- Page 1 MICRO-TALK WIRELESS GATEWAY Installation instructions English (en-US) Date: 02-2022 Document number: 87265 (Rev 4) © 2022 Raymarine UK Limited...
- Page 3 This document contains technology subject to the (US) Export Administration Regulations (EAR) (15. C.F.R. Sections 730-744). Publication copyright Copyright ©2022 Raymarine UK Ltd. All rights reserved. No parts of this material may be copied, translated, or transmitted (in any medium) without the prior written permission of Raymarine UK Ltd. English (en-US) Document number: 87265 (Rev 4) AD;26541;2022-02-07T12:11:41...
-
Page 5: Table Of Contents
Contents Chapter 1 Important information..................9 Water ingress ..........................9 Disclaimer ..........................10 Suppression ferrites ......................... 10 Connections to other equipment.................... 10 Declaration of conformity......................10 Product disposal ........................10 Warranty registration ........................ 10 IMO and SOLAS ......................... 11 Technical accuracy ........................11 Chapter 2 Document information .................. - Page 6 10.1 Troubleshooting ........................ 60 10.2 LED Diagnostics........................ 61 Chapter 11 Maintenance ....................63 11.1 Service and maintenance ....................64 11.2 Routine equipment checks....................64 11.3 Product cleaning ....................... 64 Chapter 12 Technical support..................65 12.1 Raymarine product support and servicing..............66...
- Page 7 Viewing product information ....................67 12.2 Learning resources......................67 Chapter 13 Technical specification ................69 13.1 Technical specification..................... 70 Chapter 14 Spares and accessories ................71 14.1 Accessories ........................72 14.2 SeaTalkng ® cabling components................... 72 14.3 SeaTalkng ® cables and accessories ................72 Appendix A NMEA 2000 PGN support ................
-
Page 9: Chapter 1 Important Information
Although the waterproof rating capacity of this product meets the stated water ingress protection standard (refer to the product’s Technical Specification), water intrusion and subsequent equipment failure may occur if the product is subjected to high-pressure washing. Raymarine will not warrant products subjected to high-pressure washing. -
Page 10: Disclaimer
Raymarine. Raymarine is not responsible for damages or injuries caused by your use or inability to use the product, by the interaction of the product with products manufactured by others, or by errors in information utilized by the product supplied by third parties. -
Page 11: Imo And Solas
In addition, our policy of continuous product improvement may change specifications without notice. As a result, Raymarine cannot accept liability for any differences between the product and this document. Please check the Raymarine website (www.raymarine.com) to ensure you have the most up-to-date version(s) of the documentation for your product. -
Page 13: Chapter 2 Document Information
Chapter 2: Document information Chapter contents • 2.1 Document information on page 14 • 2.2 Applicable products on page 14 • 2.3 Special bundle and promotional products on page 14 • 2.4 Related system packs on page 15 • 2.5 Product documentation on page 16 •... -
Page 14: Document Information
• install and connect your product as part of a wider system of connected marine electronics; • troubleshoot problems and obtain technical support if required. This and other Raymarine product documents are available to download in PDF format from www.raymarine.com/manuals. -
Page 15: Related System Packs
Your product is included in the following system bundles/packages: Part number Products Included Description T70338 / T70345 • Micro-Talk (E70361) Basic sailing starter kit • Wind vane (T120) • Wireless remote (T113–868 / T113–916) T70339 / T70346 • Micro-Talk (E70361) Premium i60 sailing starter •... -
Page 16: Product Documentation
The following documentation is applicable to your product: Description Part number 87265 Micro-Talk Installation instructions Installation of a Micro-Talk gateway and connection to a wider system of marine electronics. 87266 Micro-Talk mounting template Template for surface mounting the Micro-Talk gateway. -
Page 17: Chapter 3 Product And System Overview
Chapter 3: Product and system overview Chapter contents • 3.1 Product overview on page 18 • 3.2 Multiple data sources (MDS) on page 19 • 3.3 SeaTalkng ® on page 19 • 3.4 Micronet on page 19 • 3.5 Networking restrictions on page 19 •... -
Page 18: Product Overview
3.1 Product overview The Micro-Talk gateway bridges data between Micronet (wireless) and SeaTalkng ® networks. When used in conjunction with a SeaTalk ® to SeaTalkng ® converter the data can also be bridged on to the SeaTalk ® network or devices. -
Page 19: Multiple Data Sources (Mds)
