be viewed.
-
Page 5: Live
Live After login the live video of the camera can be seen under the Live tab. This tab displays only the live images of the camera, which can be enlarged to full screen using the icon in the bottom right corner of the image. Press the same icon or the ESC key to exit full screen mode. -
Page 6: Playback
Playback The Playback interface can only be accessed with S type cameras. The Playback tab houses the interface for searching and playing back the footage stored on the SD card, and saving video extracts to the computer. If the storage has been switched off, but the storage device is available, it can be connected to the camera, so the footage can be played back even with the storage being switched off. -
Page 7: Saving Images And Video Export
When selecting a period with no footage, the caption ”No data” is displayed. Once the playback time has been set, the usual functions can be used. The playback button, along with the playback speed dropdown menu, are on the left of the timeline. The Stop button is displayed when playback is in progress. - Page 8 Exporting – depending on the length of the video – can take up to several minutes. The progress of the saving can be monitored on the progress bar displayed after hitting the Export button. Install the Intellio Video Codec to watch the video exported! Afterwards, the video can be watched in Windows Media Player.
-
Page 9: Settings
Settings The parameters necessary for the optimal operation of the camera can be set under the Settings menu. 4.1. System / Device The Device data sheet contains the key data of the camera, which are the following: MAC address: the MAC address of the camera, ... -
Page 10: System / Network
4.2. System / Network The Network menu contains the network settings. Either a static or dynamic IP address can be set for the camera. Default DNS: 8.8.8.8 4.3. System / Users The Users menu serves for the maintenance of user data. The default user is the admin. ... -
Page 11: System / Time
In addition, the NTP servers can be used. Press ”Change settings” to pull up the window where the NTP server can be authorized or prohibited. Use this option only in case the camera is not registered on an Intellio server. See default values below:... -
Page 12: System / Storage
4.5. System / Storage The Storage settings available only by „S” series cameras. Storage onto SD card: Select the SD Card button in ”Storage Type”, then select above the storage of primary or secondary encoder images. When the settings have been adjusted, switch on the storage. ... - Page 13 SMB storage: Share a folder in your Windows operating system. Select the Windows Share button in Storage Type, then select above the storage of primary or secondary encoder images. Provide the IP address or domain name of the computer, then the access route of the shared folder.
- Page 14 Check the Status section to find out: whether the storage device has been mounted successfully (Mounted or Unmounted); whether there is an authentication problem in the file system: write files (Write), create files (Create), delete files (Remove); how many files can be stored onto the SD card, and whether there are files on the Storage device which cannot be played;...
-
Page 15: System / Active Connections
4.6. System / Active connections This menu allows users to check which cameras are monitored from which IP addresses, and which servers the cameras are registered to. In addition, this menu provides data concerning image transmission. Interpreting the columns of the table: IP –... -
Page 16: Video / Sensor Settings
4.7. Video / Sensor settings At the video settings near the adjusting interface is the live video of the camera, so can be seen the result of settings. The full-screen icon can be used like on the Live menu. At the sensor settings can be adjust two parameters. Framerate limit: When the limit is enabled, the maximum frame rate is this rate. -
Page 17: Video / Image Settings
4.8. Video / Image settings On this adjusting interface the picture quality can be changed. In the Day and Night profile have 6 parameters: Brightness Contrast Gamma – can be adjust the transition of dark and bright area of picture ... - Page 18 On the General tab can be found all other picture-adjusting features. Iris control – whether the iris should work automatically or should be open at all times Maximum gain – the digital amplify’s maximum Maximum exposure – the exposure’s maximum ...
- Page 19 Backlight Compensation is recommended to use if the images contain both significant and insignificant details. Authorize BLC, then mask the significant section in the live image. Click ”Apply changes” to optimize image drive for, and thus enhance image quality in the masked area. At the same time, areas outside the masked area may become overexposed or underexposed.
-
Page 20: Video / Video Encoder
4.9. Video / Video encoder The Video encoder menu features the functions related to the video encoder, along with the live video displayed above these functions. The difference between the primary and secondary encoder is that the resolution of secondary encoder is fix. ... - Page 21 Framerate Control Here can be adjust the reduced fps. The framerate control can be activate or deactivate. By the deactivated status the camera work with maximal frame rate. Mode : Here can be adjust the frame rate of motion-case, alert-case or for both Normal fps : In case of motion or alarm the camera work with this frame rate Reduced fps...
-
Page 22: Video / Motion Detector
4.10. Video / Motion detector Setting the motion detector is a crucial step with regards to storage efficiency and the flawless recording of events. The motion detectors controlling image transmission are on-board the camera. Cover the relevant area with the green polygon mask. Multiple masks can be combined to make up Mask 1. -
Page 23: Video / Eptz
4.11. Video / EPTZ In order to use the EPTZ function, it has to be authorized first. Click Yes on the Settings tab, and save the changes with the Apply changes button. The EPTZ control panel is located on the Control tab: the arrows on the left and a pointer pad on the right. -
Page 24: Events / Detector List
4.12. Events / Detector list This is where the list of detectors on-board the camera can be viewed. The first column contains the detector name, while the second column shows the detector type. Calibrate the detectors via the management software. 4.13. -
Page 25: Rtsp
RTSP The video stream of Intellio cameras can be accessed via a standard RTSP interface, as well, preferably using the recommended VLC video player. The software can be downloaded free at: http://www.videolan.org/vlc/ After starting the program, select the Media/Open Network Stream menu, and type one of the RTSP URL’s in the popup window.
