CONTROLS
WiFi: Enables WiFi capabilities.
SET: Use to set: date/time, alarm settings
(if WiFi has not been configured).
UP: Adjusts setting up in SET menu.
DOWN: Adjusts setting down in SET menu
CHANNEL SELECT: Selects which channel to
display or select all channel view mode to view all
channels.
PLAY/PAUSE: In single channel view mode,
select second line display: current time, current
minimum, current maximum, alarm setting lower
limit, alarm setting higher limit.
C/F: Selects temperature unit
CLEAR: Press to clear current min/max values.
Note: "WiFi enabled" is indicated by the flashing WiFi
symbol. It also indicates that WiFi network needs to
be configured. If WiFi network has been configured,
and WiFi symbol flashes, it indicates an alarm of
unsuccessful data transmission to cloud server.
Press button to clear alarm, or alarm will clear
automatically upon next successful transmission.
DEVICE SPECIFICATIONS:
• Temperature Range: 0 to 50°C (32 to 122°F)
• Humidity Range: 0 to 95%
• Temperature/Humidity Sampling Rate: 9 seconds
• 6525: CO Range: 0 to 10,000 ppm (1%)
2
• 6526: CO Range: 0 to 20%
2
• CO Sample rate: 5 min default, user-adjustable
2
• Default WiFi Transmission Frequency: 15 minutes
• Maximum number of Stored Records: 672 (7 days if set
to 15 minutes interval)
• Max. Stored Alarms: 100
• Battery: 4 AAA Alkaline battery
DISPLAY MODES
SINGLE CHANNEL MODE
• LCD displays information on channel 1, 2, or 3. Scroll
through: current time -> current minimum / current
maximum -> alarm setting minimum / alarm setting
maximum -> current time.
• Scrolling interval: 3 seconds.
• Press CHANNEL SELECT button to select the desired
channel, or all channels.
• Channel 1 displays humidity; Channel 2 displays
temperature; channel 3 displays pressure.
• To pause scrolling, press PLAY/PAUSE. To resume
scrolling, press PLAY/PAUSE again. To fast forward,
press PLAY/PAUSE to move to next item.
• Once desired information is displayed, press Play/
Pause button again to pause scrolling, otherwise
second line resumes scrolling.
ALL CHANNEL MODE
• To view all Channel 1, 2, and 3. Press CHANNEL
SELECT button to select all channels.
• CH123 symbol will appear on display.
www. .com
SELECTING CHANNEL
• While the device is not in SETUP Mode, press
Channel/Select button to select channel.
• If Channel 1 (HUMIDITY) is selected, CH1 symbol will
appear on display.
• If Channel 2 (TEMPERATURE) is selected, CH2
symbol will appear on display.
) is selected, CH3 symbol will appear
• If Channel 3 (CO
2
on display.
• If in all channel view mode, the first line displays
Channel 1, second line Channel 2, and third line
Channel 3. CH123 symbol will appear on display.
SENSORS
6525: A dongle with temperature, humidity, and carbon
dioxide sensor is provided with unit. Used to measure
and monitor ambient temperature, ambient humidity, and
ambient CO levels.
2
IMPORTANT: PLUG DONGLE INTO DEVICE BEFORE
INSERTING BATTERIES AS THIS WILL CAUSE
INCORRECT READINGS.
If dongle sensor was plugged into device after batteries
were installed, remove dongle sensor until LCD reads "-
-.- -" on CH1 and CH2 (about 10 seconds) and then plug
dongle back into device.
6526: An external sensor with extended cable is
provided with unit. Used to measure and monitor
temperature, humidity, and carbon dioxide in a chamber
or other enclosed environment.
CLEAR CURRENT MINIMUM/MAXIMUM MEMORY
1. Press CHANNEL SELECT to select probe channel to
be cleared.
2. CH1 will clear Channel 1; CH2 will clear Channel 2;
CH3 will clear Channel 3 and in all channel mode
CH123 will clear Channels 1, 2, 3.
3. Press CLEAR button to clear current minimum and
maximum readings.
4. Each clear of the Minimum/Maximum memory will
also trigger a transmission of current reading(s) to
TraceableLIVE service, if connected. This will display
in EVENT HISTORY with label "DEVICE CHECK".
DEVICE SETUP
SCENARIO 1: WiFi is disabled. All settings are
configurable.
1. Press and hold SET button for 3s to enter setup
menu.
2. The first flashing number is the year date setting.
Press the UP or DOWN arrow to set to the current
year. Press the PLAY/PAUSE button to save and
proceed to the next setting.
3. Continue to set the remaining parameters (Month-
>Day->Hour->Minute->Time Format (12H/24H)
->Channel 1 Minimum Alarm->Channel 1 Maximum
Alarm->Channel 2 Minimum Alarm->Channel
2 Maximum Alarm->Channel 3 Minimum Alarm
->Channel 3 Maximum Alarm->CO
->Alarm Repost Enable/Disable -> Alarm Repost
information@itm.com
Sampling Rate
2