3.2 Multiple data sources (MDS) The Micro-Talk gateway is MDS compliant. If a data type is available on the Micronet network then the gateway will be selectable as a data source, for that data type, from SeaTalkng ® displays. In installations where multiple sources of the same data type exist on the Micronet network, the data source that is used by the gateway and transmitted on to SeaTalkng ®... -
Page 20: Installing Software Updates
• Ensure that the unit has a reliable power supply and that the update process is not interrupted. • Damage caused by an incomplete update is not covered by Raymarine warranty. • By downloading the software update package, you agree to these terms. -
Page 21: Chapter 4 Parts Supplied
Chapter 4: Parts supplied Chapter contents • 4.1 Parts supplied on page 22 Parts supplied... -
Page 22: Parts Supplied
4.1 Parts supplied The following parts are supplied with your product. Unit 2. Mounting gasket 3. Documentation 4. 6 m (19.69 ft) SeaTalkng ® (White) cable 5. M4 x 40mm Threaded studs x 3 (used for surface mounting) 6. Finger nuts x 3 (used for surface mounting) Unpack your product carefully to prevent damage or loss of parts, check the box contents against the list above. -
Page 23: Chapter 5 Product Dimensions
Chapter 5: Product dimensions Chapter contents • 5.1 Product dimensions on page 24 Product dimensions... -
Page 24: Product Dimensions
5.1 Product dimensions... -
Page 25: Chapter 6 Location Requirements
Chapter 6: Location requirements Chapter contents • 6.1 Selecting a location on page 26 Location requirements... -
Page 26: Selecting A Location
6.1 Selecting a location Warning: Potential ignition source This product is NOT approved for use in hazardous/flammable atmospheres. Do NOT install in a hazardous/flammable atmosphere (such as in an engine room or near fuel tanks). Micronet device location requirements Your unit includes a wireless transceiver that utilizes the Micronet networking protocol. For optimum performance, the product should be installed above decks, on a horizontal surface with the LED ‘arrow’... -
Page 27: Wireless Location Requirements For Optimum Performance
Wireless location requirements for optimum performance All wireless devices in your system must be located in such a way that they can reliably receive and/or transmit wireless signals. A number of factors can influence wireless performance. For example, physical obstacles and certain vessel structures and materials can all negatively impact wireless performance. -
Page 28: Compass Safe Distance
EMC installation guidelines Raymarine equipment and accessories conform to the appropriate Electromagnetic Compatibility (EMC) regulations, to minimize electromagnetic interference between equipment and minimize the effect such interference could have on the performance of your system Correct installation is required to ensure that EMC performance is not compromised. -
Page 29: Chapter 7 Installation
Chapter 7: Installation Chapter contents • 7.1 Installation checklist on page 30 • 7.2 Tools required for installation on page 30 • 7.3 Warnings and cautions on page 31 • 7.4 Surface mounting on page 31 • 7.5 Pole or rail mounting on page 32 •... -
Page 30: Installation Checklist
7.1 Installation checklist Installation includes the following activities: Installation Task Plan your system. 2. Obtain all required equipment and tools. 3. Site all equipment. 4. Route all cables. 5. Drill cable and mounting holes. 6. Make all connections into equipment. Secure all equipment in place. -
Page 31: Warnings And Cautions
7.3 Warnings and cautions Important: Before proceeding, ensure that you have read and understood the warnings and cautions provided in the Chapter 1 Important information section of this document. 7.4 Surface mounting The unit can be mounted on a surface that is up to approximately 28 mm (1.10 in) thick using the fixings supplied with the unit. -
Page 32: Pole Or Rail Mounting
4. Connect the cable to an available SeaTalk spur connection then connect the other end to the connector on the underside of the unit and secure using the locking collar. 5. Screw the threaded studs into the underside of the unit (these should be hand-tight only). 6. -
Page 33: Surface Mounting Using The Deck Mounting Kit
7.6 Surface mounting using the Deck mounting kit The Deck mounting kit (A80437) can be used to surface mount your product. The Riser and Bracket pieces are not required for this installation. Ensure that the chosen location meets the product’s location requirements, see 6.1 Selecting a location for details. -
Page 34: Bracket Mounting Using The Deck Mounting Kit
5. Pull the SeaTalkng ® cable through the mounting surface hole and the Mounting tray. Plug in the cable connector on the underside of the unit and secure by rotating the locking collar clockwise 2 clicks. 6. Insert the unit into the mounting tray, ensuring the tabs in the Mounting tray are slotted into the grooves around the edge of the unit. - Page 35 1. Use the Mounting bracket template (87170) to drill 3 pilot holes in the vertical mounting surface. Secure the mounting bracket to the surface using the supplied screws. 2. Place the small sealing ring in the groove located on the bottom of the Mounting tray. 3.
-
Page 36: Surface Mounting Using The Riser
6. Insert the unit into the mounting tray, ensuring the tabs in the Mounting tray are slotted into the grooves around the edge of the unit. 7. Orientate the Mounting trim so that the release hole is accessible when mounted. 8. - Page 37 1. Use the Deck Mount riser template (87280) provided with the kit (A80437) to drill 4 holes in the mounting surface. Secure the Riser to the mounting surface using the 4 supplied fixings. 2. Place the small sealing ring in the groove located on the bottom of the mounting tray. 3.
- Page 38 6. Pull the SeaTalkng ® cable through the Riser and Mounting tray. Plug in the cable connector on the underside of the unit and secure by rotating the locking collar clockwise 2 clicks. Note: If there is not enough space in the riser to accommodate the cable and to plug the SeaTalkng ®...
-
Page 39: Releasing The Unit From The Bracket
7.9 Releasing the unit from the bracket Follow the steps below to release the unit from the Mounting bracket. 1. Insert the flat of a small flat blade screw driver, or similar tool into the release hole located on the flat edge of the mounting bracket and twist the screw driver 90°, so that there is a small gap between the Mounting trim and Mounting tray. -
Page 41: Chapter 8 Cables And Connections
Chapter 8: Cables and connections Chapter contents • 8.1 General cabling guidance on page 42 • 8.2 Connections overview on page 43 • 8.3 SeaTalkng ® power supply on page 43 • 8.4 Network examples on page 50 Cables and connections... -
Page 42: General Cabling Guidance
• Unless otherwise stated only use cables supplied by Raymarine. • Where it is necessary to use non-Raymarine cables, ensure that they are of correct quality and gauge for their intended purpose. (e.g.: longer power cable runs may require larger wire gauges to minimize voltage drop along the run). -
Page 43: Connections Overview
8.2 Connections overview Your product includes the following connections. Connection Connects to: Suitable cables SeaTalkng ® backbone SeaTalkng ® spur cables 2. NMEA 2000 backbone 2. SeaTalkng ® to DeviceNet adaptor cable (A06045) Can connect up to 32 Compatible Micronet (wireless) devices simultaneously. -
Page 44: Seatalkng ® Power Connection Point
• connection via a 12 V dc distribution panel • via an Autopilot Control Unit (ACU) (not ACU-100 or 150), or an SPX course computer (not SPX-5) that is connected to the SeaTalkng ® backbone. • for 24 V vessels, via a 5 amp, regulated, continuous 24 V dc to 12 V dc converter Note: •... -
Page 45: Seatalkng ® System Loading
• The information provided below is for guidance only, to help protect your product. It covers common vessel power arrangements, but does NOT cover every scenario. If you are unsure how to provide the correct level of protection, please consult an authorized Raymarine dealer or a suitably qualified professional marine electrician. - Page 46 Implementation — connection to distribution panel Waterproof fuse holder with 5 A inline fuse must be fitted (not supplied). 2. SeaTalkng ® power cable. 3. RF Ground connection point for drain wire. • Ideally, the SeaTalkng ® power cable should be connected to a suitable breaker or switch on the vessel's distribution panel or factory-fitted power distribution point.
- Page 47 Important: Observe the recommended fuse / breaker ratings provided in the product’s documentation, however be aware that the suitable fuse / breaker rating is dependent on the number of devices being connected. Implementation — direct connection to battery • SeaTalkng ®Where connection to a power distribution panel is not possible, the power cable may be connected to the vessel's battery..
-
Page 48: Sharing A Breaker
• For power cable extensions, a minimum wire gauge of 16 AWG (1.31 mm ) is recommended. For cable runs longer than 15 meters, you may need to consider a thicker wire gauge (e.g. 14 AWG (2.08 mm ), or 12 AWG (3.31 mm ) ). - Page 49 Warning: Product grounding Before applying power to this product, ensure it has been correctly grounded, in accordance with the instructions provided. Warning: Positive ground systems Do not connect this unit to a system which has positive grounding. Cables and connections...
-
Page 50: Network Examples
8.4 Network examples The illustrations below are provided as examples only. Example system with wireless hull transmitter Mast rotation sensor 2. Micronet Wind transducer 3. Micro-Talk gateway 4. Wireless instrument 5. Heading source (e.g.: Evolution EV sensor) 6. SeaTalkng ® instrument... - Page 51 SeaTalkng ® Pilot Controller 8. SeaTalkng ® MFD 9. SeaTalkng ® 5–way block 10. DST transducer 11. Wireless hull transmitter Example system with SeaTalkng ® DST transducer Mast rotation sensor 2. Micronet Wind transducer 3. Micro-Talk gateway Cables and connections...
- Page 52 4. Wireless instrument 5. Heading source (e.g.: Evolution EV sensor) 6. SeaTalkng ® instrument SeaTalkng ® Pilot Controller 8. SeaTalkng ® MFD 9. SeaTalkng ® 5–way block 10. DST transducer...
-
Page 53: Chapter 9 System Operation And Setup
Chapter 9: System operation and setup Chapter contents • 9.1 Transducer calibration on page 54 • 9.2 Autonetworking on page 54 • 9.3 Powering the unit on and off on page 57 • 9.4 Data damping on page 57 System operation and setup... -
Page 54: Transducer Calibration
The Micro-Talk gateway combines SeaTalkng ® and MicroNet networks together. Prior to powering on the Micro-Talk gateway for the first time you must ensure that all transducers are calibrated. This is particularly important with the Mast rotation device, which must be linearized after and independently of your primary heading source. -
Page 55: Performing Autonetworking
Performing Autonetworking Follow the steps below to add new Micronet products to an existing system, or create a new system from multiple boxes. Note: • Autonetworking should be performed before new products are mounted. • The following procedure is NOT required when creating a new system with products that have been supplied in a single box. - Page 56 7. Press the Down/Power button until the Options page is displayed. 8. Press the Right button to display the Autonetworking page. 9. Press the Set up button to begin the Autonetworking procedure. A countdown will begin and the chosen display shows ‘WAIT’ and then ‘JOIN’ as devices join the network.
-
Page 57: Powering The Unit On And Off
Powering off The Micro-Talk unit is powered off when the SeaTalkng ® network it is connected to is powered off. 9.4 Data damping Data damping affects the responsiveness of display data to changes in the data received from connected transducers/sensors. - Page 58 To determine whether you should make the damping changes on SeaTalkng ® or MicroNet, the user should consider the other products in their networks. For example: • if an Autopilot is present on the SeaTalkng ® network and the wind data source is on the MicroNet network, then it is recommended that the Response setting for wind data is set to Fast, so that the Autopilot receives more dynamic data.
-
Page 59: Chapter 10 Troubleshooting
Chapter 10: Troubleshooting Chapter contents • 10.1 Troubleshooting on page 60 • 10.2 LED Diagnostics on page 61 Troubleshooting... -
Page 60: Troubleshooting
If after referring to this section you are still having problems with your product, please refer to the Technical support section of this manual for useful links and Raymarine Product Support contact details. -
Page 61: Led Diagnostics
Status Action Unit powering up None Power up failed Power cycle unit Multiple Micro-Talk gateways Remove all but 1 Micro-Talk detected on SeaTalkng ® gateway from SeaTalkng ® Green SeaTalkng ® powered up, None Micronet powering up Micronet connection failed... -
Page 63: Chapter 11 Maintenance
Chapter 11: Maintenance Chapter contents • 11.1 Service and maintenance on page 64 • 11.2 Routine equipment checks on page 64 • 11.3 Product cleaning on page 64 Maintenance... -
Page 64: Service And Maintenance
11.1 Service and maintenance This product contains no user serviceable components. Please refer all maintenance and repair to authorized Raymarine dealers. Unauthorized repair may affect your warranty. 11.2 Routine equipment checks It is recommended that you perform the following routine checks, on a regular basis, to ensure the correct and reliable operation of your equipment: •... -
Page 65: Chapter 12 Technical Support
Chapter 12: Technical support Chapter contents • 12.1 Raymarine product support and servicing on page 66 • 12.2 Learning resources on page 67 Technical support... -
Page 66: Raymarine Product Support And Servicing
You can obtain this product information using diagnostic pages of the connected MFD. Servicing and warranty Raymarine offers dedicated service departments for warranty, service, and repairs. Don’t forget to visit the Raymarine website to register your product for extended warranty benefits: http://www.raymarine.co.uk/display/?id=788. United Kingdom (UK), EMEA, and Asia Pacific: •... -
Page 67: Viewing Product Information
5. Select the relevant product from the list. The Diagnostics page is displayed. 12.2 Learning resources Raymarine has produced a range of learning resources to help you get the most out of your products. Video tutorials Raymarine official channel on YouTube: •... -
Page 69: Chapter 13 Technical Specification
Chapter 13: Technical specification Chapter contents • 13.1 Technical specification on page 70 Technical specification... -
Page 70: Technical Specification
13.1 Technical specification Nominal supply voltage 12 V dc (Supplied by SeaTalkng ®) Operating voltage range 9 V dc to 16 V dc (protected up to 32 V dc) Power consumption 25 mA at nominal supply voltage Operating frequency (MicroNet) •... -
Page 71: Chapter 14 Spares And Accessories
Chapter 14: Spares and accessories Chapter contents • 14.1 Accessories on page 72 • 14.2 SeaTalkng ® cabling components on page 72 • 14.3 SeaTalkng ® cables and accessories on page 72 Spares and accessories... -
Page 72: Accessories
14.1 Accessories The following accessories are available: Accessories Item Part number Pole/rail mounting adaptor kit A80370 6 m SeaTalkng white spur cable A06072 Deck mounting (Clamshell/Riser) kit A80437 14.2 SeaTalkng ® cabling components SeaTalkng ® cabling components and their purposes. Connection / Cable Notes Backbone cable (various lengths) - Page 73 4. 1 x 5-Way connector (A06064). Each connector block allows connection of up to 3 SeaTalkng devices. Multiple connector blocks can be ‘daisy chained’ together. Backbone kit (A25062) consists of: 2 x 5 m (16.4 ft) Backbone cables (A06036). Used to create and extend the SeaTalkng backbone. 1 x 20 m (65.6 ft) Backbone cable (A06037).
- Page 74 1 x 2 m (6.6 ft) Power cable (A06049). Used to provide 12 V dc power to the SeaTalkng backbone. 2. 1 x 1 m (3.3 ft) Spur cable (A06039). Used to connect a device to the SeaTalkng backbone. 3. 1 x 0.4 m (1.3 ft) SeaTalk (3 pin) to SeaTalkng adapter cable (A22164). Used to connect SeaTalk devices to the SeaTalkng backbone via the SeaTalk to SeaTalkng converter.
- Page 75 SeaTalkng spur cables: • 0.4 m (1.3 ft) Spur cable (A06038). • 1 m (3.3 ft) Spur cable (A06039). • 3 m (9.8 ft) Spur cable (A06040). • 5 m (16.4 ft) Spur cable (A06041). 2. 0.4 m (1.3 ft) Elbow (right angled) to elbow spur cable (A06042). Used in confined spaces where a straight spur cable will not fit.
- Page 76 2 m (6.6 ft) Power cable (straight) (A06049). 2. 2 m (6.6 ft) Elbow (right angled) power cable (A06070). SeaTalkng ® connectors SeaTalkng connectors are used to connect SeaTalkng devices to the SeaTalkng backbone and to create and extend the backbone. 5-Way connector (A06064).
- Page 77 1 m (3.3 ft) SeaTalk (3 pin) to SeaTalkng converter cable (A22164 / A06073). Can be used to connect a SeaTalk device to a SeaTalkng backbone via the SeaTalk to SeaTalkng converter, or to connect a SeaTalkng product directly to a SeaTalk network. 2.
-
Page 79: Appendix A Nmea 2000 Pgn Support
Appendix A NMEA 2000 PGN support The unit supports the following NMEA 2000 PGNs. Receive Transmit Description (Rx) (Tx) ● 59904 ISO Request 59392 ISO Acknowledgement ● 60160 ISO Transport protocol, data ● transfer 60416 ISO Transport protocol, connection ● ●... - Page 81 Maintenance............9, 64 Protection ............42 Maximum range, See Range Routing ..............42 MDS, See Multiple data sources Security ..............42 Micro-Talk ............14, 18 Strain relief............42 Micronet ..............19 Circuit breaker connection ........48 Micronet displays ............54 Cleaning ..............9, 64 Mounting location, See Location requirements Compass safe distance ...........28...
- Page 82 Power cable extension ..........47 Power consumption..........70 Product dimensions, See Dimensions Product features ............18 Product loading ............43 Product orientation, See Orientation Product recycling (WEEE) ........10 Product support............66 Rail mounting............32 Range ..............26 Riser ................36 Routine checks ............64 SeaTalkng ...............
- Page 84 Raymarine Marine House, Cartwright Drive, Fareham, Hampshire. PO15 5RJ. United Kingdom. Tel: +44 (0)1329 246 700 www.raymarine.com a brand by...
